3RT1015-1AK61

2-year Warranty

Same Day Shipping

Siemens 3RT1015-1AK61

MANUFACTURER: Siemens
DESCRIPTION: 110/120VAC 50/60HZ 3POLE 1NO AC3...
INFO: Contactors


4 in stock

Ships Today


Free Shipping

2 Year warranty

Part Number3RT1015-1AK61
ManufacturerSiemens
TypeContactors
Model #3RT10151AK61
Warranty2 Year
RangeSIRIUS
CategoryPower contactor
Ambient temp-25 … +B5˚C
Degreee of pollution3
ProtectionIP20
Contactor sizeS00
Input type (Analog)AI1 voltage 0...10 V DC 30000 Ohm 10 bits AI2 bipolar differential voltage +/- 10 V DC 30000 Ohm 10 bits AI3 current 0...20 mA (or 4-20 mA, x-20 mA, 20-x mA or other patterns by configuration) 250 Ohm 10 bits
Input type (Discrete)Programmable (sink/source) DI1...DI4)24...30 V DC level 1 PLC Programmable as pulse input 20 kpps DI5)24...30 V DC level 1 PLC Switch-configurable PTC probe DI6)24...30 V DC Safe torque off STO)24...30 V DC - 1500 Ohm
Output type (Analogue)AQ1 software-configurable current 0...20 mA 800 Ohm 10 bits AQ1 software-configurable voltage 0...10 V 470 Ohm 10 bits
Output type (Discrete)Configurable relay logic R1A, R1B, R1C) NO/NC - 100000 cycles Configurable relay logic R2A, R2B) NO - 100000 cycles Logic LO)
Motor power5.5…7.5 kW 380…500 V 3 phase
Number of addresses1…127 CANopen 1…247 Modbus serial
Method of accessSlave CANopen
Local signallingCANopen run 1 LED green) CANopen error 1 LED red) Drive fault 1 LED red) Drive voltage 1 LED red)
Height12.13 in
Width5.91 in
Depth9.13 in
Analogue input 3
Discrete input7
Analogue output 1

Our Repair Services

MRO Electric repairs CNCs, PLCs, Servo/Spindle Drives, Motors, Amplifiers, VFDs, HMIs, and more, most of which can be repaired in only 3-5 days.

Repair Benefits

MRO can restore your failed 3RT1015-1AK61 to remanufactured condition and save you up to 75% compared to buying new. We offer standard repair pricing to ensure you the best value for your repair.

Our certified technicians use rigorous testing procedures to ensure your parts are restored to fully functioning condition. Our team proudly stands behind all repairs by providing a minimum 2-year warranty.

Our technicians have vast experience with most manufacturers and models. In addition to this 3RT1015-1AK61 we also repair a wide range of other Siemens products, so if you don’t see the model you need, please contact us.

Core Exchange

If you are interested in getting credit for your faulty 3RT1015-1AK61, just let us know, and we can issue you an RMA to send it in as an exchange. Our exchange program provides you with savings and keeps us stocked for the next time you need anything.

  • Shipping Weight : 1lb

Want it shipped today?

  • Order within the next 9 hours and 26 minutes.
  • If you order between 4pm and 6pm EST, you will be charged a small rush fee.

Ask about exchanging your faulty 3RT1015-1AK61 for credit when ordering from MRO Electric

MRO Electric provides a 2-year warranty on every item we sell and repair. We stand behind all of our products and guarantee them for the full 2 years. If there is an issue with any of our products within the warranty period, we will evaluate the unit and repair or replace it under warranty.

Siemens 3RT1015-1AK61 Overview

Siemens products are manufactured in Germany and are designed for Automotive, aerospace, power generation, and electronics usage. They come with a 2-year warranty from MRO Electric. We also carry Contactors from other manufacturers such as FANUC and Yaskawa.

Overview of 3RT1015-1AK61 Power Contactor

The 3RT1015-1AK61 is a robust power contactor manufactured under the esteemed SIRIUS product brand. This contactor, categorized as an S00 size unit, is engineered for AC-3 applications, capable of handling a substantial 3 kW power load at 400 V with 1 NO (normally open) auxiliary contact. Crafted to meet rigorous quality and performance standards, it is a dependable choice for a wide spectrum of industrial and commercial applications.

General Specifications for Versatility

In terms of its general specifications, the 3RT1015-1AK61 boasts an IP20 protection class on the front side, making it suitable for diverse operating conditions. With a degree of pollution rated at 3, this contactor can perform optimally at altitudes of up to 2,000 meters above sea level. Furthermore, it exhibits a broad operating temperature range, spanning from -25°C to +60°C, ensuring adaptability in various environments. Its efficiency is noteworthy, with an active power loss of just 0.42 W per conductor.

Mechanical Durability

This contactor is built to withstand extensive mechanical use, with impressive mechanical operating cycles. It can endure 30,000,000 cycles on its own, 10,000,000 cycles when combined with an auxiliary switch block, and 5,000,000 cycles with an electronics-compatible auxiliary switch block.

Main Circuit Performance

In the main circuit, the 3RT1015-1AK61 is designed with 3 poles and 3 NO (normally open) contacts, making it a versatile choice for controlling electrical circuits. Its operating current ratings for AC-1 are 18 A at 400 V (at 40°C) and 16 A at 400 V (at 60°C). For AC-3 applications, it can handle 7 A at 400 V. Additionally, it offers flexibility with various current ratings for DC-1 and DC-3/DC-5 applications, depending on voltage and path configuration.

Service Power and Control Circuit Service power capabilities include 11 kW at 400 V for AC-1, 3 kW at 400 V for AC-2, 3 kW at 400 V, 3.5 kW at 500 V, and 4 kW at 690 V for AC-3 applications. In the control circuit, the 3RT1015-1AK61 operates conventionally with AC voltage. Users can choose between 50 Hz (110 V) and 60 Hz (120 V) control supply voltage options, enhancing their adaptability to different power systems.

Auxiliary Circuit and Safety

This contactor also features an auxiliary circuit with reliable contacts, offering 1 faulty switching per 100 million operations. With a single NO instantaneous switching contact, it can accommodate various operating currents, depending on the application and voltage. For short-circuit protection, a 10 A fuse (gL/gG) is required for the auxiliary switch, while the main circuit necessitates a 35 A fuse (gL/gG) for Type 1 coordination and a 20 A fuse (gL/gG) for Type 2 coordination.

Installation and Versatility

Installation is convenient, with a screw and snap-on mounting system onto a 35 mm standard mounting rail according to DIN EN 50022. Overall, the 3RT1015-1AK61 stands as a reliable and versatile power contactor, suited for a wide range of electrical control applications, characterized by its durability, efficiency, and adherence to international standards.
