ABS7SC3E

ABS7SC3E

PLug-In Solid State Relay - 12.5 Mm - Output - 5..48 V DC - 2 A
Available - call for stock

2 years warranty

Categories

ManufacturerSchneider Electric
SeriesModicon Communication
Voltage state1 guaranteed18.6 V DC
Range of productAdvantys Telefast ABE7
Product or component typePlug-in solid state relay
Relay typeOutput relay
Quantity per setSet of 4
Response time<= 0.1 ms from state 0 to 1
<= 0.6 ms from state 1 to 0
Width pitch dimension0.47 in (12 mm)
Product compatibilityABE7P16T330E
ABE7P16T334
ABE7R16T332
ABE7P16T318
ABE7R16T330
ABE7P16T318E
ABE7P16T330
Discrete input voltage24 V DC
Discrete output voltage5...48 V DC
Discrete output current1500 mA
Current state 0 guaranteed0.4 mA DC
Current state 1 guaranteed2.9 mA DC
Voltage state 0 guaranteed3.8 V DC
Our core exchange program offers you credit for your faulty items, please ask about getting an RMA to send your core in with for credit. You can also send in your unit to be repaired, our standard turnaround for repairs is 5-7 days, and all of our repaired items look like new, and come with a 1 year warranty.

This product weights 1lb. Want it shipped tomorrow?

  • Order within the next 20 hours and 3 minutes.
  • If you order between 4pm and 6pm EST, you will be charged a small rush fee.

What is the product warranty?

  • ABS7SC3E comes with a 2 year warranty
  • Ask about exchanging your faulty ABS7SC3E for credit when ordering from MRO Electric

Additional Information

Check out the rest of our Schneider Electric product line. Whether it's using our online instant quote feature, giving us a call, or sending us an email, we strive for customer satisfaction first. This means lower prices and better service for you. For more products like ABS7SC3E, take a look at more from our Modicon Communication line. If your current unit has gone bad, take advantage of our Core Exchange program for the most inexpensive route. We offer a repair service on all of our products that keep your downtime to a minimum. To stay up to date on on manufacturer news, as well as access any of our datasheets, manuals, or other documentation, we suggest you take a look at our blog.
