ATV610D30N4

2-year Warranty

Same Day Shipping

Schneider Electric ATV610D30N4

Variable speed drive, Easy Altivar 610, 30kW, 40hp, 380 to 460V, IP20

Select Condition

Refurbished

Request Quote

New

1 in stock

$2,379.00

Request a Quote
  • Ships Today
  • 2 Year Warranty
  • Free Shipping
Part NumberATV610D30N4
ManufacturerSchneider Electric
TypeAC Drives
Warranty2 Year

Our Repair Services

MRO Electric repairs CNCs, PLCs, Servo/Spindle Drives, Motors, Amplifiers, VFDs, HMIs, and more, most of which can be repaired in only 3-5 days.

Repair Benefits

MRO can restore your failed ATV610D30N4 to remanufactured condition and save you up to 75% compared to buying new. We offer standard repair pricing to ensure you the best value for your repair.

Our certified technicians use rigorous testing procedures to ensure your parts are restored to fully functioning condition. Our team proudly stands behind all repairs by providing a minimum 2-year warranty.

Our technicians have vast experience with most manufacturers and models. In addition to this ATV610D30N4 we also repair drives, motors, PLCs and more, so if you don’t see the model you need, please contact us.

Core Exchange

If you are interested in getting credit for your faulty ATV610D30N4, just let us know, and we can issue you an RMA to send it in as an exchange. Our exchange program provides you with savings and keeps us stocked for the next time you need anything.

  • Shipping Weight : 1lb

Want it shipped tomorrow?

  • Order within the next 18 hours and 21 minutes.
  • If you order between 4pm and 6pm EST, you will be charged a small rush fee.

Ask about exchanging your faulty ATV610D30N4 for credit when ordering from MRO Electric

MRO Electric provides a 2-year warranty on every item we sell and repair. We stand behind all of our products and guarantee them for the full 2 years. If there is an issue with any of our products within the warranty period, we will evaluate the unit and repair or replace it under warranty.

Schneider Electric ATV610D30N4 Overview

Schneider Electric ATV610D30N4 Variable Speed Drive: Efficient Power Control for Industrial Systems

The Schneider Electric ATV610D30N4 is a powerful, cost-effective variable speed drive from the Easy Altivar 610 range, offering a reliable solution for industrial motor control applications. Designed for asynchronous and synchronous motors, the ATV610 delivers optimal performance for fans, pumps, compressors, and conveyors. With a power rating of 30kW (40 HP) for regular duty and 22kW (30 HP) for heavy duty, it operates on a 380 to 460V three-phase power supply and supports a wide output frequency range of 0.1 to 500 Hz. Its IP20-rated enclosure makes it suitable for cabinet mounting in controlled industrial environments.

Built for Industrial Demands

The ATV610D30N4 is engineered to thrive in rigorous operational conditions, offering stable performance in ambient temperatures up to 45°C without derating and up to 60°C with derating. It withstands dust, humidity, and vibration and conforms to international standards for shock and electromagnetic compatibility. The integrated EMC filter complies with IEC 61800-3 category C3, supporting cable lengths up to 50 meters. The unit also features forced convection cooling and operates vertically within a ±10° range.

Advanced Performance and Motor Protection

This drive incorporates many protection features to ensure safe and efficient motor operation. It includes thermal protection for both the drive and the motor, overcurrent, short-circuit protection, overspeed alerts, and undervoltage and overvoltage safeguards. Additionally, the unit can compensate for motor slip and includes adjustable acceleration and deceleration ramps that can be linear, S-curve, or user-defined. The braking function utilizes DC injection to ensure safe and quick stops.

Extensive I/O and Communication Capabilities

Connectivity and control flexibility are highlights of the ATV610. It offers six discrete inputs, three analog inputs, and two analog outputs, all software-configurable for voltage or current signals and compatible with temperature or water level sensors. It supports communication via Modbus serial protocol over a 2-wire RS 485 physical interface with baud rates from 4.8 to 38.4 kbit/s. Slot A can accommodate expansion cards, including Profibus DP V1, additional I/O, and relay output cards for enhanced functionality. The drive can be accessed and configured using a remote graphic terminal through an RJ45 connector.

Compact Design and Reliable Operation

The ATV610D30N4 is compact for its output class, measuring 226 mm in width, 613 mm in height (706 mm with EMC plate), and 271 mm in depth. Its net weight of 25.5 kg makes it easily integrated into control panels. It ensures smooth operation even in high altitudes (up to 4800 meters with derating) and offers a reliable solution with a 2-year warranty from MRO Electric and Supply. Its robust design and intelligent functionality make it a dependable choice for medium-power industrial motor applications.

Frequently Asked Questions (FAQ)

What motors are compatible with the ATV610D30N4?

It supports both asynchronous and synchronous motors.

What is the rated power output of the drive?

It delivers 30kW (40 HP) for normal duty and 22kW (30 HP) for heavy duty.

Is the ATV610D30N4 suitable for high-temperature environments?

Yes, it operates up to 45°C without derating and up to 60°C with derating.

What is the enclosure rating?

The drive has an IP20 enclosure, suitable for cabinet mounting.

Can this drive control pumps and fans?

It is optimized for applications like pumps, fans, compressors, and conveyors.

What communication protocols are supported?

It natively supports Modbus serial and can be expanded to Profibus DP V1 with an optional card.

What kind of I/O does the drive have?

It includes six discrete inputs, three analog inputs, and two analog outputs, all software-configurable.

How does the drive handle braking?

Braking is achieved using DC injection to bring motors to a controlled stop.

Is there protection against electrical faults?

The ATV610 includes thermal, overcurrent, short-circuit, and undervoltage/overvoltage protection.

What warranty comes with the drive?

It comes with a 2-year warranty from MRO Electric and Supply.
