171CCS76000

2-year Warranty

Same Day Shipping

Schneider Electric 171CCS76000

MODICON COMMUNICATION M1/M1E PROCESSOR ADAPTOR - 1 MODBUS, 1 I/O BUS - 20 MHZ

5/5
3 ratings

Select Condition

Refurbished

7 in stock

New

1 in stock

$479.00

Request a formal quote

  • Ships Today
  • 2 Year Warranty
  • Free Shipping
Part Number171CCS76000
ManufacturerSchneider Electric
TypeCPUs
Warranty2 Year
MarkingCE
Range of productModicon Momentum automation platform
Product or component typeM1/M1E processor adaptor
Software designationConcept V2.6
Modsoft >= V2.5
ProWORX 32
ProWORX NxT V2.0
Communication port protocolModbus
Processor nameX 86 based (INTEL, AMD)
Clock frequency32 MHz
Discrete I/O processor capacity2048 I/2048 O
Memory typeFlash 256 kB
RAM 256 kB
Memory descriptionData 4 kB
Program memory 12 kB LL984
Program memory 160 kB IEC
MaterialLexan
Word length16 bit
[Us] rated supply voltage5.0 V DC +/-5 %
SupplyBy Momentum I/O base
Exact time for 1 K instruction1 ms
Register I/O processor capacity4096 words total
I/O limit processor capacity8192 bits max
I/O words/drop128 I/O Concept
80 I/O ProWORX
Number of port1 I/O bus
1 RS232C non isolated

Our Repair Services

MRO Electric repairs CNCs, PLCs, Servo/Spindle Drives, Motors, Amplifiers, VFDs, HMIs, and more, most of which can be repaired in only 3-5 days.

Repair Benefits

MRO can restore your failed 171CCS76000 to remanufactured condition and save you up to 75% compared to buying new. We offer standard repair pricing to ensure you the best value for your repair.

Our certified technicians use rigorous testing procedures to ensure your parts are restored to fully functioning condition. Our team proudly stands behind all repairs by providing a minimum 2-year warranty.

Our technicians have vast experience with most manufacturers and models. In addition to this 171CCS76000 we also repair drives, motors, PLCs and more, so if you don’t see the model you need, please contact us.

Core Exchange

If you are interested in getting credit for your faulty 171CCS76000, just let us know, and we can issue you an RMA to send it in as an exchange. Our exchange program provides you with savings and keeps us stocked for the next time you need anything.

  • Shipping Weight : 1lb

Want it shipped today?

  • Order within the next 7 hours and 2 minutes.
  • If you order between 4pm and 6pm EST, you will be charged a small rush fee.

Ask about exchanging your faulty 171CCS76000 for credit when ordering from MRO Electric

MRO Electric provides a 2-year warranty on every item we sell and repair. We stand behind all of our products and guarantee them for the full 2 years. If there is an issue with any of our products within the warranty period, we will evaluate the unit and repair or replace it under warranty.

Schneider Electric 171CCS76000 Overview

Schneider Electric 171CCS76000 Modicon Momentum M1/M1E Processor Adapter

The Schneider Electric 171CCS76000 is a processor module designed for the Modicon Momentum automation platform. As an integral component in industrial automation systems, it facilitates efficient and precise control of large-scale operations by serving as the central processing unit (CPU) for connected devices and networks. This processor adapter is widely used across various industrial applications and has robust processing capabilities and versatile communication options.

Processor Capabilities and Performance

At the core of the Schneider Electric 171CCS76000 is an Intel or AMD X86-based processor, operating at a clock frequency of 32 MHz. This ensures fast and reliable performance across a wide range of tasks. The CPU can execute instructions with precision and speed, with an exact time of 1 millisecond for 1 K instruction. This fast execution makes the processor highly effective in industrial applications requiring real-time data processing and quick response times.

Regarding I/O handling, the processor can accommodate up to 2048 discrete inputs and 2048 discrete outputs, providing significant capacity for large-scale operations. Additionally, the processor’s I/O word capacity extends to 128 I/O words for Concept software users and 80 I/O words for ProWORX users, offering flexibility depending on the software and operational setup. The processor also supports up to 4096 words for register I/O processing, with a total I/O limit capacity of 8192 bits, making it suitable for complex automation tasks.

