SGDM-15DN

2-year Warranty

Same Day Shipping

Yaskawa SGDM-15DN

SIGMA-II SERVOPACK - 3 PHASE - 400V, 1500W, 2.01HP

5/5
2 ratings

Select Condition

Refurbished

Request Quote

New

1 in stock

$2,397.00

Request a formal quote

  • Ships Today
  • 2 Year Warranty
  • Free Shipping
Part NumberSGDM-15DN
ManufacturerYaskawa
TypeAC Drives
Model #SGDM15DN
Warranty2 Year
RangeSGDM-15DN
CategoryServo pack
ServopackDrive module
Dimensions3.0" x 6.0" x 7.0"
Rated Voltage In380-480 VAC
Current input rating4.8 amp
Phase in3 PHASE
Frequency input Rating50/60 Hz
Output voltage0-480 VAC
Phase out3 phase
Current out rating5.4 amp
Frequency output rating0-300 Hz
Power out rating1.5 kW

Our Repair Services

MRO Electric repairs CNCs, PLCs, Servo/Spindle Drives, Motors, Amplifiers, VFDs, HMIs, and more, most of which can be repaired in only 3-5 days.

Repair Benefits

MRO can restore your failed SGDM-15DN to remanufactured condition and save you up to 75% compared to buying new. We offer standard repair pricing to ensure you the best value for your repair.

Our certified technicians use rigorous testing procedures to ensure your parts are restored to fully functioning condition. Our team proudly stands behind all repairs by providing a minimum 2-year warranty.

Our technicians have vast experience with most manufacturers and models. In addition to this SGDM-15DN we also repair a wide range of other Yaskawa products, so if you don’t see the model you need, please contact us.

Core Exchange

If you are interested in getting credit for your faulty SGDM-15DN, just let us know, and we can issue you an RMA to send it in as an exchange. Our exchange program provides you with savings and keeps us stocked for the next time you need anything.

  • Shipping Weight : 12lbs

Want it shipped tomorrow?

  • Order within the next 19 hours and 32 minutes.
  • If you order between 4pm and 6pm EST, you will be charged a small rush fee.

Ask about exchanging your faulty SGDM-15DN for credit when ordering from MRO Electric

MRO Electric provides a 2-year warranty on every item we sell and repair. We stand behind all of our products and guarantee them for the full 2 years. If there is an issue with any of our products within the warranty period, we will evaluate the unit and repair or replace it under warranty.

Yaskawa SGDM-15DN Overview

Yaskawa SGDM15DN

The Yaskawa SGDM15DN is a highly capable and compact servo pack, representing a significant advancement in motion control technology. As a critical component in industrial automation and precision control systems, the SGDM15DN serves as a bridge between the control electronics and the mechanical components, enabling precise and efficient motion control in a wide range of applications.

Design

At the heart of its design is the focus on delivering exceptional performance within a compact form factor. The SGDM15DN's dimensions of 3.0" x 6.0" x 7.0" make it remarkably space-efficient, ideal for installations where real estate is a premium. Despite its compact size, this servo pack doesn't compromise on power or features, showcasing the ingenuity and engineering prowess of Yaskawa, a renowned leader in motion control solutions.

The SGDM15DN is categorized as a servo pack, specifically a drive module. This designation indicates its role as a power amplifier and controller for servo motors, responsible for precisely translating control signals into smooth and accurate mechanical motion. By seamlessly interfacing with control systems and translating their commands into precise motor movements, the SGDM15DN empowers machinery to achieve intricate tasks with exceptional accuracy and repeatability.

Features

A noteworthy feature of the SGDM15DN is its impressive power density. Weighing just 1 pound and 9 ounces, it delivers a remarkable power output of 1.5 kW. This efficiency in power conversion and delivery is crucial in minimizing energy wastage and optimizing the overall system's performance. Whether it's used in robotics, CNC machinery, or other motion-intensive applications, the SGDM15DN contributes to energy-efficient operations and helps reduce operational costs.

The SGDM15DN operates within a voltage range of 380-480 VAC, compatible with standard industrial power supplies. This broad input voltage range ensures versatility and makes the servo pack suitable for a wide array of applications and operating environments. Furthermore, the 3-phase design enables robust and stable power delivery, crucial for maintaining consistent and accurate motion control.

Operation

The input current rating of 4.8 amps underscores the SGDM15DN's ability to handle substantial power demands while maintaining efficiency. This current rating, coupled with its 5.4-amp output current rating, ensures that the servo pack can effectively drive and control motors requiring varying levels of power. The 0-480 VAC output voltage range and 0-300 Hz frequency output rating provide the necessary flexibility to cater to different motor specifications and applications.

Function

An essential aspect of the SGDM15DN's functionality is its ability to interpret and execute control signals with precision. The servo pack supports input frequency ratings of 50/60 Hz, enabling compatibility with a wide range of control systems and communication protocols. This adaptability is crucial in seamlessly integrating the servo pack into existing automation setups, ensuring seamless interoperability with other components.

FAQ for Yaskawa SGDM-15DN Servo Pack Drive Module

What is the primary function of the Yaskawa SGDM-15DN?
The SGDM-15DN is a servo drive module designed to control servo motors for precision motion control applications in industrial automation systems.

What are the input power requirements for this drive?
The SGDM-15DN requires an input voltage of 380-480 VAC, a current input rating of 4.8 amps, and operates on a 3-phase power supply at a frequency of 50/60 Hz.

What is the output power specification?
The drive outputs a voltage range of 0-480 VAC with a current rating of 5.4 amps, at frequencies ranging from 0-300 Hz, and a power output rating of 1.5 kW.

What is the purpose of a servo pack?
Servo packs, like the SGDM-15DN, are used to precisely control the movement of servo motors, ensuring accurate positioning, speed regulation, and torque control for industrial machinery.

What are the dimensions of the SGDM-15DN?
The module measures 3.0" x 6.0" x 7.0", making it compact and suitable for installations with space constraints.

Is this drive suitable for three-phase power systems?
Yes, the SGDM-15DN is designed specifically for 3-phase input and output, ensuring compatibility with standard industrial power systems.

What warranty is provided for the SGDM-15DN?
The drive comes with a 2-year warranty provided by MRO Electric and Supply, offering peace of mind regarding reliability and support.

Can this servo pack be used with multiple types of servo motors?
Yes, the SGDM-15DN is compatible with various Yaskawa servo motors, provided they meet the drive's electrical and operational specifications.

What applications is this drive commonly used for?
The SGDM-15DN is ideal for applications requiring precise motion control, such as CNC machinery, robotics, material handling, and assembly lines.

What safety precautions should be observed during installation?
Ensure proper grounding, follow all wiring instructions as specified in the installation manual, and verify that the input power matches the drive's requirements. Always have qualified personnel perform installation and maintenance to prevent electrical hazards.

Yaskawa products are manufactured in Japan and are designed for Advanced manufacturing, milling, and factory automation usage. They come with a 2-year warranty from MRO Electric. We also carry AC Drives from other manufacturers such as Schneider Electric and KUKA.
