ATS48C48Y

2-year Warranty

Same Day Shipping

Schneider Electric ATS48C48Y

Rated 5/5 on 1 review

Rate this product


MANUFACTURER: Schneider Electric
DESCRIPTION: Soft starter for asynchronous motor 414 A - 208..690 V - 110..500 KW
PRODUCT TYPE INFO: Altistart


1 in stock

Ships Today


2 Year warranty

Part NumberATS48C48Y
ManufacturerSchneider Electric
TypeAC Motors
Warranty2 Year
RangeAltistart 48
CategoryATS48
DescriptionSoft starter
DestinationAsynchronous motors
Power dissipation in W1172 W for standard applications 1386 W for standard applications
Power supply voltage208...690 V - 15...10 %
ApplicationHeavy duty industry and pumps
AssemblyWith heat sink
Power supply voltage limits177…759 V
Device connectionIn the motor supply line
Max Horse Power Rating125 Hp 208 V for severe applications 150 Hp 208 V for standard applications 150 Hp 230 V for severe applications 300 Hp 460 V for severe applications 350 Hp 460 V for standard applications 350 Hp 575 V for severe applications 400 hp 575 V for standard applications
Icl nominal current480 A for connection in the motor supply line for severe applications 480 A connection in the motor supply line for standard applications
Frequency47.5...63 Hz
Current414 A
IP degree of protectionIP00
Discrete output number2
Discrete input number5
Control circuit consumption80 W
CommunicationModbus
Connector1 RJ45
MarkingCE
CoolingForced convection
Motor power kW110 KW 230 V for severe applications 132 KW 230 V for standard applications 220 KW 400 V for severe applications 220 KW 440 V for severe applications 250 KW 400 V for standard applications 250 KW 440 V for standard applications 250 KW 500 V for severe applications 250 KW 525 V for severe applications 315 KW 500 V for standard applications 315 KW 525 V for standard applications 355 KW 660 V for severe applications 400 KW 660 V for standard applications 400 KW 690 V for severe applications 500 kW 690 V for standard applications
Height26.38 in
Width15.75 in
Depth11.81 in

Our Repair Services

MRO Electric repairs CNCs, PLCs, Servo/Spindle Drives, Motors, Amplifiers, VFDs, HMIs, and more, most of which can be repaired in only 3-5 days.

Repair Benefits

MRO can restore your failed ATS48C48Y to remanufactured condition and save you up to 75% compared to buying new. We offer standard repair pricing to ensure you the best value for your repair.

Our certified technicians use rigorous testing procedures to ensure your parts are restored to fully functioning condition. Our team proudly stands behind all repairs by providing a minimum 2-year warranty.

Our technicians have vast experience with most manufacturers and models. In addition to this ATS48C48Y we also repair drives, motors, PLCs and more, so if you don’t see the model you need, please contact us.

Core Exchange

If you are interested in getting credit for your faulty ATS48C48Y, just let us know, and we can issue you an RMA to send it in as an exchange. Our exchange program provides you with savings and keeps us stocked for the next time you need anything.

  • Shipping Weight : 125lbs

Want it shipped today?

  • Order within the next 11 hours and 59 minutes.
  • If you order between 4pm and 6pm EST, you will be charged a small rush fee.

Ask about exchanging your faulty ATS48C48Y for credit when ordering from MRO Electric

MRO Electric provides a 2-year warranty on every item we sell and repair. We stand behind all of our products and guarantee them for the full 2 years. If there is an issue with any of our products within the warranty period, we will evaluate the unit and repair or replace it under warranty.

Schneider Electric ATS48C48Y Overview

Schneider Electric ATS48C48Y Soft Starter: Enhancing Motor Control

Introduction:

The Schneider Electric ATS48C48Y soft starter is engineered to provide precise control and reliable performance for asynchronous motors in heavy-duty industrial applications. Designed as part of the Altistart 48 range, this device offers comprehensive features and specifications to optimize motor control in diverse operating conditions.

Features and Specifications:

Featuring a wide range of capabilities, the ATS48C48Y soft starter is equipped to handle varying motor power and voltage requirements. With power supply voltage ranging from 208 to 690 V and motor power ranging from 110 KW to 500 KW, it caters to both severe and standard applications across different voltage levels. The device employs a start-with-torque control mechanism, limiting the current to 5 In for smooth and controlled motor start-ups. Furthermore, it offers protection against phase failure and thermal overload for both the motor and starter, ensuring safe operation in demanding industrial environments.

Applications:

The ATS48C48Y soft starter finds extensive applications in heavy-duty industries and pumping systems where precise motor control and protection are paramount. It is commonly utilized in industrial pumps, conveyor systems, fans and blowers, compressors, as well as mixers and agitators. Its versatility and reliability make it an indispensable component in various industrial settings, enhancing the efficiency and longevity of motor-driven systems.

Environment and Compliance:

Compliant with stringent standards and certifications, the ATS48C48Y soft starter ensures reliability and safety in industrial environments. It meets various electromagnetic compatibility standards and holds certifications such as UL, NOM, DNV, and SEPRO, among others. Additionally, it boasts resistance to vibrations, shocks, and environmental factors, making it suitable for operation in diverse conditions.

Schneider Electric ATS48C48Y Soft Starter: Enhancing Motor Control

Introduction:

The Schneider Electric ATS48C48Y soft starter is engineered to provide precise control and reliable performance for asynchronous motors in heavy-duty industrial applications. Designed as part of the Altistart 48 range, this device offers comprehensive features and specifications to optimize motor control in diverse operating conditions.

Features and Specifications:

Featuring a wide range of capabilities, the ATS48C48Y soft starter is equipped to handle varying motor power and voltage requirements. With power supply voltage ranging from 208 to 690 V and motor power ranging from 110 KW to 500 KW, it caters to both severe and standard applications across different voltage levels. The device employs a start-with-torque control mechanism, limiting the current to 5 In for smooth and controlled motor start-ups. Furthermore, it offers protection against phase failure and thermal overload for both the motor and starter, ensuring safe operation in demanding industrial environments.

Applications:

The ATS48C48Y soft starter finds extensive applications in heavy-duty industries and pumping systems where precise motor control and protection are paramount. It is commonly utilized in industrial pumps, conveyor systems, fans and blowers, compressors, as well as mixers and agitators. Its versatility and reliability make it an indispensable component in various industrial settings, enhancing the efficiency and longevity of motor-driven systems.

FAQ (Frequently Asked Questions):

What is the maximum power rating of the ATS48C48Y soft starter?

The ATS48C48Y soft starter can handle motor power ratings ranging from 110 KW to 500 KW, depending on the application requirements and voltage levels.

Does the ATS48C48Y soft starter offer protection against phase failure and thermal overload?

Yes, the ATS48C48Y soft starter is equipped with comprehensive protection mechanisms to safeguard both the motor and the starter against phase failure and thermal overload, ensuring safe operation in demanding industrial environments.

What applications is the ATS48C48Y soft starter commonly used for?

The ATS48C48Y soft starter is commonly used in heavy-duty industries and pumping systems, including industrial pumps, conveyor systems, fans and blowers, compressors, as well as mixers and agitators, where precise motor control and protection are essential.

Schneider Electric products are manufactured in France and are designed for Material handling, packaging, and textile machines usage. They come with a 2-year warranty from MRO Electric. We also carry AC Motors from other manufacturers such as Modicon and ABB.
