CIMR-VU2A0006FAA

2-year Warranty

Same Day Shipping

Yaskawa CIMR-VU2A0006FAA

V1000 DRIVES DRIVE, AC, 3/4HP, 240V, 3PH, 5A, CT, N1 1HP, 6A
4.5/5
2 ratings

11 in stock


Free Shipping

2 Year warranty

Part NumberCIMR-VU2A0006FAA
ManufacturerYaskawa
TypeAC Drives
Model #CIMRVU2A0006FAA
Warranty2 Year
Power supply200-240 V
Input PhaseAC 3-Phase
Rated In A7.3 A/5.8 A
Rated In Hz50/60 Hz
OutputAC 3 Phase
Power out0-240 V
Output Hz0-400 Hz
Rated out A6.0/5.0 A
Mass1.3 Kg
EnclosureType 1
ProtectionIP20

Our Repair Services

MRO Electric repairs CNCs, PLCs, Servo/Spindle Drives, Motors, Amplifiers, VFDs, HMIs, and more, most of which can be repaired in only 3-5 days.

Repair Benefits

MRO can restore your failed CIMR-VU2A0006FAA to remanufactured condition and save you up to 75% compared to buying new. We offer standard repair pricing to ensure you the best value for your repair.

Our certified technicians use rigorous testing procedures to ensure your parts are restored to fully functioning condition. Our team proudly stands behind all repairs by providing a minimum 2-year warranty.

Our technicians have vast experience with most manufacturers and models. In addition to this CIMR-VU2A0006FAA we also repair a wide range of other Yaskawa products, so if you don’t see the model you need, please contact us.

Core Exchange

If you are interested in getting credit for your faulty CIMR-VU2A0006FAA, just let us know, and we can issue you an RMA to send it in as an exchange. Our exchange program provides you with savings and keeps us stocked for the next time you need anything.

  • Shipping Weight : 3lbs

Want it shipped tomorrow?

  • Order within the next 17 hours and 22 minutes.
  • If you order between 4pm and 6pm EST, you will be charged a small rush fee.

Ask about exchanging your faulty CIMR-VU2A0006FAA for credit when ordering from MRO Electric

MRO Electric provides a 2-year warranty on every item we sell and repair. We stand behind all of our products and guarantee them for the full 2 years. If there is an issue with any of our products within the warranty period, we will evaluate the unit and repair or replace it under warranty.

Yaskawa CIMR-VU2A0006FAA Overview

Yaskawa CIMR-VU2A0006FAA

The Yaskawa CIMR-VU2A0006FAA is a compact current vector drive that sets a new standard in the field. As the demand for efficient production and improved maintainability continues to rise in the face of global competition, Yaskawa drives have established themselves as high-performance, functional, and high-quality solutions. These products are manufactured in Japan and are designed for Advanced manufacturing, milling, and factory automation usage. They come with a 2-year warranty from MRO Electric. We also carry AC Drives from other manufacturers such as Schneider Electric and KUKA.

Features

This model offers a range of performance features to meet various application requirements. It is available in different power ratings, including 1/8 to 5 HP at 200-240 VAC 1-Phase, 1/8 to 25 HP (ND) at 200-240 VAC 3-Phase, and 1/2 to 25 HP (ND) at 380-480 VAC 3-Phase. The drive exhibits excellent overload capacity, with 150% for 60 seconds in heavy-duty applications and 120% for 60 seconds in normal duty.

Control

The CIMR-VU2A0006FAA offers several control methods, including V/f control, open-loop current vector control, PM open-loop current vector control, and simple closed-loop speed control. It also features DC injection braking, ramp-to-stop functionality, and electronic reversing. The acceleration and deceleration rates are adjustable from 0.01 to 6000 seconds, providing flexibility in application-specific speed profiles.

With a controlled speed range of 40:1 to 100:1, the drive offers precise speed regulation. It achieves ±0.5 to 1% speed regulation with slip compensation in V/f mode and ±0.2% speed regulation in open-loop current vector mode. The drive exhibits a displacement power factor of 0.98, ensuring efficient power utilization. The output frequency ranges from 0 to 400 Hz, with a frequency resolution of 0.01 Hz with digital reference and 0.06/60 Hz with analog reference.

