REAR MODULE CONTROLLER PANEL - DIG 8 INPUTS/8 OUTPUTS +ANA 4 IN/2 OUT
Available
Free Shipping
2 Year MRO warranty
| Part Number | HMISBC |
| Manufacturer | Schneider Electric |
| Type | HMIs |
| MRO Warranty | 2 Year |
| Product weight | 0.359 kg |
| Range of product | Magelis SCU |
| Product or component type | Controller |
| Supply | External source |
| [Us] rated supply voltage | 24 V at 20.4...28.8 V DC |
| Immunity to microbreaks | <= 10 ms |
| Inrush current | <= 30 A |
| Power consumption | 15 W |
| Local signalling | No indicator |
| Number of pages | Limited by internal memory capacity |
| Software designation | SoMachine |
| Operating system | Magelis |
| Processor name | CPU RISC |
| Processor frequency | 333 MHz |
| Memory description | 128 MB flash memory, type: NAND |
| 128 kB internal data storage memory, type: FRAM | |
| 128 MB application run memory, type: DRAM | |
| Integrated connection type | 1 Ethernet TCP/IP, connector type: RJ45 |
| 1 serial link, communication ports RS485/RS232, connector type: RJ45, transmission rate: <= 115.2 | |
| Realtime clock | Built-in |
| Downloadable protocols | Modbus |
| Modbus TCP/IP | |
| CANopen | |
| Fixing mode | By 1 nut - diameter: Ø 22 mm, mounting on: 1...6 mm thick panel |
| Enclosure material | PC/PBT |
| Shock resistance | 147 m/s² (duration=11 ms) conforming to IEC 60068-2-27 on DIN rail |
| 294 m/s² (duration=6 ms) conforming to IEC 60068-2-27 on panel mounting | |
| Vibration resistance | +/- 3.5 mm (f=5...9 Hz) conforming to IEC 60068-2-6 |
| 1 gn (f=9...150 Hz) conforming to IEC 60068-2-6 | |
| Electromagnetic compatibility | Electrostatic discharge immunity test - test level: 8 kV, air discharge conforming to IEC 61000-4-2 |
| Electrostatic discharge immunity test - test level: 6 kV, contact discharge conforming to IEC | |
| 61000-4-2 | |
| Susceptibility to electromagnetic fields - test level: 10 V/m, 80 MHz...3 GHz conforming to IEC | |
| 61000-4-3 | |
| Electrical fast transient/burst immunity test - test level: 2 kV, power lines conforming to IEC 61000-4-4 | |
| Electrical fast transient/burst immunity test - test level: 1 kV, between analogue I/O and operating | |
| voltage conforming to IEC 61000-4-4 | |
| Electrical fast transient/burst immunity test - test level: 2 kV, relay wires conforming to IEC 61000-4-4 | |
| Electrical fast transient/burst immunity test - test level: 1 kV, Ethernet line conforming to IEC | |
| 61000-4-4 | |
| Electrical fast transient/burst immunity test - test level: 1 kV, COM line conforming to IEC 61000-4-4 | |
| Electrical fast transient/burst immunity test - test level: 1 kV, CAN line conforming to IEC 61000-4-4 | |
| Surge immunity test - test level: 2 kV, power supply (common mode) conforming to IEC 61000-4-5 | |
| Surge immunity test - test level: 1 kV, power supply (differential mode) conforming to IEC 61000-4-5 | |
| Surge immunity test - test level: 1 kV common mode, digital I/O conforming to IEC 61000-4-5 | |
| Surge immunity test - test level: 0.5 kV differential mode, digital I/O conforming to IEC 61000-4-5 | |
| Conducted RF disturbances - test level: 10 V, 0.15...80 MHz conforming to IEC 61000-4-6 | |
| Conducted emission - test level: 150 kHz...30 MHz conforming to EN 55011 | |
| Radiated emission - test level: 30 MHz...1 GHz conforming to EN 55011 | |
| Discrete input number | 2 for fast input (normal mode) conforming to IEC 61131-2 Type 1 |
| 6 for digital input conforming to IEC 61131-2 Type 1 | |
| Discrete input voltage | 24 V DC discrete input logic:sink or source (positive/negative) |
| Number of common point | 1 for fast input (HSC mode) |
| 1 for digital input | |
| Discrete input current | 7.83 mA for fast input |
| 5 mA for digital | |
| Input impedance | 4.7 kOhm |
| 2.81 kOhm | |
| Sensor power supply | 15...28.8 V DC, voltage (state 1): >= 15 V, current (state 1): >= 5 mA, voltage (state 0): <= 5 V, |
