140CHS11000

140CHS11000

Rated 5/5 on 3 reviews

Rate this product


MANUFACTURER: SCHNEIDER ELECTRIC

DESCRIPTION: Hot Standby S911

PRODUCT TYPE INFO: Modicon Quantum



12 in stock
Ships Today

Free Shipping
2 Year warranty

Categories

Part Number140CHS11000
ManufacturerSchneider Electric
SeriesModicon Quantum
Model #140CHS11000
Alternate Model140-CHS-110-00
TypeIO Modules
Warranty2 Year
Accessory / separate part destinationI/O module
Product or componentHot standby module
type
Software designationProWORX 32 NxT V2.0
Concept >= V2.0
Input/Output type800 Series
Quantum
Sy/Max (remote I/O only)
Transmission rate10 Mbit/s
Transmission support mediumFiber optic 3 m
Switching time13...48 ms
Electrical connection1 connector RJ45 for fiber optic transmitter
1 connector RJ45 for fiber optic receiver
Local signalling1 LED red communication error
1 LED green ready module
1 LED green control process
1 LED green communication with I/O module
1 LED amber module in standby
Bus current requirement700 mA

Our Repair Services

MRO Electric repairs CNCs, PLCs, Servo/Spindle Drives, Motors, Amplifiers, VFDs, HMIs, and more, most of which can be repaired in only 3-5 days.

Repair Benefits

MRO can restore your failed 140CHS11000 to remanufactured condition and save you up to 75% compared to buying new. We offer standard repair pricing to ensure you the best value for your repair.

Our certified technicians use rigorous testing procedures to ensure your parts are restored to fully functioning condition. Our team proudly stands behind all repairs by providing a minimum 2 year warranty.

Our technicians have vast experience with most manufacturers and models. In addition to this 140CHS11000 we also repair drives, motors, PLCs and more, so if you don’t see the model you need, please contact us.

Core Exchange

If you are interested in getting credit for your faulty 140CHS11000, just let us know and we can issue you an RMA to send it in as an exchange. Our exchange program provides you with savings and keeps us stocked for the next time you need anything.

  • Shipping Weight : 1lb

Want it shipped today?

  • Order within the next 12 minutes.
  • If you order between 4pm and 6pm EST, you will be charged a small rush fee.

Ask about exchanging your faulty 140CHS11000 for credit when ordering from MRO Electric

MRO Electric provides a 2-year warranty on every item we sell and repair. We stand behind all of our products and guarantee them for the full 2 years. If there is an issue with any of our products within the warranty period, we will evaluate the unit and repair or replace it under warranty.

Additional Information

Schneider Electric 140CHS11000 Overview

The Modicon 140CHS11000 is manufactured by Schneider Electric and is a part of the Modicon Quantum system. The use of Quantum communication and network modules is necessary to interface with the Quantum controller.  Communication and networking are done through the Quantum system local backplane.  Through the backplane, high-speed data is transferred to and from the communication and networking modules.  It helps to maximize performance. The 140CHS11000 is an Intelligent / Special purpose module on the Modicon Quantum system called a Hot Standby unit.  The Hot Standby unit is designed specifically for use on the Quantum system with remote I/O networks.  It is implemented during times when downtime can not be permitted. It is used to determine the synchronization of the PCU and I/O scans.

Features

The Modicon 140CHS11000 has many useful features available on the front of the unit.  At the front top of the module is the LED display.Immediately above the LED display is where the model number and the module description are located. The modules and description are color-coded. Below the LED display you will find the key switch.  Just beneath the key switch is the A/B designation slide switch.  The program update button is below the A/B designation slide switch. Next, you will find the transmit cable connector followed by the receive cable connector.

There is a removable door available for this unit that covers several of these features.  The removable door covers the key switch, the A/B designation slide switch, the program update button, the transmit cable connector, and the receive cable connector. You can also add a customer identification label to the door.

Advantages

The Schneider Electric 140CHS11000 gives you Quantum I/O communication and two transmit and receive fiber optic communication ports.  It is compatible with Modsoft V2.32 or Concept 2.0 programming software at a minimum. The bus current required for the 140CHS11000 Hot Standby unit is 700 mA.

How to use the 140CHS11000

There are five LED indicators on the Modicon 140CHS11000: Ready, Com Act, Primary, Comm Err, and Standby.

The Ready LED indicator is green in color and indicates power is being supplied to the module.It also lets you know it passed the initial internal diagnostic tests.  It will stay steady green if both of these things are happening.  It will blink green if it is trying to recover from an interface error.  The next LED is Com Act. It is also green and indicates the CHS 110 module is communicating.

If it is blinking, there is an error detected.  Primary is the next LED and it is also green and indicates that the module is supporting the primary controller. Next is Com Err which is red.  If the Com Err red light is on, it is indicating the module is retrying communication or it has detected a communication failure.  The final LED is the Standby which is amber in color.  The Standby LED will be steady when the module is supporting the standby controller, which is ready to take the primary role if necessary.

The Schneider Electric 140CHS11000 comes with a two-year warranty.

Product Description

The 140CHS11000 is a Hot Standby S911 that is manufactured by Schneider Electric. These products are manufactured in France and are designed for Material handling, packaging, and textile machines usage. All of the products in the modicon-quantum line come with a 2 year warranty from MRO Electric. We also carry PLC from other manufacturers such as Modicon and ABB.
