140CPU65160

2-year Warranty

Same Day Shipping

Schneider Electric 140CPU65160

MODICON QUANTUM UNITY PROCESSOR - 1024 KB - 266MHZ

5/5
5 ratings

Select Condition

Refurbished

Request Quote

New

1 in stock

$10,913.00

Request a formal quote

  • Ships Today
  • 2 Year Warranty
  • Free Shipping
Part Number140CPU65160
ManufacturerSchneider Electric
TypeCPUs
Model #140-CPU-651-60
Warranty2 Year
Electrical connection1 female connector, connector type: SUB-D 9 for connecting to the Modbus Plus
network
1 connector, connector type: RJ45 for connecting Modbus bus
1 connector, connector type: RJ45 for connecting Ethernet network
1 connector, connector type: MT-RJ (fiber optic) for interconnecting primary and
secondary PLCs (hot standby architecture)
Product or componentUnity processor
Clock frequency266 MHz
Number of slots10
16
2
4
6
Number of racks2 - local rack(s)
Number of distributed I/O station63 station(s) - 1 rack(s) - 3 distributed network(s)
Number of remote I/O station31 - 2 remote rack(s)
Discrete I/O number8000 inputs, 8000 outputs - distributed - per network
31744 inputs, 31744 outputs - remote
Unlimited (26 slots max) - local
Analogue I/O numberUnlimited (26 slots max) - local
500 inputs, 500 outputs - distributed - per network
1984 inputs,1984 outputs - remote
Application specific I/OAccurate time stamping
Counter
High-speed interrupt inputs
Serial link
Number of optional modules6 (Ethernet, Modbus, Modbus Plus, Profibus DP, Sy/Max)
Maximum number of connectionsUnlimited (AS-Interface) - local
6 (Profibus DP) - local
6 (Modbus Plus) - local
6 (Ethernet TCP/IP) - local
4 (AS-Interface) - remote
2 (AS-Interface) - distributed
1 (USB)
1 (Modbus) - RS232/485 Modbus/ASCII
Integrated connection type1 Ethernet TCP/IP
1 Modbus
1 Modbus Plus
1 USB
ChecksProcess control
Memory descriptionInternal RAM 1024 kB
Expandable 8 MB - file storage with PCMCIA card
Expandable 7168 kB - program with PCMCIA card
Switch functionKey switch memory port on/off
Application structure4 auxiliary tasks
32 timer interrupt tasks
128 interrupt tasks
128 I/O interrupt tasks
1 periodic fast task
1 cyclic/periodic master task
Execution time per instruction0.4...0.5 µs floating points
0.0525...0.075 µs Boolean
0.045...0.06 µs on word
0.045...0.06 µs on fixed-point arithmetic
Execution time for 1 K instruction10.28 100 % Boolean
10.07 65 % Boolean and 35 % numerical
System overhead1 ms - master task
0.2 ms - fast task
Bus current requirement2760 mA
Local signalling1 LED red for Ethernet collision
1 LED green for Ethernet activity (COM)

Our Repair Services

MRO Electric repairs CNCs, PLCs, Servo/Spindle Drives, Motors, Amplifiers, VFDs, HMIs, and more, most of which can be repaired in only 3-5 days.

Repair Benefits

MRO can restore your failed 140CPU65160 to remanufactured condition and save you up to 75% compared to buying new. We offer standard repair pricing to ensure you the best value for your repair.

Our certified technicians use rigorous testing procedures to ensure your parts are restored to fully functioning condition. Our team proudly stands behind all repairs by providing a minimum 2-year warranty.

Our technicians have vast experience with most manufacturers and models. In addition to this 140CPU65160 we also repair drives, motors, PLCs and more, so if you don’t see the model you need, please contact us.

Core Exchange

If you are interested in getting credit for your faulty 140CPU65160, just let us know, and we can issue you an RMA to send it in as an exchange. Our exchange program provides you with savings and keeps us stocked for the next time you need anything.

  • Shipping Weight : 3lbs

Want it shipped today?

  • Order within the next 11 hours and 5 minutes.
  • If you order between 4pm and 6pm EST, you will be charged a small rush fee.

Ask about exchanging your faulty 140CPU65160 for credit when ordering from MRO Electric

MRO Electric provides a 2-year warranty on every item we sell and repair. We stand behind all of our products and guarantee them for the full 2 years. If there is an issue with any of our products within the warranty period, we will evaluate the unit and repair or replace it under warranty.