| current (state 0): <= 1.5 mA | |
| 15...28.8 V DC, voltage (state 1): >= 15 V, current (state 1): >= 2.5 mA, voltage (state 0): <= 5 V, | |
| current (state 0): <= 1 mA | |
| Configurable filtering time | 0 ms no filter (none) |
| 0.004...0.04 ms bounce filter (latch/event and cumulative filter by step Nx0.5ms (64>=N>=2)) | |
| 3...12 ms integrator (none/run/stop) | |
| Input frequency | 100 kHz for fast input (encoder mode) - control type A/B |
| 100 kHz for fast input - control type single phase | |
| 100 kHz for fast input - control type pulse/direction | |
| Cable length | 10 m shielded cable for fast input |
| 100 m shielded cable for digital input | |
| 50 m unshielded cable for digital input | |
| Connection pitch | 3.5 mm |
| Overvoltage protection | With |
| Isolation between channels and | 500 V DC |
| Isolation between channels | None |
| Discrete output number | 2 fast output (normal mode), output logic: source |
| 6 digital output, output logic: source | |
| Discrete output voltage | 24 V DC (voltage limit: 19.2...28.8 V) with transistor discrete output(s) |
| 24 V DC (voltage limit: 5...30 V) with relay discrete output(s) | |
| 220 V AC (voltage limit: 100...250 V) with relay discrete output(s) | |
| Input/Output number | 2 for fast input, terminal(s): FI0...FI1 |
| 2 for fast output, terminal(s): FQ0...FQ1 | |
| 6 for digital input, terminal(s): DI0...DI5 | |
| 6 for digital output, terminal(s): DQ0...DQ5 | |
| Discrete output current | 300 mA, response time 2 ms for fast output (normal mode) |
| 50 mA, response time 2 ms for fast output (PWM or PTO mode) | |
| 2 A (current per output common:4 A), response time 5 ms with opening contact for digital output | |
| 2 A (current per output common:4 A), response time 2 ms with closing contact for digital output | |
| Insulation resistance | > 10 MOhm between the I/O and internal logic |
| > 10 MOhm between power supply and earth | |
| Output frequency | <= 100 kHz for fast output (PTO mode) |
| Absolute accuracy error | +/- 0.1 % of full scale of cyclic ratio 1...99% for fast output (PWM or PTO mode) |
| 1 % of full scale of cyclic ratio 1...99% for fast output (PWM or PTO mode) | |
| +/- 5 % of full scale of cyclic ratio 10...90% for fast output (PWM or PTO mode) | |
| +/- 10 % of full scale of cyclic ratio 20...80% for fast output (PWM or PTO mode) | |
| +/- 15 % of full scale of cyclic ratio 30...70% for fast output (PWM or PTO mode) | |
| Analogue input number | 2 for analog input |
| 2 for RTDs | |
| Analogue input range | 0...20 mA/4...20 mA - resolution: 12 bits, input impedance: 250 Ohm (tolerance: +/- 1 %) |
| -10...+10 V or 0...10 V - resolution: 12 bits + sign, input impedance: >= 1 MOhm | |
| Analogue input type | RTD at - 200...600 °C - resolution: 16 bits temperature probe: Pt 100/Pt 1000 |
| RTD at - 50...200 °C - resolution: 16 bits temperature probe: Ni 100/Ni 1000 | |
| RTD at - 200...760 °C - resolution: 16 bits (thermocouple J) | |
| RTD at - 240...1370 °C - resolution: 16 bits (thermocouple K) | |
| RTD at 0...1600 °C - resolution: 16 bits (thermocouple R) | |
| RTD at 200...1800 °C - resolution: 16 bits (thermocouple B) | |
| RTD at 0...1600 °C - resolution: 16 bits (thermocouple S) | |
| RTD at - 200...400 °C - resolution: 16 bits (thermocouple T) | |
| RTD at - 200...900 °C - resolution: 16 bits (thermocouple E) | |
| RTD at - 200...1300 °C - resolution: 16 bits (thermocouple N) | |
| Analogue output number | 2 resistive load for 12 bits + sign |
| Analogue output range | 0...20 mA/4...20 mA (> 300 Ohm) for open-circuit |
| -10...10 V/0...10 V (> 2 kOhm) for short-circuit | |
| Height | 50.65 mm |
| Width | 128 mm |
| Depth | 102 mm |
MRO Electric repairs CNCs, PLCs, Servo/Spindle Drives, Motors, Amplifiers, VFDs, HMIs, and more, most of which can be repaired in only 3-5 days.
