BMXCPS2010

2-year Warranty

Same Day Shipping

Schneider Electric BMXCPS2010

POWER SUPPLIES STANDARD ISOLATED DC POWER SUPPLY

4/5
1 rating

Select Condition

Refurbished

Request Quote

New

4 in stock

$349.00

Request a formal quote

  • Ships Today
  • 2 Year Warranty
  • Free Shipping
Part NumberBMXCPS2010
ManufacturerSchneider Electric
TypePower Supplies
Model #BMX-CPS-2010
Warranty2 Year
RangeModicon X80
ComponentPower supply module
Circuit typeDC
Max voltage18...31.2 V
Voltage24 V isolated
Power (secondary)16.8 W 24 V DC I/O module power supply and processor 8.3 W 3.3 V DC I/O module logic power supply
Input current1 A 24 V
MTBF reliability4886000 H
Status LED1 LED (green) rack voltage OK
Inrush current30 A 24 V
Control typeRESET push-button cold restart
Protection typeInternal fuse not accessible for primary circuit Overload protection for secondary circuit, 24 V sensor power supply Overvoltage protection for secondary circuit, 24 V sensor power supply Short-circuit protection for secondary circuit, 24 V sensor power supply
Maximum cable distance between devices20 m power supply cable copper 1.5 mm² 30 m power supply cable copper 2.5 mm²
Insulation resistance>= 10 MOhm primary/ground
>= 10 MOhm primary/secondary
Maximum power dissipation8.5 W
Dielectric strength1500 V primary/ground 1500 V primary/secondary
IP degree of protectionIP20
Vibration resistance3 gn
Shock resistance30 gn
Ambient temp (operation)0…60 °C
Ambient temp (storage)-40…85 °C
Operating altitude0...2000 m 2000...5000 m with derating factor
Relative humidity5…95 % at 55 °C without condensation

Our Repair Services

MRO Electric repairs CNCs, PLCs, Servo/Spindle Drives, Motors, Amplifiers, VFDs, HMIs, and more, most of which can be repaired in only 3-5 days.

Repair Benefits

MRO can restore your failed BMXCPS2010 to remanufactured condition and save you up to 75% compared to buying new. We offer standard repair pricing to ensure you the best value for your repair.

Our certified technicians use rigorous testing procedures to ensure your parts are restored to fully functioning condition. Our team proudly stands behind all repairs by providing a minimum 2-year warranty.

Our technicians have vast experience with most manufacturers and models. In addition to this BMXCPS2010 we also repair drives, motors, PLCs and more, so if you don’t see the model you need, please contact us.

Core Exchange

If you are interested in getting credit for your faulty BMXCPS2010, just let us know, and we can issue you an RMA to send it in as an exchange. Our exchange program provides you with savings and keeps us stocked for the next time you need anything.

  • Shipping Weight : 1lb

Want it shipped today?

  • Order within the next 1 hour and 1 minute.
  • If you order between 4pm and 6pm EST, you will be charged a small rush fee.

Ask about exchanging your faulty BMXCPS2010 for credit when ordering from MRO Electric

MRO Electric provides a 2-year warranty on every item we sell and repair. We stand behind all of our products and guarantee them for the full 2 years. If there is an issue with any of our products within the warranty period, we will evaluate the unit and repair or replace it under warranty.

Schneider Electric BMXCPS2010 Overview

Schneider Electric BMXCPS2010 Power Supply Module

The Schneider Electric BMXCPS2010 power supply module is a critical component in the Modicon X80 range, designed to provide reliable and efficient power to various industrial control systems. This power supply unit is essential for maintaining a stable electrical environment in automation and control processes, ensuring the proper functioning of input/output modules, processors, and related components. The BMXCPS2010 is backed by a 2-year warranty from MRO Electric and Supply, and it includes free shipping, making it a dependable and convenient choice for your power supply needs.

Power Supply and Voltage Range

The BMXCPS2010 operates within a wide voltage range, handling 18 and 31.2 volts of direct current (DC) with a nominal voltage of 24 V DC. This wide voltage tolerance makes it adaptable to varying industrial environments, ensuring consistent performance even in fluctuating power conditions. The power supply module offers two key output configurations: 16.8 W at 24 V DC for I/O module power supply and processor power and 8.3 W at 3.3 V DC for I/O module logic power supply. This efficient dual-output design allows it to supply power to logic and control elements within a system, making it versatile in complex industrial settings.

Inrush and Input Current

The power supply is designed to handle an inrush current of up to 30 A at 24 V, crucial for managing initial power surges when the system starts up. Its input current is 1 A at 24 V, ensuring a steady and stable power supply during operation. These characteristics contribute to its durability and resilience, making it ideal for environments where sudden power demands can occur.

Protection and Reliability Features

The Schneider Electric BMXCPS2010 has multiple protection features to ensure long-term reliability and safety. It includes an inaccessible internal fuse for the primary circuit, which prevents circuit damage during power surges. The module also has overload, overvoltage, and short-circuit protection for the secondary circuit, specifically for the 24 V sensor power supply. These protections prevent damage to connected components and ensure longevity, particularly in demanding industrial environments.