Memory and Storage

The Schneider Electric 171CCS76000 has a reliable memory architecture to ensure smooth operation and data handling. It features 256 kB of Flash memory for storing critical system data and configurations and 256 kB of RAM for fast, temporary data storage during operations. The processor also includes specific memory allocations for different programming languages: 12 kB for LL984 programs and 160 kB for IEC programming, which allows for greater versatility in how the system can be programmed and operated. In addition, four kB of memory is reserved for data storage, ensuring that essential system information can be retained efficiently.

Software Compatibility

This processor adapter is compatible with several industry-standard software packages, including Concept V2.6, Modsoft V2.5 or higher, ProWORX 32, and ProWORX NxT V2.0. These software platforms allow operators to program, control, and monitor the processor effectively, ensuring a smooth integration into existing automation systems.

Communication and Connectivity

Communication is facilitated through the Modbus protocol, which ensures reliable data exchange between the processor and connected devices. The 171CCS76000 features one I/O bus port and one RS232C non-isolated communication port, enabling connection to various input/output devices, control systems, and other components in the automation network. As the communication protocol, Modbus ensures compatibility with a wide range of industrial devices and systems, offering greater flexibility and integration potential in complex environments.

Design and Durability

The unit’s physical construction is made of durable Lexan material, which provides excellent resistance to environmental factors commonly encountered in industrial settings. The processor operates on a 5 V DC power supply with a tolerance of ±5% and receives power from the Momentum I/O base. The device is CE-marked, ensuring it meets essential safety and performance standards. It also has an IP20 protection rating, making it suitable for installation in controlled environments.

Warranty and Availability

Schneider Electric backs the 171CCS76000 processor module with a 2-year warranty, offering quality and reliability assurance. The product is available with free shipping from MRO Electric and Supply, ensuring that customers can receive and install it quickly and easily.

FAQ for Schneider Electric 171CCS76000 Modicon Momentum M1/M1E Processor Adapter

What type of processor does the 171CCS76000 use?

The Schneider Electric 171CCS76000 uses an X86-based processor, either Intel or AMD, with a clock frequency of 32 MHz.

What is the memory capacity of this processor module?

The 171CCS76000 has 256 kB of Flash memory and 256 kB of RAM. Additionally, it has a data memory of 4 kB and supports program memory of 12 kB for LL984 and 160 kB for IEC programming.

What communication protocol does the processor use?

The 171CCS76000 uses the Modbus communication protocol, which allows it to effectively connect and communicate with other industrial devices and systems.

How many inputs and outputs does the processor support?

The processor can handle up to 2048 discrete inputs and 2048 discrete outputs. It also supports a total register I/O capacity of 4096 words.

Which software is compatible with the 171CCS76000?

This processor module is compatible with several programming and control software packages, including Concept V2.6, Modsoft (version 2.5 or higher), ProWORX 32, and ProWORX NxT V2.0.

What is the power supply requirement for this module?

The 171CCS76000 operates on a 5 V DC power supply with a tolerance of ±5%. It receives power from the Momentum I/O base.

What is the maximum instruction execution time for the processor?

The processor has an execution time of 1 millisecond for 1 K instruction, ensuring fast and efficient performance.

How many communication ports are available?

The 171CCS76000 processor adapter features one I/O bus port and one RS232C non-isolated communication port for device connectivity.

What environmental conditions can the 171CCS76000 withstand?

The processor operates within a temperature range of 0 to 60°C during use and can be stored in temperatures ranging from -40 to 85°C. It also has an IP20 protection rating and can be installed at altitudes of up to 2000 meters, deriving up to 5000 meters.

Does the 171CCS76000 have any built-in protection features?

The module is CE-marked, ensuring it complies with essential safety and performance standards. The Lexan construction also provides durability, while the IP20 rating protects against dust and other particles.

Is there a warranty on the 171CCS76000?

Yes, the Schneider Electric 171CCS76000 comes with a 2-year warranty from MRO Electric and Supply, and it is available with free shipping.

What is the processor's inrush current?

The inrush current for the 171CCS76000 processor module is 30 A at 24 V.

This FAQ clarifies the main technical aspects and usage considerations for the Schneider Electric 171CCS76000 Modicon Momentum M1/M1E processor adapter.
