TSXMRPC007M

TSXMRPC007M

Rated 5/5 on 2 reviews

Rate this product


MANUFACTURER: Schneider Electric

DESCRIPTION: Configurable Sram Memory Extension - For Processor - 192..7168 Kb, 6976..0 Kb

PRODUCT TYPE INFO: Modicon Micro

6 in stock
Ships Today

Free Shipping
2 Year warranty

Categories

Part NumberTSXMRPC007M
ManufacturerSchneider Electric
SeriesModicon Micro
Model #TSXMRPC007M
Alternate ModelTSX-MRP-C00-7M
TypePLC
Warranty2 Year
Range of productModicon Premium Automation platform
Accessory / separate part designationConfigurable SRAM application/file memory extension
Accessory / separate part typeMemory extension
Accessory / separate part categorySeparate parts
Accessory / separate part destinationProcessor
Product compatibilityTSX570. to TSX576.
TSX57C.
TSXPCI572./3.
Memory typeSRAM
Memory capacity192...7168 kB application
6976...0 kB data storage
SlotSlot 0
Product weight0.076 kg
Sustainable offer statusGreen Premium product
RoHS (date code: YYWW)Compliant - since 1001 - Schneider Electric declaration of conformity
Product environmental profileAvailable
Product end of life instructionsAvailable

Our Repair Services

MRO Electric repairs CNCs, PLCs, Servo/Spindle Drives, Motors, Amplifiers, VFDs, HMIs, and more, most of which can be repaired in only 3-5 days.

Repair Benefits

MRO can restore your failed TSXMRPC007M to remanufactured condition and save you up to 75% compared to buying new. We offer standard repair pricing to ensure you the best value for your repair.

Our certified technicians use rigorous testing procedures to ensure your parts are restored to fully functioning condition. Our team proudly stands behind all repairs by providing a minimum 2 year warranty.

Our technicians have vast experience with most manufacturers and models. In addition to this TSXMRPC007M we also repair drives, motors, PLCs and more, so if you don’t see the model you need, please contact us.

Core Exchange

If you are interested in getting credit for your faulty TSXMRPC007M, just let us know and we can issue you an RMA to send it in as an exchange. Our exchange program provides you with savings and keeps us stocked for the next time you need anything.

  • Shipping Weight : 1lb

Want it shipped today?

  • Order within the next 4 hours and 53 minutes.
  • If you order between 4pm and 6pm EST, you will be charged a small rush fee.

Ask about exchanging your faulty TSXMRPC007M for credit when ordering from MRO Electric

MRO Electric provides a 2-year warranty on every item we sell and repair. We stand behind all of our products and guarantee them for the full 2 years. If there is an issue with any of our products within the warranty period, we will evaluate the unit and repair or replace it under warranty.

Additional Information

Schneider Electric TSX MRPC 007M Overview

The 7 MB PCMCIA memory card module TSX MRPC 007M is manufactured by Schneider Electric for use on the Modicon Quantum platform. The TSX MRPC 007M is a configurable SRAM memory extension and is used with the Quantum Safety PLC. Safety modules that are certified for use in SIL 3 applications utilize the PCMCIA memory card module TSX MRPC 007M.

Communication of the Quantum Safety PLC with Unity Pro XLS

When the Safety CPU is in Safety Mode, it rejects all write requests to the following memory areas:  %M or %Q (0x register), %MW or %QW (4x register), EFB data. In some cases, you may need to write data to the Safety PLC.  When this is the case, the memory will divide into two. The two parts the memory becomes sorted into are the safety and unrestricted parts. Sorting into parts allows one to write in %M as well as %MW.

Safety memory allows for a write-protected area for any other device.  The Unity Pro XLS configuration cannot be checked because of some of the communications with the HMI or other PLCs. These communications do not configure in the safety PLC and are not located in the Unity Po XLS. The write access is controlled within the CPU.

What is write protection? Write protection prevents other devices from writing to the Safety memory area. It accomplishes this with the use of a blocking mechanism.  The PLC is not responsible for any write command and will return an error code.

What is the unrestricted memory area? The unrestricted memory area, or UMA, is a memory area that is specially dedicated to bits and words, which are not write-protected. What are the characteristics of the unrestricted memory area? First, it is located at the start of the complete memory range. Second, it can be configured in Unity Pro XLS. Finally, the values of the unrestricted memory area can not be used directly.  It can only be used through the use of specific function blocks.

General info on SIL 3 application programming can be found in the product manual.

The Schneider Electric TSX MRPC 007M7 MB PCMCIA memory card module comes with a two-year warranty.

Product Description

The TSXMRPC007M is a Configurable Sram Memory Extension - For Processor... that is manufactured by Schneider Electric. These products are manufactured in France and are designed for Material handling, packaging, and textile machines usage. All of the products in the modicon-micro line come with a 2 year warranty from MRO Electric. We also carry TSX from other manufacturers such as Modicon and ABB.