The module also features a RESET push button, which allows cold restarts and provides a convenient and easy way to reset the system when necessary. Additionally, the unit has a green status LED that indicates when the rack voltage is operational, simplifying diagnostics and troubleshooting.

Durability and Environmental Specifications

With an IP20 rating, the BMXCPS2010 is designed for indoor use and offers protection against solid objects larger than 12.5 mm, ensuring its durability in controlled environments. It is engineered to withstand vibrations of up to 3 gn and shocks of up to 30 gn, making it resilient to the mechanical stresses often encountered in industrial settings.

The BMXCPS2010 operates efficiently in ambient temperatures ranging from 0°C to 60°C, while it can be stored in environments as cold as -40°C and as hot as 85°C. Its robust design allows it to function at altitudes of up to 2000 meters and even between 2000 and 5000 meters with a derating factor applied. Additionally, it can handle relative humidity levels between 5% and 95% at 55°C without condensation, further enhancing its versatility in various climates and conditions.

Electrical Insulation and Safety

The module provides high levels of electrical insulation with a resistance of 10 MOhm between primary/ground and primary/secondary circuits, ensuring that electrical noise and interference are minimized. It also features a dielectric strength of 1500 V between the primary/ground and primary/secondary circuits, adding an extra layer of safety for both the equipment and operators.

FAQs for Schneider Electric BMXCPS2010 Power Supply Module

What is the voltage range for the Schneider Electric BMXCPS2010?

The Schneider Electric BMXCPS2010 operates within a voltage range of 18 to 31.2 V DC, with a nominal voltage of 24 V DC. This wide voltage range ensures the module’s adaptability to different power conditions and system requirements.

What type of protection does the BMXCPS2010 offer?

The BMXCPS2010 is equipped with multiple protection features, including:

Internal fuse protection (not accessible) for the primary circuit.

Overload protection for the secondary circuit (24 V sensor power supply).

Overvoltage protection for the secondary circuit.

Short-circuit protection for the secondary circuit.

These features ensure reliable and safe operation, preventing damage to the power supply module and connected components.

What is the output power of the BMXCPS2010?

The module provides two main output power ratings:

16.8 W for the 24 V DC I/O module power supply and processor.

8.3 W for the 3.3 V DC I/O module logic power supply.

This dual-output configuration allows it to power logic and control systems in various industrial settings.

Does the BMXCPS2010 have any status indicators?

Yes, the BMXCPS2010 includes a green LED indicator that displays the status of the rack voltage. If the voltage is operational, the LED will remain on, visually indicating proper function.

What is the inrush current for the BMXCPS2010?

The BMXCPS2010's inrush current is 30 A at 24 V, which ensures the module can handle power surges during startup without any issues.

What is the insulation resistance of the BMXCPS2010?

The BMXCPS2010 offers insulation resistance of 10 MOhm between primary/ground and primary/secondary circuits, which ensures the system remains safe and protected from electrical interference or faults.

What are the environmental operating conditions for the BMXCPS2010?

The power supply operates efficiently in ambient temperatures ranging from 0°C to 60°C and can be stored in temperatures as extreme as -40°C to 85°C. It also performs reliably at altitudes of up to 2000 meters and up to 5000 meters with a derating factor applied. Additionally, the module can function in environments with 5% to 95% relative humidity without condensation.

Is the BMXCPS2010 suitable for industrial environments?

Yes, the BMXCPS2010 is highly durable and designed for industrial use. It is resistant to vibrations up to 3 gn and shocks up to 30 gn. With an IP20 protection rating, it is suitable for indoor environments, making it ideal for industrial control systems.

What are the dimensions of the BMXCPS2010?

The BMXCPS2010's physical dimensions allow it to fit easily into most rack systems, and it can be integrated with a wide range of devices and modules within the Modicon X80 system.

What warranty is provided for the BMXCPS2010?

The Schneider Electric BMXCPS2010 comes with a 2-year warranty from MRO Electric and Supply. Additionally, free shipping is provided, ensuring you receive a reliable product with comprehensive customer support.

Schneider Electric products are manufactured in France and are designed for Material handling, packaging, and textile machines usage. They come with a 2-year warranty from MRO Electric. We also carry Power Supplies from other manufacturers such as Modicon and ABB.

Contact Us Today For More Information About Schneider Electric Products

Check out the rest of our Schneider Electric product line. Whether it's using our online instant quote feature, giving us a call at (800) 691-8511, or emailing us at sales@mroelectric.com, we strive for customer satisfaction first. This means lower prices and better service for you. For more products like BMXCPS2010, take a look at more from our Power Supplies line. If your current unit has gone bad, take advantage of our Core Exchange program for the most inexpensive route. You can learn more about this program on our FAQ page here. We offer a repair service on all of our BMXCPS2010 products that keep your downtime to a minimum. To stay up to date on manufacturer news, as well as access any of our datasheets, manuals, or other documentation, we suggest you take a look at our blog.
