CIMR-VU4A0011FAA

CIMR-VU4A0011FAA

Rated 5/5 on 2 reviews

Rate this product


MANUFACTURER: Yaskawa

DESCRIPTION: Drive, AC, 5HP, 480V, 3PH, 9.2A, CT, N1 7.5HP, 11.1A

PRODUCT TYPE INFO: V1000 drive

6 in stock
Ships Today

Free Shipping
2 Year warranty
Part NumberCIMR-VU4A0011FAA
ManufacturerYaskawa
Model #CIMRVU4A0011FAA
TypeAC Drives
Warranty2 Year
Max HP7.5 hp
Phase (Input/Output)3 Phase
Voltage output380-480 V
Voltage Input380-480 V
Max Amps11.1 A
Output Frequency0~400 Hz
Braking TransistorStandard
ProtextionIP20/NEMA 1
CertificationsCE, UL, cUL, RoHS, TUV
CommunicationRS-422/485 MODBUS 115 kbps

Our Repair Services

MRO Electric repairs CNCs, PLCs, Servo/Spindle Drives, Motors, Amplifiers, VFDs, HMIs, and more, most of which can be repaired in only 3-5 days.

Repair Benefits

MRO can restore your failed CIMR-VU4A0011FAA to remanufactured condition and save you up to 75% compared to buying new. We offer standard repair pricing to ensure you the best value for your repair.

Our certified technicians use rigorous testing procedures to ensure your parts are restored to fully functioning condition. Our team proudly stands behind all repairs by providing a minimum 2 year warranty.

Our technicians have vast experience with most manufacturers and models. In addition to this CIMR-VU4A0011FAA we also repair drives, motors, PLCs and more, so if you don’t see the model you need, please contact us.

Core Exchange

If you are interested in getting credit for your faulty CIMR-VU4A0011FAA, just let us know and we can issue you an RMA to send it in as an exchange. Our exchange program provides you with savings and keeps us stocked for the next time you need anything.

  • Shipping Weight : 3lbs

Want it shipped today?

  • Order within the next 14 hours and 2 minutes.
  • If you order between 4pm and 6pm EST, you will be charged a small rush fee.

Ask about exchanging your faulty CIMR-VU4A0011FAA for credit when ordering from MRO Electric

MRO Electric provides a 2-year warranty on every item we sell and repair. We stand behind all of our products and guarantee them for the full 2 years. If there is an issue with any of our products within the warranty period, we will evaluate the unit and repair or replace it under warranty.

Additional Information

Yaskawa CIMR-VU4A0011FAA Overview

The CIMR-VU4A0011FAA is an AC drive manufactured by Yaskawa, with a maximum power of 7.5 horsepower. It is a three-phase drive with input and output voltages of 380-480V and a maximum current of 11.1A. The output frequency ranges from 0 to 400 Hz, and it has a standard braking transistor. The drive has protection ratings of IP20/NEMA 1 and is certified by CE, UL, cUL, RoHS, and TUV. It can communicate through RS-422/485 MODBUS 115 kbps and comes with a 2-year warranty.

Performance Features

The Yaskawa CIMRVU4A0011FAA V1000 drive is a powerful and versatile drive with a wide range of performance features. It is rated at 1/8 to 5 HP at 200-240 VAC 1-Ph, 1/8 to 25 HP (ND) at 200-240 VAC 3-Ph, and 1/2 to 25 HP (ND) at 380-480 VAC 3-Ph. It has an overload capacity of 150% for 60 sec. (Heavy Duty) and 120% for 60 sec. (Normal Duty). The drive offers different control methods, including V/f Control, Open Loop Current Vector Control, PM Open Loop Current Vector Control, and Simple closed-loop speed control.

The drive also features DC injection braking and ramp to stop, electronic reversing, adjustable accel/decel of 0.01 to 6000 seconds, and a controlled speed range of 40:1(1) to 100:1(2). The speed regulation is ± 0.5 to 1% with slip compensation (1) and ± 0.2% (2). The displacement power factor is 0.98, and the output frequency ranges from 0 to 400 Hz. The frequency resolution is 0.01 Hz with digital reference and 0.06/60 Hz with analog reference. The frequency accuracy is 0.01% with digital command and 0.5% with analog command.

The volts/hertz ratio is an infinitely adjustable pattern, and the DC injection braking is adjustable in amplitude, duration, and current limited. The drive also has torque boost, full range, auto, power loss ride-thru of 0.5 sec, speed search, auto restart, and three critical frequency rejection settings.

Additionally, it has slip compensation, an energy savings function, and

enhanced PID with the loss of feedback function. These performance features make the Yaskawa CIMRVU4A0011FAA V1000 drive a reliable and efficient solution for many applications.

Design Features

The Yaskawa CIMRVU4A0011FAA V1000 drive is equipped with dual microprocessor logic, a digital keypad operator with five digits, and an LED status display. The drive also has remote mount keypad capability and an RJ-45 digital operator connector. It features seven multifunction digital inputs, three multifunction digital outputs, hardwire base block (EN954-1 Cat. 3), and a programmable form C output contact for customer use (1A at 250 VAC or 30 VDC). The 24 VDC control logic is compatible with sourcing or sinking outputs (PNP or NPN), and the carrier frequency is 15 kHz max with swing PWM. The V1000 drive also includes 16 multi-speed settings plus jog speed, and two remote speed references (0-10 VDC (20 kohms) or isolated 4-20 mA (250 ohms)). It has a signal follower with bias and gain, two programmable open collector outputs, and an analog monitor output (0-10 VDC proportional to output frequency or output current). The V1000 has approximately 400 parameters and monitors, a digital pulse train input (33 kHz max), and a cooling fan controlled by drive run/stop. It also has RS-422/485 Modbus 115 kbps, a UL-recognized electronic overload, and an MTBF of 28 years. The built-in dynamic braking transistor and NEMA 1 enclosure contribute to the drive's rugged construction. It also features side-by-side mounting, application presets, and maintenance monitors for improved efficiency and productivity.

Protective features

The Yaskawa CIMRVU4A0011FAA drive has several protective features that prevent damage to the equipment and ensure safe operation. The drive has a current limit function that prevents motor stalling during acceleration, deceleration, and operation. It also has overload protection for both the motor and the drive, and an overvoltage prevention function. The drive is equipped with protection against instantaneous overcurrent, short circuits, under voltage, heatsink overheating, and ground faults. In addition, it has over/under torque protection. The drive has a short circuit current rating of 30kA rms symmetrical, ensuring that it can handle short-circuit conditions without causing damage to the system. These protective features make the Yaskawa CIMRVU4A0011FAA drive reliable and safe to use.

Product Description

The CIMR-VU4A0011FAA is a Drive, AC, 5HP, 480V, 3PH, 9.2A, CT, N1 7.5HP, 11.... that is manufactured by Yaskawa. These products are manufactured in Japan and are designed for Advanced manufacturing, milling, and factory automation usage. All of the products come with a 2 year warranty from MRO Electric. We also carry AC Drives from other manufacturers such as Schneider Electric and KUKA.
