MODICON MOMENTUM - MODBUS PLUS COMMUNICATION ADAPTOR
| Part Number | 170PNT16020 |
| Manufacturer | Schneider Electric |
| Type | Accessories |
| Model # | 170-PNT-160-20 |
| Warranty | 2 Year |
| Electrical connection | 1 connector SUB-D 9 for connecting Modbus Plus network |
| 1 connector SUB-D 9 for redundant Modbus Plus network | |
| Range of product | Modicon Momentum automation platform |
| Product or component type | Modbus Plus communication adaptor |
| Bus manager PLC | Quantum |
| Structure type | Industrial |
| Communication port protocol | Modbus Plus |
| Method of access | Token bus |
| Peer to peer | |
| Transmission rate | 1 Mbit/s |
| Transmission support medium | Twisted pair |
| Redundancy | Yes |
| Topology | Multidrop, device connecting by extension or tap off cable |
| Number of devices | 0...31 per segment |
| 0...63 all segment | |
| Cable length | <= 16404.2 ft (5000 m) with repeater |
| Data format | IEC 61131-2 |
| Fail state | Fallback to zero |
| Forcing to state zero | |
| Full scale value | |
| Maintain value | |
| Supply | From I/O base |
| Marking | CE |
| Local signalling | 1 LED green module powered up or communicating (MB + ACT) |
| 1 LED red communication error network A (ERR A) | |
| 1 LED red communication error network B (ERR B) |
MRO Electric repairs CNCs, PLCs, Servo/Spindle Drives, Motors, Amplifiers, VFDs, HMIs, and more, most of which can be repaired in only 3-5 days.
MRO can restore your failed 170PNT16020 to remanufactured condition and save you up to 75% compared to buying new. We offer standard repair pricing to ensure you the best value for your repair.
Our certified technicians use rigorous testing procedures to ensure your parts are restored to fully functioning condition. Our team proudly stands behind all repairs by providing a minimum 2-year warranty.
Our technicians have vast experience with most manufacturers and models. In addition to this 170PNT16020 we also repair drives, motors, PLCs and more, so if you don’t see the model you need, please contact us.
If you are interested in getting credit for your faulty 170PNT16020, just let us know, and we can issue you an RMA to send it in as an exchange. Our exchange program provides you with savings and keeps us stocked for the next time you need anything.
Want it shipped today?
Ask about exchanging your faulty 170PNT16020 for credit when ordering from MRO Electric
Reliable Communication for Industrial Automation
The Schneider Electric 170PNT16020 is a reliable and high-performance Modbus Plus communication adapter, explicitly designed for the Modicon Momentum automation platform. Also known by its model number 170-PNT-160-20, this industrial-grade accessory plays a critical role in enabling advanced network connectivity and communication between devices within automation systems. It provides a powerful link between I/O bases and Quantum PLCs, making it an essential component in complex Modbus Plus networks that demand reliability, speed, and redundancy.
This communication adapter features two SUB-D 9-pin connectors, one for standard Modbus Plus network communication and another for redundant networking. This dual-port design ensures continuous operation and increases system reliability in critical industrial environments. With support for redundant network topologies, the 170PNT16020 is capable of maintaining operations even in the event of a partial network failure, making it an ideal solution for industries requiring high availability and reduced downtime.
Operating on a token bus protocol, this adapter enables peer-to-peer communication and achieves a transmission rate of 1 Mbit/s over a twisted-pair cable. It supports multiple topologies, including multidrop configurations and device connection through extension or tap-off cables. Each segment of the network can include up to 31 devices, with a total of up to 63 devices supported across all segments when using repeaters. The maximum supported cable length is an impressive 5,000 meters (16,404.2 feet), allowing for expansive network layouts across extensive facilities.
The 170PNT16020 is designed to handle fault conditions gracefully, supporting fail states such as fallback to zero, forcing to zero state, full-scale value, or maintaining the last value. This capability ensures that even in adverse conditions, system behavior can be predicted and managed to avoid unsafe states or unnecessary shutdowns.
The device draws its power directly from the I/O base, making installation clean and streamlined with minimal additional wiring. Explicit local signaling is provided via integrated LEDs, including a green LED that indicates module power or activity and two red LEDs for communication errors on network A and network B. This built-in status indication enables quick diagnostics and system monitoring, allowing maintenance personnel to identify and resolve issues more efficiently.
Certified with CE marking and compliant with IEC 61131-2 standards, the 170PNT16020 meets the requirements of modern industrial automation environments. Available from MRO Electric and Supply, this communication adapter comes with a 2-year warranty and qualifies for free shipping, ensuring fast delivery and peace of mind. Whether you're upgrading an existing system or building a new automation architecture, this adapter delivers robust connectivity and dependable performance.
What is the function of the 170PNT16020 module?
It serves as a Modbus Plus communication adapter for Modicon Momentum systems.
Does it support network redundancy?
Yes, it includes dual ports for redundant Modbus Plus network configurations.
Can it communicate with Quantum PLCs?
Yes, it is designed to interface with Quantum PLCs as the bus manager.
What is the communication speed of this adapter?
It operates at a data rate of 1 Mbit/s.
What cable type is required?
It uses twisted pair cable for transmission.
How many devices can be connected?
Up to 31 devices per segment and a total of 63 devices, including repeaters.
What kind of topologies are supported?
Multidrop topologies with connections via extension or tap-off cables are supported.
What power supply does it require?
The module is powered directly from the I/O base.
Are diagnostics available on the module?
Yes, it includes LEDs for power, communication status, and error indication.
Is this adapter available for immediate shipping?
Yes, MRO Electric offers it in stock with free shipping and a 2-year warranty.
