6SL3210-1KE18-8AF1

Siemens 6SL3210-1KE18-8AF1 Overview

The 6SL3210-1KE18-8AF1 AC Drive, manufactured by Siemens, is a versatile and powerful motor control device designed to drive three-phase AC motors. It boasts a maximum output frequency of 550 Hz for V/f control and 240 Hz for vector control, making it an ideal choice for a wide range of industrial applications.

Ratings

The AC drive has an input that can handle three-phase AC power with a line voltage of 380-480 V, a line frequency of 47-63 Hz, and a rated current of 11.40 A (LO) and 10.60 A (HO). The device also features a built-in line reactor that helps to protect the motor and the drive from any electrical disturbances in the power supply.

The AC drive can deliver up to 4.00 kW of rated power (LO) and 3.00 kW of rated power (HO) to a three-phase AC motor. It can handle a maximum output current of 14.60 A, making it suitable for use with a wide range of motors. The device features a pulse frequency of 4 kHz.

Features

One of the standout features of the 6SL3210-1KE18-8AF1 AC Drive is its ability to support both V/f and vector control modes. V/f control is the most common method of AC motor control, and it allows the motor to run at a constant speed regardless of the load. However, vector control is a more advanced technique that provides more precise control over the motor's speed and torque, making it an ideal choice for high-performance applications.

The AC drive is also designed to be easy to use and install. C cables for the motor are connected to the device, and the line filter is included as a base component, which means that it can be easily mounted on a surface to save space.

1. Output frequency for V/f control: This AC drive has an output frequency range of 0 to 550 Hz, making it suitable for a wide range of applications.
2. Input: The AC drive requires a 3-phase AC input, which makes it compatible with most industrial power systems. It has a line voltage range of 380 to 480 V with a tolerance of +10% to -20%, and a line frequency range of 47 to 63 Hz.
3. Rated current: The AC drive has a rated current of 11.4 A for LO (low overload) and 10.6 A for HO (high overload), which means that it can handle high currents for short periods without overheating.
4. Output: The AC drive has a 3-phase AC output with a rated voltage of 400 V. It has a rated power of 4.0 kW for LO and 3.0 kW for HO, which means it can provide high power output for a range of industrial applications. The rated current for IN (input) is 9.0 A, while the rated current for LO and HO is 8.8 A and 7.3 A.
5. Max. output current: The AC drive has a maximum output current of 14.6 A, which means it can provide high current output for short periods without overheating.
6. Pulse frequency: The AC drive has a pulse frequency of 4 kHz, which makes it suitable for a range of applications that require high precision and accuracy.
7. Output frequency for vector control: The AC drive has an output frequency range of 0 to 240 Hz for vector control, which makes it suitable for applications that require precise control over motor speed and torque.

Overall, the 6SL3210-1KE18-8AF1 AC Drive is a powerful and versatile device that is suitable for use in a wide range of industrial applications. With its support for both V/f and vector control modes, it provides precise and efficient motor control. It's easy-to-use design and two-year warranty make it a reliable choice for any industrial setting.

Product Description

The 6SL3210-1KE18-8AF1 is a G120C Compact Inverter, 3PH, 380-480V AC, 4.0kW, 5... that is manufactured by Siemens. These products are manufactured in Germany and are designed for Automotive, aerospace, power generation, and electronics usage. All of the products come with a 2 year warranty from MRO Electric. We also carry AC Drives from other manufacturers such as FANUC and Yaskawa.
