6SN1118-1NK01-0AA1 Siemens Simodrive Axis Control – Product Info

6SN1118-1NK01-0AA1 Siemens Simodrive Axis Control – Product Info

The 6SN1118-1NK01-0AA1 Simodrive Axis Control card is part of the Simodrive 611 series. It is a 2 axis control card that is used for resolver speed/torque setpoint positioning. This card is expandable by using option modules. For more information, you can visit the product page for the Siemens 6SN1118-1NK01-0AA1 Control.

Continue reading 6SN1118-1NK01-0AA1 Siemens Simodrive Axis Control – Product Info

Micromaster 420

Siemens Micromaster 420 Faults and Alarms

A blog we posted earlier this week about the Micromaster 420 troubleshooting referenced the Faults and Alarms list for the Micromaster series, so we decided that it would make sense to make the list of Micromaster 420 Faults and Alarms directly available. This is from the corresponding manual for the Micromaster 420 series, but it is buried within the manual which most people most likely don’t even have. Hopefully this helps with your troubleshooting.

View our 420 Micromaster Drives in stock. For more information or to request a quote, please call 800-691-8511 or email sales@mroelectric.com. We also provide pre-priced Micromaster 420 Repairs.

Continue reading Siemens Micromaster 420 Faults and Alarms

6AV2124-0GC01-0AX0

Siemens 6AV2124-0GC01-0AX0: Beyond the User Manual

The Siemens 6AV2124-0GC01-0AX0 is a TP700 Comfort Panel with a 7 inch widescreen TFT display. It has 12MB of user memory, Windows CE 6.0, as well as Profinet and MPI/Profibus DP interfaces. The panel uses a 24V DC supply input, with a permissible range from 19.2 V to 28.8 V.  It’s input current has a consumption of 0.5 A.

When connecting the power supply, be sure to switch it off before connecting to the HMI. Check the correct polarity of the cables using the interface marking on the back of the panel. Once the power supply connector is in the corresponding socket of the HMI, switch on the power. The HMI is equipped with a reverse polarity protection circuit. Once the power is turned on, the 6AV2124-0GC01-0AX0 display will light up. If the panel fails to start, you may have crossed the cables at the power supply connector. Once the operating system starts, the desktop with the Start Center is displayed. The panel will automatically switch to “Transfer” mode during the initial startup if either no project is loaded on the HMI device, or if at least one data channel has been configured.

The backlight on the 6AV2124-0GC01-0AX0 is good for roughly 80,000 hours. If your panel has been in use for longer and you are experiencing issues, you may want to consider contacting MRO Electric to order a replacement.
6AV2124-0GC01-0AX0
6AV2124-0GC01-0AX0

The 6AV2124-0GC01-0AX0 offers excellent functionality and is configured exclusively with the outstanding HMI software, WinCC. The software is integrated into the engineering framework Totally Integrated Automation Portal (TIA Portal).  Additionally, there a number of software add-ons available. These include WinCC/Sm@rtServer, WinCC/Audit, UPS, Microsoft Excel Viewer, Microsoft PDF Viewer, Microsoft Word Viewer, and printer driver. This panel is certified by a number of organizations to be used on marine vessels and certain hazardous areas.

For more information on the 6AV2124-0GC01-0AX0 Comfort Panel or to request a price quote, please call 800-691-8511 or email sales@mroelectric.com.

Below is the 6AV2124-0GC01-0AX0 datasheet and manual in PDF format.

6AV21240GC010AX0



6AV2124-0GC01-0AX0
A06B-6105-H002

A06B-6105-H002 – FANUC Robotics R-2000iA Servo Amplifier

The FANUC A06B-6105-H002 is a servo amplifier used with the FANUC Robot Module R-2000iA. Usually these amplifiers are factory set for operation, so you do not need to set or adjust them. However, if you need to configure or troubleshoot your A06B-6105-H002, please follow the instructions below. Take not that before touching your servo amplifier, you should always check the voltage at the screw above LED “D7” to ensure that the remaining voltage is not higher than 50V.

The following table highlights the various LEDs on the A06B-6105-H002 and their meanings.

LED Color Description
P5V Green Lights when the power supply circuit inside of the servo amplifier outputs a voltage of +5V normally.
P3.3V Green Lights when the power supply circuit inside of the servo amplifier outputs a voltage of +3.3V normally.
SVEMG Red Lights when an emergency stop signal is input to the servo amplifier.
ALM Red Lights when the servo amplifier detects an alarm.
RDY Green Lights when the servo amplifier is ready to drive the servo motor.
OPEN Green Lights when the communication between the servo amplifier and the main board is normal.
WD Red Lights when the watchdog alarm is detected in the servo amplifier.
D7 Red Lights when the DCLINK circuit inside the servo amplifier is charged to reach a specific voltage.

If you need to replace the A06B-6105-H002 amplifier on your R-2000iA, ensure that you begin by first turning off the control unit main power. Next detach the amplifier cover and pull out the cable. Check the screw above LED D7 with a DC voltage tester to make sure the remaining voltage is not above 50V. Remove the two screws located on the top of the amplifier. At the middle top of the drive, there is an M5 screw that fastens the amplifier during the transport of the cabinet. After installation of the cabinet, remove the screw as this will help improve maintainability.  After these steps are complete, you can pull the amplifier toward you using the handles located at the top and bottom. Be careful not to touch any components on the lower part of the drive’s PCB, and try not to damage any cables routed under the amp when pulling it out. Use a slanted angle when pulling it out.

You can easily install a replacement by reversing the steps above.

MRO Electric and Supply has spare A06B-6105-H002 Servo Amplifiers available. For more information or to request a quote, please email sales@mroelectric.com or call 800-691-8511.
