MANUFACTURER: Schneider Electric
DESCRIPTION: Variable speed drive, 5.5kW - 500V 3-phase supply - EMC filter - IP20
PRODUCT TYPE INFO: Altivar 31
|Category||Variable speed drive|
|Assembly||with heat sink|
|Protection||On upper part: IP20 (without cover plate)|
|On connection terminals: IP21|
|On upper part: IP31|
|On upper part: IP41|
|Supply voltage||380...500 V - 5...5 %|
|Power rating||5.5 kW 4 kHz|
|Motor power||7.5 hp 4 kHz|
|Supply frequency||50...60 Hz - 5...5 %|
|Line current||16.5 A at 500 V 21.9 A at 380 V, Isc = 1 kA|
|Nominal output current||14.3 A 4 kHz|
|Apparent power||15 kVA|
|Power dissipation in W||232 W at nominal load|
|Prospective line Isc||1 kA|
|Analog in/out||3 in/2 out|
|Regulation loop||Frequency PI regulator|
|Discrete in/out||6 in/2 out|
MRO Electric repairs CNCs, PLCs, Servo/Spindle Drives, Motors, Amplifiers, VFDs, HMIs, and more, most of which can be repaired in only 3-5 days.
MRO can restore your failed ATV31HU55N4 to remanufactured condition and save you up to 75% compared to buying new. We offer standard repair pricing to ensure you the best value for your repair.
Our certified technicians use rigorous testing procedures to ensure your parts are restored to fully functioning condition. Our team proudly stands behind all repairs by providing a minimum 2-year warranty.
Our technicians have vast experience with most manufacturers and models. In addition to this ATV31HU55N4 we also repair drives, motors, PLCs and more, so if you don’t see the model you need, please contact us.
If you are interested in getting credit for your faulty ATV31HU55N4, just let us know, and we can issue you an RMA to send it in as an exchange. Our exchange program provides you with savings and keeps us stocked for the next time you need anything.
Want it shipped today?
Ask about exchanging your faulty ATV31HU55N4 for credit when ordering from MRO Electric
Schneider Electric products are manufactured in France and are designed for Material handling, packaging, and textile machines usage. They come with a 2-year warranty from MRO Electric. We also carry AC Drives from other manufacturers such as Modicon and ABB.
The ATV31HU55N4, a remarkable variable speed drive from the Altivar series, is a sophisticated and versatile component designed to optimize the performance of simple machines across a wide range of industrial applications. With its compact assembly style, integrated EMC filter, and robust IP20 protection rating, this drive unit represents a pinnacle of engineering innovation.
Central to its capabilities is its adaptability to a 3-phase supply network, with a rated voltage spanning from 380 to 500 volts, encompassing a 5.5 kW power range. Its ability to function seamlessly within a frequency range of 50 to 60 Hz further solidifies its versatility. This makes the ATV31HU55N4 ideal for applications requiring precision control, such as in modern manufacturing and automation processes.
One of the key highlights of the ATV31HU55N4 is its advanced control over asynchronous motors. Factory-set for constant torque, the drive employs sensorless flux vector control with PWM-type motor control signals. Its three analog input channels enable precise motor control and regulation.
Designed to cater to both simple machines and more complex systems, the ATV31HU55N4 is equipped with an integrated EMC filter, which plays a pivotal role in reducing electromagnetic interference and ensuring optimal performance. This feature is particularly vital in environments where precision and stability are paramount.
Operating within a three-phase network, the ATV31HU55N4 exhibits a line current of 16.5 A at 500 V and 21.9 A at 380 V. Its nominal output current is 14.3 A at 4 kHz, with a maximum transient current of 21.5 A for 60 seconds. The drive showcases an impressive peak power dissipation of 232 W at nominal load, a testament to its efficient energy management capabilities.
The Schneider Electric ATV31HU55N4 drive unit offers a plethora of adjustable parameters. Its regulation loop employs a Frequency PI regulator, ensuring smooth and consistent motor performance. Furthermore, the ATV31HU55N4 allows for motor slip compensation, which is automatically adjusted based on the load, ensuring efficient operation regardless of the workload.
In terms of environmental robustness, the ATV31HU55N4 is built to withstand a spectrum of conditions. With a dielectric strength of 2410 V DC between earth and power terminals and 3400 V AC between control and power terminals, it offers reliable protection against electrical disturbances. Its vibration resistance, shock resistance, and wide operating temperature range further underscore its durability and suitability for demanding industrial environments.
For utmost convenience, the ATV31HU55N4 incorporates a user-friendly display featuring LED indicators for drive voltage and four 7-segment displays for CANopen bus status. This intuitive interface enhances the monitoring and management of the drive's performance.
Connectivity is a hallmark of the ATV31HU55N4. It offers a range of physical interfaces, including an RJ45 connector for CANopen via the VW3 CANTAP2 adaptor and another RJ45 for Modbus communication. This enables seamless integration into industrial networks and systems, facilitating real-time data exchange and remote management.
In conclusion, the ATV31HU55N4 variable speed drive is a true testament to engineering excellence. With precise control, robust design, and advanced features, the ATV31HU55N4 optimizes processes, enhances efficiency, and ensures consistent and reliable performance. Whether it's simple machine operations or more intricate industrial applications, the ATV31HU55N4 stands ready to meet the demands of modern automation and drive technology.
Check out the rest of our Schneider Electric product line. Whether it's using our online instant quote feature, giving us a call at (800) 691-8511, or emailing us at firstname.lastname@example.org, we strive for customer satisfaction first. This means lower prices and better service for you. For more products like ATV31HU55N4, take a look at more from our AC Drives line. If your current unit has gone bad, take advantage of our Core Exchange program for the most inexpensive route. You can learn more about this program on our FAQ page here. We offer a repair service on all of our ATV31HU55N4 products that keep your downtime to a minimum. To stay up to date on manufacturer news, as well as access any of our datasheets, manuals, or other documentation, we suggest you take a look at our blog.
