TSXP57453AM

2-year Warranty

Same Day Shipping

Schneider Electric TSXP57453AM

Rated 5/5 on 2 reviews

Rate this product


MANUFACTURER: Schneider Electric

DESCRIPTION: Double-Format PL7 Processor - 1080 Ma

PRODUCT TYPE INFO: Modicon

1 in stock


Free Shipping

2 Year warranty

Part NumberTSXP57453AM
ManufacturerSchneider Electric
TypeCPUs
Model #TSX-P57-453AM
Warranty2 Year
Module formatDouble
Product or component typeDouble-format PL7 processor
Number of racks8 12 slots
16 4/6/8 slots
Discrete I/O processor capacity2040 I/O
Analogue I/O processor capacity256 I/O
Number of application specific channel≤ 64
Number of process control channel≤ 20 up to 60 simple loops
Integrated connection typeFipio manager (127 agents) SUB-D 9
Serial link 2 female mini DIN 19.2/115 kbit/s
Communication module processor1 CANopen bus module
2 fieldbus modules (1 if CANopen used)
4 network modules
8 AS-Interface bus modules
Memory descriptionPCMCIA card 992 Kwords program
PCMCIA card 2048 Kwords additional data storage
Internal RAM (with PCMCIA card) 176 Kwords data
Internal RAM (without PCMCIA card) 96 Kwords program and data
Software designationPL7 Junior/Pro
Protective treatmentTC
Number of slots≤ 128
Maximum size of object areas30.5 %MWi internal words located internal data
32 %KWi constant words located internal data
32768 %Mi located internal bits
Application structure1 fast task
1 master task
64 event tasks
Execution time per instruction0.06 µs Boolean without PCMCIA card
0.06 µs Boolean with PCMCIA card
0.08 µs word or fixed-point arithmetic without PCMCIA card
0.08 µs word or fixed-point arithmetic with PCMCIA card
1.7 µs floating points without PCMCIA card
1.7 µs floating points with PCMCIA card
Number of instructions per ms8.8 Kinst/ms 65 % Boolean + 35 % fixed arithmetic without PCMCIA card
8.8 Kinst/ms 65 % Boolean + 35 % fixed arithmetic with PCMCIA card
13.82 Kinst/ms 100 % Boolean without PCMCIA card
13.82 Kinst/ms 100 % Boolean with PCMCIA card
System overhead0.22 ms fast task
1.15 ms master task
MarkingCE
Local signalling1 LED green processor running (RUN)
1 LED red processor or system fault (ERR)
1 LED red I/O module or configuration fault (I/O)
1 LED yellow activity on the terminal port (TER)
1 LED red activity on Fipio bus (FIP)
Current consumption1080 mA

Our Repair Services

MRO Electric repairs CNCs, PLCs, Servo/Spindle Drives, Motors, Amplifiers, VFDs, HMIs, and more, most of which can be repaired in only 3-5 days.

Repair Benefits

MRO can restore your failed TSXP57453AM to remanufactured condition and save you up to 75% compared to buying new. We offer standard repair pricing to ensure you the best value for your repair.

Our certified technicians use rigorous testing procedures to ensure your parts are restored to fully functioning condition. Our team proudly stands behind all repairs by providing a minimum 2-year warranty.

Our technicians have vast experience with most manufacturers and models. In addition to this TSXP57453AM we also repair drives, motors, PLCs and more, so if you don’t see the model you need, please contact us.

Core Exchange

If you are interested in getting credit for your faulty TSXP57453AM, just let us know, and we can issue you an RMA to send it in as an exchange. Our exchange program provides you with savings and keeps us stocked for the next time you need anything.

  • Shipping Weight : 3lbs

Want it shipped tomorrow?

  • Order within the next 22 hours and 53 minutes.
  • If you order between 4pm and 6pm EST, you will be charged a small rush fee.

Ask about exchanging your faulty TSXP57453AM for credit when ordering from MRO Electric

MRO Electric provides a 2-year warranty on every item we sell and repair. We stand behind all of our products and guarantee them for the full 2 years. If there is an issue with any of our products within the warranty period, we will evaluate the unit and repair or replace it under warranty.

Schneider Electric TSXP57453AM Overview

Schneider Electric products are manufactured in France and are designed for Material handling, packaging, and textile machines usage. They come with a 2-year warranty from MRO Electric. We also carry CPUs from other manufacturers such as Modicon and ABB.

PL7 processor

The TSXP57453AM is a double-format PL7 processor, a vital component within the Modicon Premium Automation platform by Schneider Electric. This processor plays a critical role in facilitating efficient and advanced automation and control functions in industrial applications.

Key Features:

  • Processor Type: The TSXP57453AM is a double-format PL7 processor, which is a central processing unit responsible for executing automation programs and managing communication between various devices in a control system.
  • Software Compatibility: The processor is designed to work seamlessly with the PL7 Junior/Pro software suite, providing a powerful platform for programming and configuring automation tasks.
  • Rack and Slot Capacity: The processor supports up to 16 racks with varying slot configurations. It can accommodate up to 128 slots, allowing for the integration of numerous input/output modules and communication interfaces.
  • I/O Capacity: The processor offers robust discrete and analog I/O capabilities. It can handle up to 2040 discrete I/O points and up to 256 analog I/O points, providing flexibility for various automation tasks.
  • Communication Options: The TSXP57453AM is equipped with versatile communication features, including a Fipio manager with 127 agents, non-isolated serial links, CANopen, network modules, Fieldbus modules, and AS-Interface bus modules. These communication options enable seamless data exchange and coordination within the control system.
  • Memory and Performance: The processor boasts ample memory resources for efficient program execution and data storage. It includes internal RAM (with or without a PCMCIA card) and a PCMCIA card for additional data storage. It supports various object areas for storing different types of data.
  • Execution Time and Performance: The TSXP57453AM processor delivers impressive execution times per instruction, allowing for rapid and responsive control tasks. It can handle various instruction types, such as Boolean, fixed-point arithmetic, and floating-point arithmetic, with varying execution times.
  • Status Indicators: The processor features a set of LED indicators that provide visual feedback on its status. These indicators include green LEDs for processor running (RUN), red LEDs for activity on the Fipio bus (FIP), I/O module or configuration fault (I/O), and processor or system fault (ERR), as well as a yellow LED for activity on the terminal port (TER).
  • Environmental Considerations: The processor is designed to operate effectively within specified environmental conditions. It can withstand a wide range of temperatures, from 32 to 140 °F (0 to 60 °C) during operation and -13 to 158 °F (-25 to 70 °C) during storage. It is also designed to handle relative humidity levels of 10 to 95% without condensation for operation and 5 to 95% without condensation for storage.
  • Safety and Compliance: The TSXP57453AM processor is compliant with various safety and regulatory standards, including RoHS compliance. It has an IP20 degree of protection, making it suitable for use in various industrial settings.

Conclusion:

The TSXP57453AM double-format PL7 processor is a key component of Schneider Electric's Modicon Premium Automation platform, designed to provide robust automation and control capabilities for industrial applications. With its versatile communication options, memory capacity, execution performance, and status indicators, this processor offers a comprehensive solution for managing complex automation tasks. Its adherence to safety standards and environmental considerations further enhance its suitability for use in a variety of industrial settings, making it a valuable tool for optimizing automation processes and enhancing operational efficiency.
