Schneider Electric TSXCRJMD25

Schneider Electric TSXCRJMD25 Connecting Cable

The Schneider Electric TSXCRJMD25 is a versatile, high-quality connecting cable for seamless integration with the Modicon Premium/Quantum automation platforms. As a crucial accessory within Schneider Electric's product range, this cable module facilitates reliable communication and data transfer between various automation system components. Whether for industrial automation or complex control systems, the TSXCRJMD25 is engineered to meet the high demands of modern industrial applications, ensuring smooth and efficient operation.

Overview of the TSXCRJMD25

The TSXCRJMD25 cable module is a premium accessory from Schneider Electric, specifically designed to enhance connectivity within the Modicon Premium/Quantum automation platforms. This module is crucial for establishing reliable communication between a PC terminal and the processor units of the Modicon series. Its robust construction and advanced design make it a dependable choice for various automation tasks, ensuring that data transfer and system integration are carried out efficiently and without interruptions.

Specifications and Design

The TSXCRJMD25 is 8.2 feet long, providing ample reach to connect devices at varying distances within an industrial setup. The cable has three essential connectors:

• One USB connector for the PC side
• One RJ45 connector for the processor side
• One mini-DIN connector for additional processor connectivity

This combination of connectors ensures compatibility with a wide range of devices, making the cable a versatile solution for different types of automation equipment.

Connection and Compatibility

This connecting cable is designated as a connection cord set for PC terminals. It is designed to interface between a personal computer and the Modicon Premium/Quantum processors. The USB connector allows for a straightforward connection to a PC. In contrast, the RJ45 and mini-DIN connectors ensure they can be integrated with various processor models within the Modicon series. The separate part designation for compatibility includes Premium TSX574./5 and Quantum 140CPU6.1, ensuring users can easily match the cable with their existing equipment.

Application and Usage

The TSXCRJMD25 cable module is designed for use in commercialized applications within industrial automation and control systems. Its primary function is facilitating communication between a PC and Modicon processors, making it an essential tool for configuration, monitoring, and control tasks. The cable's robust design and reliable performance ensure that it can handle the demands of industrial environments, providing stable and consistent connectivity for critical operations.

Warranty and Shipping

To ensure customer satisfaction and peace of mind, the TSXCRJMD25 cable module has a 2-year MRO Electric and Supply warranty. Additionally, when purchased from MRO Electric and Supply, the TSXCRJMD25 qualifies for free shipping, adding value to the purchase by reducing additional delivery costs.

Benefits of the TSXCRJMD25

The primary benefits of the Schneider Electric TSXCRJMD25 include its high-quality construction, reliable performance, and versatile connectivity options. The cable module's ability to connect a PC to various Modicon processors with different connector types makes it an indispensable accessory for industrial automation professionals. Its durability and compatibility with key Modicon models ensure it meets the high standards required for demanding applications.

Frequently Asked Questions (FAQ) for Schneider Electric TSXCRJMD25 Connecting Cable

1. What is the Schneider Electric TSXCRJMD25?

The Schneider Electric TSXCRJMD25 is a connecting cable designed for use with the Modicon Premium/Quantum automation platforms. It is an accessory that enables communication between a personal computer (PC) and the Modicon processors. This cable module is essential for integrating and connecting various components within industrial automation systems.

2. What are the key specifications of the TSXCRJMD25?

The TSXCRJMD25 cable has the following key specifications:

• Length: 8.2 feet (2.5 meters)
• Connectors:
• 1 USB connector (PC side)
• 1 RJ45 connector (Processor side)
• One mini-DIN connector (Processor side)
• Part Type: Accessory
• Status: Commercialized
• Application: Connection cord set for PC terminals
• Compatibility: Premium TSX574./5, Quantum 140CPU6.1

3. How does the TSXCRJMD25 connect different devices?

The TSXCRJMD25 cable connects devices using its three types of connectors:

• USB Connector: Connects to a PC, allowing communication between the computer and the automation system.
• RJ45 Connector: Connects to the processor side, enabling network communication.
• Mini DIN Connector also connects to the processor side, providing additional interface options.

4. What is the purpose of this connecting cable?

The TSXCRJMD25 establishes communication between a PC and the Modicon Premium/Quantum processors. It is essential for configuring, monitoring, and controlling automation systems. The cable facilitates data transfer and system integration, ensuring efficient operation within industrial automation setups.

5. What is the warranty period for the TSXCRJMD25?

The TSXCRJMD25 comes with a 2-year warranty from MRO Electric and Supply, which gives customers confidence in the product's quality and reliability.

6. Can this cable be used with other automation platforms besides Modicon Premium/Quantum?

The TSXCRJMD25 is specifically designed for use with the Modicon Premium/Quantum automation platforms. Due to its unique connector configuration and design tailored for Modicon equipment may not be compatible with other automation systems or platforms.

7. How should I handle the cable to ensure its longevity?

To ensure the longevity of the TSXCRJMD25 cable:

• Avoid excessive bending or twisting of the cable.
• Keep the cable away from extreme temperatures, moisture, and chemicals.
• Ensure that the connectors are securely attached and not subjected to physical stress.
• Store the cable in a clean, dry environment when not in use.

8. Is free shipping available for this product?

When purchased from MRO Electric and Supply, the TSXCRJMD25 qualifies for free shipping. This benefit reduces additional costs and provides added convenience for customers.

9. What are the dimensions of the TSXCRJMD25 cable?

The cable's dimensions are as follows:

• Length: 8.2 feet (2.5 meters)
• Height: Not applicable
• Width: Not applicable
• Depth: Not applicable. These dimensions are suited for a wide range of industrial and automation applications.

10. Where can I use the TSXCRJMD25 cable?

The TSXCRJMD25 is ideal for use in industrial automation environments where Modicon Premium or Quantum processors are employed. It is commonly used in control systems, manufacturing processes, and other automation tasks requiring reliable communication between a PC and processors.
