170INT11000

2-year Warranty

Same Day Shipping

Schneider Electric 170INT11000

Rated 5/5 on 1 review

Rate this product


MANUFACTURER: schneider electric

DESCRIPTION: Momentum - Interbus, Adaptor - Twisted Pair

PRODUCT TYPE INFO:  Modicon Communication

25 in stock


Free Shipping

2 Year warranty

Part Number170INT11000
ManufacturerSchneider Electric
TypeAccessories
Model #170-INT-110-00
Warranty2 Year
Local signalling1 LED green module powered up or in service (RUN)
1 LED red fault state (ERR)
1 LED yellow recieve or send data (COM)
Range of productModicon Momentum automation platform
Product or component typeInterbus communication adaptor
Communication port protocolInterbus generation SUPI 2
Method of accessContinuous shift register
Master/Slave
Transmission rate500 kbit/s
Transmission support mediumTwisted pair
TopologyRing
Number of devices0...254
Cable length<= 41994.75 ft (12800 m)
<= 1312.34 ft (400 m) between two modules
Fail stateFail safe
Control parameterCRC-16
SupplyFrom I/O base
MarkingCE
Local signalling1 LED green bus enable (BA)
1 LED green remote bus check (RC)
1 LED green remote bus disabled (RD)
Electrical connection2 connectors SUB-D 9 for connecting Interbus

Our Repair Services

MRO Electric repairs CNCs, PLCs, Servo/Spindle Drives, Motors, Amplifiers, VFDs, HMIs, and more, most of which can be repaired in only 3-5 days.

Repair Benefits

MRO can restore your failed 170INT11000 to remanufactured condition and save you up to 75% compared to buying new. We offer standard repair pricing to ensure you the best value for your repair.

Our certified technicians use rigorous testing procedures to ensure your parts are restored to fully functioning condition. Our team proudly stands behind all repairs by providing a minimum 2-year warranty.

Our technicians have vast experience with most manufacturers and models. In addition to this 170INT11000 we also repair drives, motors, PLCs and more, so if you don’t see the model you need, please contact us.

Core Exchange

If you are interested in getting credit for your faulty 170INT11000, just let us know, and we can issue you an RMA to send it in as an exchange. Our exchange program provides you with savings and keeps us stocked for the next time you need anything.

  • Shipping Weight : 1lb

Want it shipped tomorrow?

  • Order within the next 19 hours and 20 minutes.
  • If you order between 4pm and 6pm EST, you will be charged a small rush fee.

Ask about exchanging your faulty 170INT11000 for credit when ordering from MRO Electric

MRO Electric provides a 2-year warranty on every item we sell and repair. We stand behind all of our products and guarantee them for the full 2 years. If there is an issue with any of our products within the warranty period, we will evaluate the unit and repair or replace it under warranty.

Schneider Electric 170INT11000 Overview

Modicon Momentum 170INT11000 Interbus Communication Adaptor

Efficient Interbus Communication for Automation

The Modicon Momentum 170INT11000 Interbus Communication Adaptor is a crucial component within the Modicon Momentum automation platform, designed to facilitate seamless communication using the Interbus protocol. In this technical description, we explore the specifications, features, and frequently asked questions related to this communication adaptor.

Specifications:

Communication Protocol: Interbus generation SUPI 2

Access Method: Continuous shift register, Master/slave

Transmission Rate: 500 kbit/s

Transmission Medium: Twisted pair

Topology: Ring

Devices per Segment: 0 to 254

Maximum Cable Distance between Devices: 12,800 meters (41,995 feet)

Fail State: Fail-safe

Control Parameter: CRC-16

Supply: From I/O base

Marking: CE

Local Signalling:

  • Bus Enable (BA): 1 LED (green)
  • Remote Bus Check (RC): 1 LED (green)
  • Remote Bus Disabled (RD): 1 LED (green)
  • Electrical Connection: 2 connectors SUB-D 9 for connecting Interbus
  • Module Format: Standard
  • Net Weight: 0.15 lb (0.07 kg)

Environmental Specifications:

Product Certifications: UL, FM Class 1 Division 2, CSA

Degree of Protection: IP20

Protective Treatment: TC

Resistance to Electrostatic Discharge:

  • 4 kV contact (IEC 801-2)
  • 8 kV on air (IEC 801-2)
  • Resistance to Electromagnetic Fields:
  • 9.14 V/m (10 V/m) at 80-1000 MHz (IEC 801-3)
  • Operating Temperature: 0-60°C (32-140°F)
  • Storage Temperature: -40-85°C (-40-185°F)
  • Relative Humidity: 95% without condensation
  • Operating Altitude: Up to 5000 meters (16,404.2 feet)

FAQs:

Q: What is the main purpose of the Modicon Momentum 170INT11000 Interbus Communication Adaptor?

A: The 170INT11000 facilitates communication between devices in an Interbus network within the Modicon Momentum automation platform.

Q: What is the maximum number of devices that can be connected to a single segment with this adaptor?

A: This adaptor supports up to 254 devices on a single segment.

Q: Can you explain the LED indicators on the adaptor?

A: Certainly. There are three LED indicators:

  • Bus Enable (BA): Indicates the activation of the bus.
  • Remote Bus Check (RC): Shows the status of remote bus checking.
  • Remote Bus Disabled (RD): Indicates when the remote bus is disabled.

Q: Is the Modicon Momentum 170INT11000 suitable for use in harsh industrial environments?

A: Yes, this communication adaptor is designed to operate in a wide temperature range and offers resistance to electrostatic discharge and electromagnetic fields.

Q: How is the Modicon Momentum 170INT11000 powered?

A: It is powered directly from the I/O base within the Modicon Momentum system.

Q: What is the purpose of the CRC-16 control parameter?

A: The CRC-16 control parameter is used for error checking to ensure data integrity during communication.

Q: Can this adaptor be used in hazardous locations?

A: Yes, it has certifications such as UL and FM Class 1 Division 2, making it suitable for use in certain hazardous environments.

The Modicon Momentum 170INT11000 Interbus Communication Adaptor is an essential component for establishing efficient communication in industrial automation applications. With robust environmental specifications and support for a large number of devices, it ensures reliable and secure data exchange within the Interbus network. For detailed installation and configuration instructions, please refer to the user manual provided with the product.