Functionality

Designed for versatility, the CIMR-VU2A0006FAA provides adjustable volts/hertz ratio and DC injection braking parameters. It also incorporates torque boost functionality and power loss ride-thru capability of 0.5 seconds. The drive includes features like auto restart, speed search, slip compensation, energy savings function, and enhanced PID control with loss of feedback function.

Design

The design features of the CIMR-VU2A0006FAA contribute to its user-friendly operation and integration. It utilizes dual microprocessor logic and includes a digital keypad operator with a five-digit display and LED status indicators. The drive supports remote mount keypad capability and features an RJ-45-style digital operator connector. It provides multiple digital inputs and outputs, programmable form C output contact, analog monitor output, and digital pulse train input.

Safety

The drive offers a range of protective features to ensure the safety and longevity of the motor. It includes various protections such as current limit, stall prevention, motor and drive overload protection, overvoltage prevention, instantaneous overcurrent protection, short circuit protection, under voltage protection, heatsink overheat protection, ground fault protection, and over/under torque protection.

Operation

The CIMR-VU2A0006FAA is designed to operate under specific service conditions. It has an ambient service temperature range of -10°C to 40°C (+14°F to 104°F) in NEMA 1 enclosure and -10°C to 50°C (+14°F to 122°F) in an open chassis configuration. The drive can operate in high humidity environments up to 95% non-condensing and is suitable for altitudes up to 3300 ft (higher with derating).

Options

Yaskawa provides a range of options and accessories for the CIMR-VU2A0006FAA, including a dynamic braking resistor, communication modules (Profibus-DP, DeviceNet, Modbus TCP/IP, EtherNet/IP, and MECHATROLINK-II), software tools (DriveWizard Plus and CASE software), mounting kits, control power units, remote operator interfaces, interface adapters, external heatsink kits, reactors, EMC filters, and more.

Standards

The CIMR-VU2A0006FAA complies with various international standards and certifications, ensuring its reliability and safety. It is UL 508C and CSA 22.2 No. 14-95 listed for power conversion and industrial control equipment, respectively. The drive is also UL and cUL listed, CE marked, RoHS compliant, and complies with standards such as EN 50178 (LVD), EN 50081-2, EN 50082-2 (EMC), EN 954-1 Category 3 (Safety Standard), EN 61800-3, IEC 529, 146, and FCC CFR 47 Part 15 Subpart B (with External Filter).

FAQ: Yaskawa CIMR-VU2A0006FAA AC Drive

Q: What is the Yaskawa CIMR-VU2A0006FAA?

A: The Yaskawa CIMR-VU2A0006FAA is an AC drive designed for controlling the speed and torque of AC motors in industrial applications.

Q: What power supply voltage does the CIMR-VU2A0006FAA support?

A: The CIMR-VU2A0006FAA supports a power supply voltage range of 200-240 V, ensuring compatibility with standard industrial power systems.

Q: What type of input phase does the CIMR-VU2A0006FAA require?

A: The CIMR-VU2A0006FAA is designed to operate with AC 3-phase input power, commonly found in industrial settings, ensuring efficient and reliable operation.

Q: What are the rated input current and frequency for the CIMR-VU2A0006FAA?

A: The CIMR-VU2A0006FAA has a rated input current of 7.3 A at 50 Hz and 5.8 A at 60 Hz, providing ample power for motor control in industrial applications.

Q: What is the output voltage and frequency range of the CIMR-VU2A0006FAA?

A: The CIMR-VU2A0006FAA provides an output voltage range of 0-240 V and an output frequency range of 0-400 Hz, allowing for precise control over motor speed and torque.

Q: What is the rated output current of the CIMR-VU2A0006FAA?

A: The CIMR-VU2A0006FAA has a rated output current of 6.0 A at 50 Hz and 5.0 A at 60 Hz, ensuring optimal performance and efficiency in motor control applications.

Q: What is the mass and enclosure type of the CIMR-VU2A0006FAA?

A: The CIMR-VU2A0006FAA has a mass of 1.3 kg and features a Type 1 enclosure, providing protection against solid foreign objects and ensuring safe operation in industrial environments.

Q: What level of protection does the CIMR-VU2A0006FAA offer?

A: The CIMR-VU2A0006FAA is rated IP20, indicating its protection against solid foreign objects and ensuring reliable performance in various industrial environments.