MRO can restore your failed HMISBC to remanufactured condition and save you up to 75% compared to buying new. We offer standard repair pricing to ensure you the best value for your repair.
Our certified technicians use rigorous testing procedures to ensure your parts are restored to fully functioning condition. Our team proudly stands behind all repairs by providing a minimum 2-year MRO warranty.
Our technicians have vast experience with most manufacturers and models. In addition to this HMISBC we also repair drives, motors, PLCs and more, so if you don’t see the model you need, please contact us.
If you are interested in getting credit for your faulty HMISBC, just let us know, and we can issue you an RMA to send it in as an exchange. Our exchange program provides you with savings and keeps us stocked for the next time you need anything.
Want it shipped today?
Ask about exchanging your faulty HMISBC for credit when ordering from MRO Electric
Can a HMISCU controller be used without the display?
The Schneider Electric HMISBC is a high-performance HMI controller from the Magelis SCU range, designed for industrial automation systems that require precision, reliability, and scalable control solutions. HMISBC features a 24 V DC supply, immunity to microbreaks of up to 10 ms, and low power consumption of 15 W, ensuring dependable operation in demanding environments. The controller utilizes a CPU RISC processor operating at 333 MHz, complemented by 128 MB of NAND flash memory, 128 MB of DRAM, and 128 kB of FRAM for application execution and data storage.
HMISBC offers flexible connectivity via Ethernet TCP/IP and RS-485/RS-232 serial ports, supporting widely used industrial communication protocols, including Modbus, Modbus TCP/IP, and CANopen. These features enable seamless integration into existing automation networks, allowing HMISBC to communicate reliably with drives, sensors, and actuators.
The controller includes multiple discrete inputs and outputs, as well as analogue I/Os, enabling precise control over industrial processes. Fast inputs and outputs support high-speed operation up to 100 kHz, while configurable filtering and overvoltage protection ensure accuracy and stability. HMISBC accommodates multiple RTD and thermocouple types, allowing exact temperature measurement across a wide range of industrial applications.
HMISBC is engineered for robustness with shock resistance up to 294 m/s² and vibration tolerance across industrial frequency ranges. The enclosure, made from PC/PBT, is designed for panel mounting using a single nut on panels 1–6 mm thick. The controller meets electromagnetic compatibility standards, including electrostatic discharge, surge, and fast transient immunity, ensuring reliable performance even in electrically noisy environments.
The HMI controller mounts easily and integrates with Schneider Electric's SoMachine software and Magelis operating system, providing flexible programming and monitoring options. Its real-time clock, internal memory, and multiple communication ports enable comprehensive control for modern automation systems.
HMISBC is available immediately from MRO Electric and Supply. Each unit comes with a 2-year MRO warranty and free shipping, ensuring rapid deployment and peace of mind for industrial automation projects. With its robust performance, extensive protocol support, and flexible connectivity, HMISBC is an ideal solution for manufacturers, system integrators, and engineers seeking a reliable HMI.
What is the part number of the Schneider Electric HMI controller?
The part number is HMISBC, designed explicitly for Magelis SCU applications.
What type of HMI is HMISBC?
HMISBC is a Magelis SCU HMI controller, providing advanced interface and control functions for industrial automation.
What is the rated supply voltage for HMISBC?
HMISBC operates on a 24 V DC supply, with an acceptable range of 20.4–28.8 V DC.
Which communication protocols are supported by HMISBC?
HMISBC supports Modbus, Modbus TCP/IP, and CANopen, ensuring compatibility with a wide range of industrial devices and systems.
What is the processor frequency of HMISBC?
The processor in HMISBC is a CPU RISC running at 333 MHz, providing efficient performance for complex control tasks.
What type of memory does HMISBC include?
HMISBC features 128 MB of NAND flash memory for programs, 128 MB of DRAM for application execution, and 128 kB of FRAM for internal data storage.
What is the mounting method for HMISBC?
HMISBC mounts using a single nut on panels 1–6 mm thick, making installation straightforward and secure.
What is the warranty for HMISBC?
Each HMISBC unit comes with a 2-year MRO warranty from MRO Electric, covering manufacturing defects and ensuring reliability.
What is the maximum shock and vibration resistance of HMISBC?
HMISBC withstands shock of up to 294 m/s² and vibration of up to 1 g across industrial frequencies, meeting IEC standards for harsh environments.
Is HMISBC available for immediate shipping?
Yes, HMISBC is available immediately from MRO Electric and Supply with free shipping, ensuring fast delivery for industrial projects.
