6ES7132-6BF01-0BA0

2-year Warranty

Same Day Shipping

Siemens 6ES7132-6BF01-0BA0

SIMATIC DIGITAL OUTPUT MODULE, 0.5AMP, 8X24VDC, FITS TO BU-TYPE A0

Select Condition

Refurbished

Request Quote

New

4 in stock

$197.00

Request a formal quote

  • Ships Today
  • 2 Year Warranty
  • Free Shipping
Part Number6ES7132-6BF01-0BA0
ManufacturerSiemens
TypeI/O Modules
Model #6ES71326BF010BA0
Warranty2 Year
RangeSIMATIC
SIMATICET 200SP
CategoryDigital output
DesignationDQ 8x24VDC/0.5A ST
Functional statusFrom FS02
Base Unit BU type A0
DataI&M0 to I&M3
Color codeCC02
FirmwareV0.0
Supply voltage24 V
Range Supply voltage19.2 V…28.8 V
Max current consumption35 mA; without load
Rated output24 V DC
Power loss1 W
Outputs8 Digital
Switching frequency (resistive load)100 Hz
Current out 4A
Shielded cable length1,000 m
Width 15 mm
Height 73 mm
Depth 58 mm

Our Repair Services

MRO Electric repairs CNCs, PLCs, Servo/Spindle Drives, Motors, Amplifiers, VFDs, HMIs, and more, most of which can be repaired in only 3-5 days.

Repair Benefits

MRO can restore your failed 6ES7132-6BF01-0BA0 to remanufactured condition and save you up to 75% compared to buying new. We offer standard repair pricing to ensure you the best value for your repair.

Our certified technicians use rigorous testing procedures to ensure your parts are restored to fully functioning condition. Our team proudly stands behind all repairs by providing a minimum 2-year warranty.

Our technicians have vast experience with most manufacturers and models. In addition to this 6ES7132-6BF01-0BA0 we also repair a wide range of other Siemens products, so if you don’t see the model you need, please contact us.

Core Exchange

If you are interested in getting credit for your faulty 6ES7132-6BF01-0BA0, just let us know, and we can issue you an RMA to send it in as an exchange. Our exchange program provides you with savings and keeps us stocked for the next time you need anything.

  • Shipping Weight : 1lb

Want it shipped today?

  • Order within the next 5 hours and 10 minutes.
  • If you order between 4pm and 6pm EST, you will be charged a small rush fee.

Ask about exchanging your faulty 6ES7132-6BF01-0BA0 for credit when ordering from MRO Electric

MRO Electric provides a 2-year warranty on every item we sell and repair. We stand behind all of our products and guarantee them for the full 2 years. If there is an issue with any of our products within the warranty period, we will evaluate the unit and repair or replace it under warranty.

Siemens 6ES7132-6BF01-0BA0 Overview

Siemens 6ES71326BF010BA0 Digital Output Module

The Siemens 6ES71326BF010BA0 is a digital output module designed to provide reliable control of external devices in industrial automation systems. As part of the Siemens SIMATIC ET 200SP series, this module offers precise and efficient digital output functionality, making it a valuable component in a wide range of automation applications. With its compact design, 0.5-amp current capacity, and 8 outputs at 24VDC, the 6ES71326BF010BA0 enables seamless integration and precise control of external devices, contributing to the efficiency and performance of automation systems.

Highly Efficient Digital Output Control:

The 6ES71326BF010BA0 excels in providing digital output control, allowing automation systems to interact with various external devices such as solenoids, valves, motors, and lamps. With 8 outputs at 24VDC, the module offers flexibility in controlling multiple devices simultaneously, streamlining industrial processes, and optimizing productivity. Its ability to handle up to 0.5 amps of current enables efficient and reliable control of a wide range of output devices, making it suitable for both low-power and high-power applications.

