CIMR-VU4A0004FAA

CIMR-VU4A0004FAA

Rated 5/5 on 1 review

Rate this product


MANUFACTURER: Yaskawa

DESCRIPTION: Drive, AC, 1HP, 480V, 3PH, 3.4A, CT, N1 2HP, 4.1A, VT 5.89"Hx4.25"Wx5.41"D

PRODUCT TYPE INFO: V1000 Drive

5 in stock

Free Shipping
2 Year warranty

Categories

Part NumberCIMR-VU4A0004FAA
ManufacturerYaskawa
SeriesV1000 Drives
Model #CIMRVU4A0004FAA
Weight3lbs
TypeAC Drives
Warranty2 Year
Input380-480 V
Phase3 Phase
CT Amps3.4 A
VT Amps4.1 A
Frequency Max 400 Hz
CT Horsepower1 hp
VT Horsepower2 hp
Braking TypeDC injection, Dynamic braking Transistor
Mount typePanel
Dimensions5.89 in x 4.25 in x 5.41 in
RatingNEMA 1

Our Repair Services

MRO Electric repairs CNCs, PLCs, Servo/Spindle Drives, Motors, Amplifiers, VFDs, HMIs, and more, most of which can be repaired in only 3-5 days.

Repair Benefits

MRO can restore your failed CIMR-VU4A0004FAA to remanufactured condition and save you up to 75% compared to buying new. We offer standard repair pricing to ensure you the best value for your repair.

Our certified technicians use rigorous testing procedures to ensure your parts are restored to fully functioning condition. Our team proudly stands behind all repairs by providing a minimum 2 year warranty.

Our technicians have vast experience with most manufacturers and models. In addition to this CIMR-VU4A0004FAA we also repair drives, motors, PLCs and more, so if you don’t see the model you need, please contact us.

Core Exchange

If you are interested in getting credit for your faulty CIMR-VU4A0004FAA, just let us know and we can issue you an RMA to send it in as an exchange. Our exchange program provides you with savings and keeps us stocked for the next time you need anything.

This product weighs 3lbs. Want it shipped tomorrow?

  • Order within the next 23 hours and 7 minutes.
  • If you order between 4pm and 6pm EST, you will be charged a small rush fee.

Ask about exchanging your faulty CIMR-VU4A0004FAA for credit when ordering from MRO Electric

Additional Information

Yaskawa CIMR-VU4A0004FAA Overview

The CIMR-VU4A0004FAA Variable Frequency Drive manufactured by Yaskawa is an AC drive within the V1000 series.  The dimensions of this vector control drive are 5.89 inches high x 4.25 inches wide x 5.41 inches deep.  The CIMR-VU4A0004FAA is a 3-input phase drive with an input range of 380 v to 480 V AC. The Yaskawa CIMR-VU4A0004FAA has 3 HP and is available for purchase at MRO Electric and Supply.

Features

The rating for the CIMR-VU4A0004FAA is NEMA 1. There are three main circuit terminals when connecting this module. Before wiring the variable frequency drive, the NEMA 1 open-chassis front, and bottom cover are removed by loosening the screws that lock them into place.  The cover removes when pressure is applied to both sides as you pull the cover away.

A description of Yaskawa CIMR-VU4A0004FAA main circuit wiring includes information about the terminal, the type, and function. Terminals R/L1, S/L2, and T/L3 are main circuit power supply input connections.  The function of the main circuit power supply is to connect line power to the drive. Terminals U/T1, V/T2, and W/T3 are drive output connections.  The job of the drive output connection is to connect the drive to the motor. Terminals B1 and B2 are braking resistor connections.  The braking resistor connections are available for connecting a braking resistor or the braking resistor option to the unit. There are 2 available DC-link choke connections. The DC-link choke connections are terminals are shorted and the short must be removed between connections 1 and 2 so the CIMR-VU4A0004FAA unit can then be connected to the DC link. There is one connection terminal for the DC power supply input. The DC power supply input connection is used to connect a DC power supply.  The final connections on the Yaskawa CIMR-VU4A0004FAA Variable Frequency Drive are 2 ground terminals.  The ground terminals are made for grounding the vector control drive.

The functions that apply to the multi-function digital inputs, multi-function digital outputs, the multi-function pulse inputs and outputs, and multifunction photocoupler outputs are determined by the drive parameters.

Advantages

The Yaskawa CIMR-VU4A0004FAA Variable Frequency Drive has a switch for I/O connections. The two modes are sinking and sourcing. The DIP switch S3 is located on the front of the drive.  It is used to switch the digital input terminal logic between the two different modes. It is preset to sinking mode and must be switched to achieve sourcing mode.

           -Control digital inputs by NPN transistors by setting the DIP switch S3 to SINK and use an internal 24 V power supply.

           -Control digital inputs by PNP transistors by setting the DIP switch S3 to SOURCE and use an external 24 V power supply.

When selecting DIP switch S1 analog input signals, there can either be a voltage or a current signal input regarding the main frequency. A1 and A2 can both be used for voltage signals, but current signals, you must use A2.

Set DIP switch S1 to the left position, the “V” position, and program parameter H3-09 to “0” or “1” when using input A2 as a voltage input. Terminal A2 used for current input uses the DIP switch S1 setting “I” with parameter settings H3-09= “2” or ”3”.

The braking resistor is a feature that allows your motor to come to a smooth stop in a quick manner when working with loads high in inertia.

The Yaskawa CIMR-VU4A0004FAA Variable Frequency Drive comes with a two-year warranty.
