Siemens Simatic 6AV6647-0AF11-3AX0: Beyond the User Manual

The 6AV6647-0AF11-3AX0 is a Simatic 477 HMI  Basic Panel with a key and touch operation, and a 10 inch TFT display.

The panel has a Profinet interface, a RISC 32-bit processor, and contains open-source software which is provided free of charge. The 6AV6647-0AF11-3AX0 is best mounted vertically in a landscape position.

The 6AV6647-0AF11-3AX0 uses a 24V DC power supply, however its permissible voltage can range from 19.2V to 28.8V DC. The panel is intended for operation on grounded supply networks only, it is not designed for operation on ungrounded or impedance-grounded power networks. The permitted nominal voltage of the device must conform with the local mains voltage. The mains connector must be disconnected to completely isolate the device from the mains. It is helpful if easy access is left to this area during installation. The master mains disconnect switch must be installed in the device is mounted in a switch cabinet. Always and be sure to have free and easy access to the power inlet on the device or that the safety power outlet of the building installation is freely accessible and located close the device.

During 6AV6647-0AF11-3AX0 commissioning and its first start up, the Windows XP operating system on the Compact Flash card or hard disk is configured automatically. Follow the instructions on the screen, and then restart the system after you have entered all the necessary information and the operating system is configured. It is important to note that system startup may take longer than usual for the basic commissioning – it is normal for a blue screen to be displayed for several minutes. After this, when you switch on the PC, the user interface of the Windows XP Embedded operating system is automatically opened when the startup routine is completed.

It is advisable to create an image of your system partition after basic commissioning in order to prevent potential data loss.

MRO Electric carries new and refurbished Simatic 6AV6647-0AF11-3AX0 Panels.  For more information or to request a quote, please call 800-691-8511 or email sales@mroelectric.com.
