6SN1118-0DJ23-0AA0

Siemens 6SN1118-0DJ23-0AA0 Overview

The 6SN1118-0DJ23-0AA0 is a single axis control module and part of the Simodrive 611 series. The SIMODRIVE 611 series is manufactured by Siemens.

Features

The Siemens 6SN1118-0DJ23-0AA0 1-axis drive control is a closed-loop control with a digital setpoint interface.  It is a high-performance control that can be loaded with either FD control or MSD control drive software. Both the FD control and the MSD control contain the same user interface.

The 6SN1118-0DJ23-0AA0 high-performance board comes in two versions. The first version is the basic version.  The basic version has sinusoidal voltage signals. This allows it to connect with absolute encoders with the EnDat interface.  The second version has the same features as above with additional features including the ability to evaluate a direct position measuring system. It uses sinusoidal voltage signals and a connection of absolute encoders that use the EnDat interface and an SSI interface.

The Siemens SIMODRIVE 611 control unit with a digital setpoint interface is available to work with several motors. These motors include 1 FT 6, 1 FT 7, 1 FK 7, 1 PH, 1 PM, 2 SP 1, and 1 FE 1 motors. These motors are used with the 2-axis version with high-Standard control with motor encoders and additional measuring system, voltage signals.

Advantages

Simodrive 611 universal control boards, such as this 6SN1118-0DJ23-0AA0, can be used in a variety of applications. They can be used in textile machines, machine tools, conveyor equipment, and many more systems. The system can also be made up of individual components and higher-level components to adapt to a variety of needs. The 6SN1118-0DJ23-0AA0 universal control board was manufactured for use with the SIMODRIVE power modules.

The Siemens 6SN1118-0DJ23-0AA0 is a part of the larger SIMODRIVE 611 Drive Converter system that encompasses many modules.  What are the components that comprise the drive converter system? The drive converter system has a transformer, switching and protective parts, a line filter, communicating reactors, infeed modules, power modules, and control units like the 6SN1118-0DJ23-0AA0 control board that is harmonized to the chosen application technology and or processes including the motor type. Additionally, the drive converter system uses special modules and accessories to enhance performance. The Siemens drive system also implements various cooling methods for the line supply in the feed as well as the drive modules as these are dependent on power sources. There are internal cooling units, external cooling units, and hose cooling units available for the Siemens SIMODRIVE 611 drive converter system.

How to use a 6SN1118-0DJ23-0AA0

This digital control plugs into one of the Simodrive power modules, such as a 6SN1123-1AA00-0CA1 or 6SN1123-1AA00-0EA1, which are sold separately. The Simodrive 611 series is a modular converter system with both operating and positioning modes. The control boards can also be expanded by terminal and Profibus-DP modules.

The Siemens SIMODRIVE 611 single-axis control module 6SN1118-0DJ23-0AA0 comes with a two-year warranty.

Product Description

The 6SN1118-0DJ23-0AA0 is a 1 AXIS CLOSED-LOOP CONTROL PLUG-IN that is manufactured by Siemens. These products are manufactured in Germany and are designed for Automotive, aerospace, power generation, and electronics usage. All of the products in the simodrive line come with a 2 year warranty from MRO Electric. We also carry AC Drives from other manufacturers such as FANUC and Yaskawa.
