ABE7H12R50

ABE7H12R50

Passive Connection Sub-Base Abe7 - 12 Inputs Or Outputs
Available - call for stock

2 year warranty

Categories

Part NumberABE7H12R50
ManufacturerSchneider Electric
SeriesModicon Communication
Weight1lb
TypeTelefast
Warranty2 year
Width4.92 in (125 mm)
Range of productAdvantys Telefast ABE7
Product or component typePassive discrete I/O sub-base
Sub-base typeI/O sub-base
[Us] rated supply voltage19...30 V conforming to IEC 61131-2
Number of channels12
Number of terminal per channel1
Supply circuit typeDC
Number of horizontal rows2
Status LED1 LED, green power ON
Polarity distributionNo
Short circuit protection6.3 A internal fuse, 5 x 20 mm, fast blow (PLC end)
Connector typeHE-10
Pin number20 pins
Fixing modeBy clips on 35 mm symmetrical DIN rail
By screws on solid plate with fixing kit
Supply current<= 6.1 A
Current per channel<= 0.5 A
Current per output common<= 6.1 A
Voltage drop on power supply fuse0.2 V
[Ui] rated insulation voltage2000 V
Installation categoryII conforming to IEC 60664-1
Tightening torque5.31 lbf.in (0.6 N.m) (with flat Ø 3.5 mm)

Our Repair Services

MRO Electric repairs CNCs, PLCs, Servo/Spindle Drives, Motors, Amplifiers, VFDs, HMIs, and more, most of which can be repaired in only 3-5 days.

Repair Benefits

MRO can restore your failed ABE7H12R50 to remanufactured condition and save you up to 75% compared to buying new. We offer standard repair pricing to ensure you the best value for your repair.

Our certified technicians use rigorous testing procedures to ensure your parts are restored to fully functioning condition. Our team proudly stands behind all repairs by providing a minimum 12-month warranty.

Our technicians have vast experience with most manufacturers and models. In addition to this ABE7H12R50 we also repair drives, motors, PLCs and more, so if you don’t see the model you need, please contact us.

Core Exchange

If you are interested in getting credit for your faulty ABE7H12R50, just let us know and we can issue you an RMA to send it in as an exchange. Our exchange program provides you with savings and keeps us stocked for the next time you need anything.

This product weighs 1lb. Want it shipped today?

  • Order within the next 13 hours and 33 minutes.
  • If you order between 4pm and 6pm EST, you will be charged a small rush fee.

Ask about exchanging your faulty ABE7H12R50 for credit when ordering from MRO Electric

Additional Information

Check out the rest of our Schneider Electric product line. Whether it's using our online instant quote feature, giving us a call, or sending us an email, we strive for customer satisfaction first. This means lower prices and better service for you. For more products like ABE7H12R50, take a look at more from our Modicon Communication line. If your current unit has gone bad, take advantage of our Core Exchange program for the most inexpensive route. We offer a repair service on all of our products that keep your downtime to a minimum. To stay up to date on manufacturer news, as well as access any of our datasheets, manuals, or other documentation, we suggest you take a look at our blog.
