140EIA92100

2-year Warranty

Same Day Shipping

Schneider Electric 140EIA92100

MODICON QUANTUM AS-INTERFACE MASTER MODULE- 30 V DC

5/5
2 ratings

1 Available


Free Shipping

2 Year warranty

Part Number140EIA92100
ManufacturerSchneider Electric
TypeI/O Modules
Model #140-EIA-921-00
Warranty2 Year
Module formatStandard
Product or component typeAS-Interface master module
Range compatibilityAS-Interface cabling system
AS-i versionV1
AS-i profileM2
AddressingStandard
Cycle time<= 5 ms
Bus length<= 100 m without repeater
Discrete input number<= 124
Discrete output number<= 124
Number of slave<= 31
Number of module per PLC2 per Quantum PLC distributed drop
4 per Quantum PLC local drop
4 per Quantum PLC remote drop
SupplyVia AS-Interface line
[Us] rated supply voltage30 V DC
AS-i cabling system cycle time156 x (n + 1) µs 31
156 x (n + 2) µs
Transmission rate167 kbit/s
Reverse polarity protectionInternal
Local signalling32 LEDs slave addresses and state of slave I/O bits
Electrical connection1 male connector SUB-D 3 pins AS-Interface link
Current consumption<= 100 mA
Typical current consumption60 mA 30 V DC

Our Repair Services

MRO Electric repairs CNCs, PLCs, Servo/Spindle Drives, Motors, Amplifiers, VFDs, HMIs, and more, most of which can be repaired in only 3-5 days.

Repair Benefits

MRO can restore your failed 140EIA92100 to remanufactured condition and save you up to 75% compared to buying new. We offer standard repair pricing to ensure you the best value for your repair.

Our certified technicians use rigorous testing procedures to ensure your parts are restored to fully functioning condition. Our team proudly stands behind all repairs by providing a minimum 2-year warranty.

Our technicians have vast experience with most manufacturers and models. In addition to this 140EIA92100 we also repair drives, motors, PLCs and more, so if you don’t see the model you need, please contact us.

Core Exchange

If you are interested in getting credit for your faulty 140EIA92100, just let us know, and we can issue you an RMA to send it in as an exchange. Our exchange program provides you with savings and keeps us stocked for the next time you need anything.

  • Shipping Weight : 1lb

Want it shipped tomorrow?

  • Order within the next 21 hours and 40 minutes.
  • If you order between 4pm and 6pm EST, you will be charged a small rush fee.

Ask about exchanging your faulty 140EIA92100 for credit when ordering from MRO Electric

What is the max length of the bus for the 140EIA92100 AS-i module?

  • The max buss length is 100m but can be extended up to 300m using repeaters.

What is the max length of the bus for the 140EIA92100 AS-i module?

  • The max buss length is 100m but can be extended up to 300m using repeaters.
MRO Electric provides a 2-year warranty on every item we sell and repair. We stand behind all of our products and guarantee them for the full 2 years. If there is an issue with any of our products within the warranty period, we will evaluate the unit and repair or replace it under warranty.

Schneider Electric 140EIA92100 Overview

Schneider Electric 140EIA92100 AS-Interface Master Module

Schneider Electric presents the 140EIA92100, a versatile AS-Interface master module that facilitates seamless communication and control in industrial automation systems. As part of Schneider Electric's comprehensive range of I/O modules, this master module offers advanced features and reliable performance for various applications.

Comprehensive Module Format

The 140EIA92100 master module adopts a standard format, ensuring compatibility with various automation systems and components. Its standardized design simplifies installation and integration, allowing seamless deployment in diverse industrial environments.

AS-Interface Compatibility

Compatible with the AS-Interface cabling system, the 140EIA92100 master module provides robust connectivity and communication capabilities. It supports AS-i version V1 and AS-i profile M2, ensuring interoperability with AS-Interface devices and peripherals for efficient data exchange and control.

Enhanced Performance Specifications

Featuring a cycle time of less than or equal to 5 ms, the 140EIA92100 master module delivers rapid and responsive performance, enabling real-time control and monitoring of connected devices. With a maximum bus length of 100 m without a repeater, it offers flexibility in system configuration and expansion.

Flexible I/O Configuration

The 140EIA92100 master module supports a maximum of 124 discrete inputs and 124 discrete outputs, providing ample I/O capacity for diverse automation applications. With support for up to 31 slave devices, it allows for scalable and customizable system configurations to meet specific operational requirements.

Reliable Power Supply

The 140EIA92100 master module receives power via the AS-Interface line, eliminating the need for additional power sources and simplifying wiring and installation. With a rated supply voltage of 30 V DC and reverse polarity protection, it ensures reliable and safe operation in industrial environments.

Advanced Communication Capabilities

Equipped with a transmission rate of 167 kbit/s, the 140EIA92100 master module facilitates high-speed data transmission and communication between devices. Its robust communication protocol ensures reliable data exchange and minimal latency for optimal system performance.

User-Friendly Interface

The 140EIA92100 master module features 32 LEDs for local signaling, providing visual feedback on slave addresses and the state of slave I/O bits. This intuitive interface enhances usability and facilitates troubleshooting, allowing for quick identification of system status and errors.

Easy Installation and Configuration

With a convenient electrical connection using a male connector SUB-D 3 pins AS-Interface link, the 140EIA92100 master module offers easy installation and wiring. Its low current consumption of less than or equal to 100 mA ensures efficient use of power resources, minimizing operating costs.

Versatile Application Support

The 140EIA92100 master module suits various industrial automation applications, including manufacturing, process control, and material handling. Its versatile capabilities, reliable performance, and flexible configuration options make it ideal for optimizing efficiency and productivity in diverse industrial settings.

Frequently Asked Questions

What is the Schneider Electric 140EIA92100 AS-Interface Master Module?

The Schneider Electric 140EIA92100 is an AS-Interface master module for industrial automation systems. It facilitates communication and control between various system devices and offers advanced features and reliable performance.

What are the key specifications of the 140EIA92100 module?

The 140EIA92100 module supports AS-i version V1 and AS-i profile M2. Its cycle time is less than or equal to 5 ms, the maximum bus length is 100 m without a repeater, and it supports up to 124 discrete inputs and outputs. It also has a transmission rate of 167 kbit/s and operates on a rated supply voltage of 30 V DC.

What industries can benefit from the 140EIA92100 module?

The 140EIA92100 module suits various industries, including manufacturing, process control, and material handling. It can be used in applications requiring reliable communication and control of devices within an industrial automation system.

How does the 140EIA92100 module enhance system performance?

The 140EIA92100 module offers rapid cycle times, high-speed data transmission, and reliable power supply, enhancing system performance and responsiveness. Its flexible I/O configuration, user-friendly interface, and easy installation further improve industrial automation applications' efficiency.

What service and support options are available for the 140EIA92100 module?

Schneider Electric provides comprehensive support for the 140EIA92100 module, including installation assistance, technical support, and maintenance services. Additionally, the module comes with a warranty to ensure reliability and peace of mind for users.