Schneider Electric 140CPU65160 Overview

Schneider Electric 140CPU65160 Unity Processor

The Schneider Electric 140CPU65160 is a powerful Unity processor designed for industrial control and automation applications. As a critical control system component, it offers advanced features and versatile connectivity options to meet the demands of modern industrial environments.

Advanced Connectivity Options:

Equipped with various connectors, the 140CPU65160 facilitates seamless integration into different network architectures. It includes a female SUB-D 9 connector for Modbus Plus network connection, RJ45 connectors for Modbus and Ethernet networks, and MT-RJ fiber optic connector for interconnecting primary and secondary PLCs in hot standby architecture. These connections enable efficient data exchange and communication between devices, enhancing system flexibility and scalability.

Versatile Input/Output Configuration:

With extensive input/output capabilities, the 140CPU65160 supports diverse control requirements. It offers 8000 inputs and 8000 outputs for distributed configurations per network, 31744 inputs and outputs for remote configurations, and unlimited options for local setups. Additionally, it provides analog I/O support and application-specific features such as accurate time stamping, counters, and high-speed interrupt inputs, catering to a wide range of industrial processes.

Expandable Modular Design:

The 140CPU65160's modular design allows for easy expansion and customization according to specific application needs. It supports up to 10 slots for optional modules, including Ethernet, Modbus, Modbus Plus, Profibus DP, and Sy/Max, enabling users to enhance functionality and quickly adapt to evolving requirements.

Robust Performance and Execution:

Powered by a 266 MHz clock frequency, the 140CPU65160 delivers robust performance and high-speed processing capabilities. It supports multiple tasks and interrupts, with execution times as low as 0.4 to 0.5 microseconds for floating-point operations and 0.045 to 0.06 microseconds for Boolean and fixed-point arithmetic, ensuring efficient control and responsiveness in real-time applications.

Reliable Memory and Storage:

The 140CPU65160 features internal RAM of 1024 kB and expandable memory options up to 8 MB for file storage and 7168 kB for program storage using PCMCIA cards. This ample memory capacity allows for the storage of programs, data, and configuration settings, ensuring reliable operation and data integrity.

Efficient System Management:

With built-in system management features, including essential switch memory port control and LED indicators for Ethernet activity and collision detection, the 140CPU65160 facilitates efficient system monitoring and diagnostics. Users can easily manage system resources and troubleshoot issues to maintain optimal performance and uptime.

Frequently Asked Questions

Q: What is the Schneider Electric 140CPU65160 Unity Processor? A: The Schneider Electric 140CPU65160 is a Unity Processor designed for industrial control and automation applications. It is a central processing unit within a control system, providing advanced functionality and connectivity options for managing industrial processes.

Q: What are the connectivity options offered by the 140CPU65160? A: The 140CPU65160 features multiple connectors, including SUB-D 9 for Modbus Plus network, RJ45 for Modbus and Ethernet networks, and MT-RJ fiber optic for hot standby PLC interconnection. These connections enable seamless integration into various network architectures, facilitating efficient data exchange and communication.

Q: What are the 140CPU65160's input/output capabilities? A: The 140CPU65160 supports extensive input/output configurations, including 8000 inputs and outputs for distributed setups per network, 31744 inputs and outputs for remote configurations, and unlimited options for local setups. It also supports analog I/O and application-specific features like time stamping and counters.

Q: Can the 140CPU65160 be expanded or customized? A: Yes, the 140CPU65160 features a modular design that supports up to 10 optional modules, such as Ethernet, Modbus, Modbus Plus, Profibus DP, and Sy/Max. This allows users to expand functionality and customize the processor according to specific application requirements.

Q: What is the 140CPU65160's performance? A: The 140CPU65160 is powered by a 266 MHz clock frequency, delivering robust performance and high-speed processing capabilities. It supports multiple tasks and interrupts, with execution times as low as 0.4 to 0.5 microseconds for floating-point operations, ensuring efficient control and responsiveness in real-time applications.

Q: How does the 140CPU65160 manage memory and storage? A: The 140CPU65160 features internal RAM of 1024 kB and expandable memory options up to 8 MB for file storage and 7168 kB for program storage using PCMCIA cards. This ample memory capacity allows storing programs, data, and configuration settings, ensuring reliable operation and data integrity.

Q: What system management features are available on the 140CPU65160? A: The 140CPU65160 includes system management features such as essential switch memory port control and LED indicators for Ethernet activity and collision detection. These features facilitate efficient system monitoring and diagnostics, enabling users to manage resources and troubleshoot issues effectively.