Compatibility with BU-Type A0:

The 6ES71326BF010BA0 is designed to fit the BU-Type A0 base units, offering easy and secure installation within the automation system. The BU-Type A0 provides a platform for connecting various I/O modules, including the digital output module, allowing users to configure their automation systems based on their specific needs. The compatibility with BU-Type A0 enhances the modularity and scalability of the automation system, accommodating future expansions and adaptations.

Module Diagnostics for Enhanced Reliability:

Siemens has equipped the 6ES71326BF010BA0 with advanced module diagnostics to ensure enhanced reliability and system performance. The module diagnostics feature detects and monitors potential faults or anomalies, such as short circuits to L+ and ground, wire breaks, and supply voltage variations. These diagnostics help identify issues promptly, allowing for quick troubleshooting and minimizing downtime in the event of a fault. The module diagnostics feature ensures that the output module operates optimally and reliably, contributing to the overall efficiency of the automation system.

Color Code CC02 for Easy Identification:

The 6ES71326BF010BA0 comes with a color code CC02, providing a simple and effective means of identifying the module within the automation system. Color coding aids in quick and accurate identification, especially in setups with multiple modules and I/O devices. This feature streamlines installation, maintenance, and troubleshooting processes, saving valuable time and reducing the risk of errors during system maintenance.

Wide Range of Applications:

The 6ES71326BF010BA0's versatility allows it to be used in a wide range of industrial applications, making it a valuable asset in various automation systems. From controlling motorized devices in manufacturing processes to activating valves in water treatment systems, the module's digital output capabilities offer precise and efficient control in diverse applications. Its ability to handle different loads and respond to varying control signals ensures that the module meets the requirements of different industrial scenarios.

Seamless Integration with Siemens SIMATIC ET 200SP:

The 6ES71326BF010BA0 is part of the Siemens SIMATIC ET 200SP series, a renowned family of I/O systems designed to meet the demands of modern automation applications. The module seamlessly integrates with other components in the ET 200SP series, creating a cohesive and efficient automation system. The ET 200SP series' compact and space-saving design optimizes cabinet space and facilitates easy expansion and maintenance, enhancing the overall efficiency and reliability of the automation system.

Frequently Asked Questions (FAQ) for Siemens 6ES7132-6BF01-0BA0 I/O Module.

What type of module is the Siemens 6ES7132-6BF01-0BA0?

Answer: The Siemens 6ES7132-6BF01-0BA0 is a digital output I/O module designed for use within the SIMATIC ET 200SP range.

How many digital outputs does this module provide?

Answer: This module provides eight digital outputs, each rated for 24 V DC.

What is the maximum current output per channel?

Answer: The module allows a maximum current output of 4 A for all outputs combined.

What is the rated supply voltage for the Siemens 6ES7132-6BF01-0BA0?

Answer: This module's rated supply voltage is 24 V, with a permissible range from 19.2 V to 28.8 V.

What is the switching frequency of the outputs when driving a resistive load?

Answer: The switching frequency for a resistive load on the outputs is 100 Hz.

What is the power loss rating of the module?

Answer: The power loss for the Siemens 6ES7132-6BF01-0BA0 module is rated at 1 W.

What is this module's width, height, and depth?

Answer: The module's dimensions are 15 mm in width, 73 mm in height, and 58 mm in depth.

What is the functional status of the Siemens 6ES7132-6BF01-0BA0?

Answer: The functional status of this module is designated as FS02, indicating its version and capabilities.

How long can the shielded cable length be when connecting to the outputs?

Answer: The maximum length for the shielded cable when connecting to the outputs can be up to 1,000 meters.

What firmware version is the Siemens 6ES7132-6BF01-0BA0 currently using?

Answer: The module operates on firmware version V0.0, its initial release version.

Siemens products are manufactured in Germany and are designed for Automotive, aerospace, power generation, and electronics usage. They come with a 2-year warranty from MRO Electric. We also carry I/O Modules from other manufacturers such as FANUC and Yaskawa.
