ATV12H075F1

2-year Warranty

Same Day Shipping

Schneider Electric ATV12H075F1

Rated 4/5 on 1 review

Rate this product


MANUFACTURER: Schneider Electric
DESCRIPTION: Variable speed drive - 0.75kW - 1hp - 100..120V - 1ph - with heat sink
PRODUCT TYPE INFO: Altivar 12


5 in stock


Free Shipping

2 Year warranty

Part NumberATV12H075F1
ManufacturerSchneider Electric
TypeAC Drives
Warranty2 Year
RangeATV12
ComponentVariable speed drive
ApplicationSimple machine
ProtocolModbus
EMC filterWithout EMC filter
MountingCabinet mount
Supply frequency50/60 Hz +/- 5 %
Motor power1 hp
Supply voltage100...120 V - 15...10 %
ProtectionIP20
Motor power0.75 kW 1 hp
Discrete input number4
Discrete output number2
Connector1 RJ45
Analog1 in/ 1 out
Speed range1…20
Frequency resolutionAnalog input: converter A/D, 10 bits
Interface2-wire RS 485
AccessServer Modbus serial
Nominal output current4.2 A

Our Repair Services

MRO Electric repairs CNCs, PLCs, Servo/Spindle Drives, Motors, Amplifiers, VFDs, HMIs, and more, most of which can be repaired in only 3-5 days.

Repair Benefits

MRO can restore your failed ATV12H075F1 to remanufactured condition and save you up to 75% compared to buying new. We offer standard repair pricing to ensure you the best value for your repair.

Our certified technicians use rigorous testing procedures to ensure your parts are restored to fully functioning condition. Our team proudly stands behind all repairs by providing a minimum 2-year warranty.

Our technicians have vast experience with most manufacturers and models. In addition to this ATV12H075F1 we also repair drives, motors, PLCs and more, so if you don’t see the model you need, please contact us.

Core Exchange

If you are interested in getting credit for your faulty ATV12H075F1, just let us know, and we can issue you an RMA to send it in as an exchange. Our exchange program provides you with savings and keeps us stocked for the next time you need anything.

  • Shipping Weight : 1lb

Want it shipped tomorrow?

  • Order within the next 32 minutes.
  • If you order between 4pm and 6pm EST, you will be charged a small rush fee.

Ask about exchanging your faulty ATV12H075F1 for credit when ordering from MRO Electric

MRO Electric provides a 2-year warranty on every item we sell and repair. We stand behind all of our products and guarantee them for the full 2 years. If there is an issue with any of our products within the warranty period, we will evaluate the unit and repair or replace it under warranty.

Schneider Electric ATV12H075F1 Overview

Schneider Electric products are manufactured in France and are designed for Material handling, packaging, and textile machines usage. They come with a 2-year warranty from MRO Electric. We also carry AC Drives from other manufacturers such as Modicon and ABB.

Schneider Electric ATV12H075F1 VSD

The ATV12H075F1 is a variable-speed drive designed by Schneider Electric under the Altivar 12 product range. This drive is a crucial component in industrial automation systems, specifically catering to simple machine applications. It offers precise control and efficient performance, making it an ideal choice for various industrial processes.

Features

As a variable-speed drive, the ATV12H075F1 allows users to regulate the speed of the connected motor, enabling flexible and energy-efficient operation. It is suitable for single-phase power supply systems with a rated voltage of 100 to 120 V, providing a nominal output current of 4.2 A. The motor power is rated at 0.75 kW (equivalent to 1 horsepower), making it suitable for moderate power applications.

The drive features four discrete inputs, two discrete outputs, one analog input, one analog output, and one relay output, facilitating diverse communication and control options. For communication purposes, it utilizes the Modbus protocol and supports a 2-wire RS 485 physical interface with an RJ45 connector for easy connectivity.

The speed drive output frequency ranges from 0.5 to 400 Hz, allowing users to achieve precise speed control in a wide range of applications. The sampling duration for logic input is 20 ms with a tolerance of +/- 1 ms, and for the analog input, it is 10 ms. The drive provides a display unit with a resolution of 0.1 Hz for easy monitoring and control of motor speed.

Control

For motor control, the ATV12H075F1 offers various methods, including voltage/frequency ratio (V/f), quadratic voltage/frequency ratio, and sensorless flux vector control. It also supports 4-quadrant operation, allowing bidirectional control for applications such as regenerative braking.

Safety

To ensure the safety of the system, the drive is equipped with several protection features. These include protection against line supply overvoltage and undervoltage, overcurrent between output phases and earth, overheating protection, short-circuit between motor phases, and input phase loss in three-phase systems.

Function

The ATV12H075F1 comes with a built-in braking function using DC injection, ensuring smooth and controlled deceleration of the motor. However, it does not have an integrated brake chopper.

The drive offers adjustable acceleration and deceleration ramps, allowing users to customize the motor's response to start and stop commands. It supports motor slip compensation, preset in the factory but adjustable as needed.

Design

The ATV12H075F1 is designed for ease of installation and operation. It features a width of 105 mm, height of 142 mm, and depth of 156.2 mm, with a net weight of 1.3 kg. The drive is IP20 rated, indicating protection against solid objects larger than 12.5 mm and no protection against water.

For environmental considerations, the drive operates efficiently in temperatures ranging from -10 to 50 °C without derating. At higher temperatures up to 60 °C, a derating factor of 2.2% per °C is applied. The drive is designed for relative symmetric network frequency tolerance of 5% and operates well in environments with pollution degree 2.

The ATV12H075F1 conforms to several product certifications and standards, including NOM, CSA, C-Tick, UL, GOST, RCM, and KC. It complies with various international regulations such as UL 508C, UL 618000-5-1, EN/IEC 61800-5-1, and EN/IEC 61800-3.

In summary, the ATV12H075F1 variable speed drive is a reliable and efficient solution for simple machine applications. With its versatile features, precise control, and safety protections, it enhances the performance of industrial processes and contributes to energy savings. Its compact design and user-friendly interface make it a valuable component for automation systems in various industries.
