MANUFACTURER: Siemens
DESCRIPTION: INTEGRATED ENABLING BUTTON, STOP BUTTON, HANDWHEEL, KEY SWITCH
PRODUCT TYPE INFO: SIMATIC 277 MOBILE PANEL
1 in stock
Ships Today
Free Shipping
2 Year warranty
Part Number | 6AV6645-0CC01-0AX0 |
Manufacturer | Siemens |
Type | HMIs |
Model # | 6AV66450CC010AX0 |
Warranty | 2 Year |
Display | TFT |
Control | Keys and touch |
Function keys | 18 LED keys |
Touch screen | Analog, resistive |
Screen diagonal | 7.5 in |
Connection | USB |
MTBF backlighting | 50 000 h |
Operator controls | Stop button, Key-operated switch, Handwheel, |
Supply voltage | DC |
Memory | Flash / RAM |
Color display | 65 536 colors |
Resolution | Horizontal, 640 pixel, Vertical 480 pixel |
User data Memory | 6 Mbyte |
Capacity of main memory | 128 Mbyte |
Protocols | PROFINET IO, PROFIBUS, |
EtherNet/IP, | |
AS-Interface, TCP/IP, MODBUS | |
Standards | CE mark, cULus, RCM |
MRO Electric repairs CNCs, PLCs, Servo/Spindle Drives, Motors, Amplifiers, VFDs, HMIs, and more, most of which can be repaired in only 3-5 days.
MRO can restore your failed 6AV6645-0CC01-0AX0 to remanufactured condition and save you up to 75% compared to buying new. We offer standard repair pricing to ensure you the best value for your repair.
Our certified technicians use rigorous testing procedures to ensure your parts are restored to fully functioning condition. Our team proudly stands behind all repairs by providing a minimum 2-year warranty.
Our technicians have vast experience with most manufacturers and models. In addition to this 6AV6645-0CC01-0AX0 we also repair a wide range of other Siemens products, so if you don’t see the model you need, please contact us.
If you are interested in getting credit for your faulty 6AV6645-0CC01-0AX0, just let us know, and we can issue you an RMA to send it in as an exchange. Our exchange program provides you with savings and keeps us stocked for the next time you need anything.
Want it shipped today?
Ask about exchanging your faulty 6AV6645-0CC01-0AX0 for credit when ordering from MRO Electric
The Siemens SIMATIC 6AV6645-0CC01-0AX0 Mobile Panel 277 comes with an integrated acknowledgment button, stop pushbutton, handwheel, key switch, and two illuminated push-buttons. It can be configured with WinCC flexible Standard Version 2005 SP1 or higher, or TIA Portal V11 to V14. These products are manufactured in Germany and are designed for Automotive, aerospace, power generation, and electronics usage. They come with a 2-year warranty from MRO Electric. We also carry HMIs from other manufacturers such as FANUC and Yaskawa.
The Siemens 6AV6645-0CC01-0AX0 features a TFT display with a diagonal screen size of 7.5 inches and a color display capable of displaying 65,536 colors. The display has a resolution of 640 pixels horizontally and 480 pixels vertically. The backlighting has a Mean Time Between Failures (MTBF) of 50,000 hours at 25°C.
The device has a combination of Flash and RAM memory types. There is 6 Mbyte of memory available for user data, and the maximum capacity of main memory is 128 Mbyte. The device has an accumulator with a buffer battery that has a maximum buffer time of 10 minutes. It also has a hardware clock (real-time) that is retentive and synchronizable. The interfaces available on the device are 1x RS 422, 1x RS 485, and 1x Ethernet (RJ45) with a maximum data transfer rate of 12 Mbit/s.
The 6AV6645-0CC01-0AX0 SIMATIC Mobile Panel has one MMC/SD card slot for multimedia cards. It supports various protocols such as PROFIBUS, EtherNet/IP, and MODBUS, and has communication functions for headers. However, it does not support protocols for PROFIsafe or AS-Interface. The device does not have support for wireless communication standards such as WLAN 802.11. It has the necessary certificates of suitability including CE, cULus, C-TICK, and SIBE.
The panel module 6AV66450CC010AX0 can operate within an ambient temperature range of 0°C to 40°C, while its storage and transportation temperature range is between -20°C to 60°C. The maximum relative humidity for operation is 80%. This module comes with a pre-installed Windows CE operating system and has various features such as a message indicator, alarm system (with buffer and acknowledgment), and process value display (output). Additionally, it is possible to set the process value default (input) and manage recipes. To configure this module, you can use the WinCC flexible Standard Version 2005 SP1 or higher as a configuration tool.
The language capabilities of the system are divided into two categories: online languages and project languages. The system supports 16 online/runtime languages and up to 32 languages per project. The WinCC (TIA Portal) functionality also includes the use of libraries. In addition, there are several applications and options available such as Internet Explorer, Sm@rtService, and Sm@rtAccess.
The message system of the Siemens 6AV66450CC010AX0 panel has the following features. It supports 32 alarm classes and includes bit messages, with a maximum of 4,000 bit messages, and analog messages, with a maximum of 4,000 analog messages. The system also supports HMI system messages, PLC system messages, and system events such as SIMATIC S7, SINUMERIK, SIMOTION, and more. There is one line available with a maximum of 80 characters per message and up to 8 process values per message. The system also includes acknowledgment groups, with a maximum of 99 acknowledgment groups, and a message indicator. Additionally, it has a "first/last value" feature.
Check out the rest of our Siemens product line. Whether it's using our online instant quote feature, giving us a call at (800) 691-8511, or emailing us at sales@mroelectric.com, we strive for customer satisfaction first. This means lower prices and better service for you. For more products like 6AV6645-0CC01-0AX0, take a look at more from our HMIs line. If your current unit has gone bad, take advantage of our Core Exchange program for the most inexpensive route. You can learn more about this program on our FAQ page here. We offer a repair service on all of our 6AV6645-0CC01-0AX0 products that keep your downtime to a minimum. To stay up to date on manufacturer news, as well as access any of our datasheets, manuals, or other documentation, we suggest you take a look at our blog.
