TSXP57303AM

2-year Warranty

Same Day Shipping

Schneider Electric TSXP57303AM

MODICON PREMIUM DOUBLE-FORMAT PL7 PROCESSOR - 1000 MA - IP20
5/5
1 rating

2 in stock


Free Shipping

2 Year warranty

Part NumberTSXP57303AM
ManufacturerSchneider Electric
TypeCPUs
Model #TSX-P57-303AM
Warranty2 Year
Module formatDouble
Product or component typeDouble-format PL7 processor
Number of racks8 12 slots
16 4/6/8 slots
Discrete I/O processor capacity1024 I/O
Analogue I/O processor capacity128 I/O
Number of application specific channel≤ 32
Number of process control channel≤ 15 up to 45 simple loops
Integrated connection typeSerial link 2 female mini DIN 19.2/115 kbit/s
Communication module1 CANopen bus module
processor2 fieldbus modules (1 if CANopen used)
3 network modules
8 AS-Interface bus modules
Memory descriptionPCMCIA card 384 Kwords program
PCMCIA card 2688 Kwords additional data storage
Internal RAM (with PCMCIA card) 80 Kwords data
Internal RAM (without PCMCIA card) 64 Kwords
program and data
Software designationPL7 Junior/Pro
Protective treatmentTC
Number of slots≤ 128
Maximum size of object areas30.5 %MWi internal words located internal data
32 %KWi constant words located internal data
16384 %Mi located internal bits
Application structure1 fast task
1 master task
64 event tasks
Execution time per instruction0.12 µs Boolean without PCMCIA card
0.17 µs word or fixed-point arithmetic without PCMCIA card
0.17 µs Boolean with PCMCIA card
0.33 µs word or fixed-point arithmetic with PCMCIA card
2.5 µs floating points without PCMCIA card
2.6 µs floating points with PCMCIA card
Number of instructions per ms3.08 Kinst/ms 65 % Boolean + 35 % fixed arithmetic with PCMCIA card
4.49 Kinst/ms 100 % Boolean with PCMCIA card
4.7 Kinst/ms 65 % Boolean + 35 % fixed arithmetic without PCMCIA card
6.57 Kinst/ms 100 % Boolean without PCMCIA card
System overhead0.29 ms fast task
1.15 ms master task
MarkingCE
Local signalling1 LED green processor running (RUN)
1 LED red processor or system fault (ERR)
1 LED red I/O module or configuration fault (I/O)
1 LED yellow activity on the terminal port (TER)
Current consumption1000 mA

Our Repair Services

MRO Electric repairs CNCs, PLCs, Servo/Spindle Drives, Motors, Amplifiers, VFDs, HMIs, and more, most of which can be repaired in only 3-5 days.

Repair Benefits

MRO can restore your failed TSXP57303AM to remanufactured condition and save you up to 75% compared to buying new. We offer standard repair pricing to ensure you the best value for your repair.

Our certified technicians use rigorous testing procedures to ensure your parts are restored to fully functioning condition. Our team proudly stands behind all repairs by providing a minimum 2-year warranty.

Our technicians have vast experience with most manufacturers and models. In addition to this TSXP57303AM we also repair drives, motors, PLCs and more, so if you don’t see the model you need, please contact us.

Core Exchange

If you are interested in getting credit for your faulty TSXP57303AM, just let us know, and we can issue you an RMA to send it in as an exchange. Our exchange program provides you with savings and keeps us stocked for the next time you need anything.

  • Shipping Weight : 2lbs

Want it shipped tomorrow?

  • Order within the next 17 hours and 45 minutes.
  • If you order between 4pm and 6pm EST, you will be charged a small rush fee.

Ask about exchanging your faulty TSXP57303AM for credit when ordering from MRO Electric

MRO Electric provides a 2-year warranty on every item we sell and repair. We stand behind all of our products and guarantee them for the full 2 years. If there is an issue with any of our products within the warranty period, we will evaluate the unit and repair or replace it under warranty.

Schneider Electric TSXP57303AM Overview

Schneider Electric products are manufactured in France and are designed for Material handling, packaging, and textile machines usage. They come with a 2-year warranty from MRO Electric. We also carry CPUs from other manufacturers such as Modicon and ABB.

Contact Us Today For More Information About Schneider Electric Products

Check out the rest of our Schneider Electric product line. Whether it's using our online instant quote feature, giving us a call at (800) 691-8511, or emailing us at sales@mroelectric.com, we strive for customer satisfaction first. This means lower prices and better service for you. For more products like TSXP57303AM, take a look at more from our CPUs line. If your current unit has gone bad, take advantage of our Core Exchange program for the most inexpensive route. You can learn more about this program on our FAQ page here. We offer a repair service on all of our TSXP57303AM products that keep your downtime to a minimum. To stay up to date on manufacturer news, as well as access any of our datasheets, manuals, or other documentation, we suggest you take a look at our blog.
