ATV16U09M2

ATV16U09M2

Rated 5/5 on 1 review

Rate this product


MANUFACTURER: Schneider Electric
DESCRIPTION: VARIABLE SPEED DRIVE, Speed controller for asynchronous motors
PRODUCT TYPE INFO: Altivar 16


Available

Free Shipping
2 Year warranty
Part NumberATV16U09M2
ManufacturerSchneider Electric
Model #ATV16U09M2
TypeDrives
Warranty2 Year

Our Repair Services

MRO Electric repairs CNCs, PLCs, Servo/Spindle Drives, Motors, Amplifiers, VFDs, HMIs, and more, most of which can be repaired in only 3-5 days.

Repair Benefits

MRO can restore your failed ATV16U09M2 to remanufactured condition and save you up to 75% compared to buying new. We offer standard repair pricing to ensure you the best value for your repair.

Our certified technicians use rigorous testing procedures to ensure your parts are restored to fully functioning condition. Our team proudly stands behind all repairs by providing a minimum 2 year warranty.

Our technicians have vast experience with most manufacturers and models. In addition to this ATV16U09M2 we also repair drives, motors, PLCs and more, so if you don’t see the model you need, please contact us.

Core Exchange

If you are interested in getting credit for your faulty ATV16U09M2 , just let us know and we can issue you an RMA to send it in as an exchange. Our exchange program provides you with savings and keeps us stocked for the next time you need anything.

  • Shipping Weight : 5lbs

Want it shipped tomorrow?

  • Order within the next 21 hours and 21 minutes.
  • If you order between 4pm and 6pm EST, you will be charged a small rush fee.

Ask about exchanging your faulty ATV16U09M2 for credit when ordering from MRO Electric

MRO Electric provides a 2-year warranty on every item we sell and repair. We stand behind all of our products and guarantee them for the full 2 years. If there is an issue with any of our products within the warranty period, we will evaluate the unit and repair or replace it under warranty.

Additional Information

Schneider Electric ATV16U09M2 Overview

The Schneider Electric ATV16U09M2 drive is a Telemecanique product and part of the Altivar 16 AC drive collection accessible for world-wide use. This module accomplishes three-phase asynchronous squirrel-cage motor needs. Intelligent power modules and application-specific integrated circuits are two of the technology points integrated into this drive. It also has a 16-bit microprocessor, a technology that allows for the transfer of 16-bits of data at a time.

Features

It features standard surface mount technology. Constructed precisely for space-saving with its compact size and with global international standards in mind to help meet the needs of various applications.  The Altivar 16 comes with preset settings straight from the factory. These settings administer the necessary transient over-torque for starting. They also maximize available torque at low speeds which requires no adjustment. When torque capacity is reached, amp times will be automatically adjusted for acceleration and deceleration.  One beneficial consideration is the reduction of motor noise. The switching frequency is 5 kHz (or 10 kHz for certain applications) which allows for decreased sound irritation.  The motor noise is limited by the switching frequency being randomly modulated and that means reducing losses in the drive. To restrict radiofrequency emissions from interfering with or technologies, the use of RFI filters is enforced. Included in the RFI filter kit are output and input filter modules.  Inductors are used and allow the drive to run when outfitted with lines with low resistance and lines that get input interference.

The Altivar 16 carries NEMA 1, IP30 protection (IP30 without the top plate mounted) with UL, CSA, IEC, VDE, and CE standards.  Maximum relative humidity should be held at 93% non-condensing without dripping. Storage temperature is -13 to +158 °F (-25 to + 70°C). Operation optimal at a maximum altitude of 3300 ft (1000 m) without derating and derating by 3% for each additional 3300 ft (1000 m). It has a reference response time of 5 to 10 minutes.

How to use the Schneider Electric ATV16U09M2

There are times when inductor use between drive and motor is suggested. Two of these are when there is a long connection between drive and motor and the other is when several motors are running parallel.  You have rotation direction command and acceleration and deceleration ramps factory set to 3 seconds, individually adjustable from 0.1 seconds to 600 seconds with option.  These ramps automatically adjust in case of over-torque. The low speed is factory set at 0 and the factory high speed setting is50/60 Hz. Constant torque applications work with factory settings. It has automatic slip compensation.  The display on the drive consists of 2 LEDs on the front: red LED will indicate there is a fault while a green LED will indicate the drive supply is on.

Advantages

You can trust this drive with easy to adjust factory settings that is work with your industrial setting and enables noise reduction measures, dynamic braking and configures to your specific needs.

The Schneider Electric ATV16U09M2 also comes with a two-year warranty.

Product Description

The ATV16U09M2 is a VARIABLE SPEED DRIVE, Speed controller for asynch... that is manufactured by Schneider Electric. These products are manufactured in France and are designed for Material handling, packaging, and textile machines usage. All of the products come with a 2 year warranty from MRO Electric. We also carry Drives from other manufacturers such as Modicon and ABB.

Related Products

Check out the rest of our Schneider Electric product line. Whether it's using our online instant quote feature, giving us a call at (800) 691-8511, or sending us an email at sales@mroelectric.com, we strive for customer satisfaction first. This means lower prices and better service for you. For more products like ATV16U09M2 , take a look at more from our Drives line. If your current unit has gone bad, take advantage of our Core Exchange program for the most inexpensive route. You can learn more about this program on our FAQ page here. We offer a repair service on all of our ATV16U09M2 products that keep your downtime to a minimum. To stay up to date on manufacturer news, as well as access any of our datasheets, manuals, or other documentation, we suggest you take a look at our blog.
