|Series||Modicon 984 Series|
|Description||24 Vac output|
|Number of Points||32|
|Operating Voltage||20 ... 28 Vac / 47 ... 63 Hz|
|Number of Groups||2|
|Outputs per Group||16|
|Max. per Point||1 A continuous|
|15 A one cycle|
|Max. per Group||8 A|
|Max. per Module||16 A|
|Leakage Current||2 mA (max.)|
|Max. Response Time|
|OFF to ON||8.3 ms @ 60 Hz|
|ON to OFF||8.3 ms @ 60 Hz|
|+5 V||210 mA|
|+4.3 V||1 mA|
|-5 V||0 mA|
|Space Required||1 slot|
|Weight||2.49 lbs (1.13 kg)|
MRO Electric repairs CNCs, PLCs, Servo/Spindle Drives, Motors, Amplifiers, VFDs, HMIs, and more, most of which can be repaired in only 3-5 days.
MRO can restore your failed AS-B806-124 to remanufactured condition and save you up to 75% compared to buying new. We offer standard repair pricing to ensure you the best value for your repair.
Our certified technicians use rigorous testing procedures to ensure your parts are restored to fully functioning condition. Our team proudly stands behind all repairs by providing a minimum 12-month warranty.
Our technicians have vast experience with most manufacturers and models. In addition to this AS-B806-124 we also repair drives, motors, PLCs and more, so if you don’t see the model you need, please contact us.
If you are interested in getting credit for your faulty AS-B806-124, just let us know and we can issue you an RMA to send it in as an exchange. Our exchange program provides you with savings and keeps us stocked for the next time you need anything.
This product weighs 3lbs. Want it shipped today?
Ask about exchanging your faulty AS-B806-124 for credit when ordering from MRO Electric
Check out the rest of our Schneider Electric product line. Whether it's using our online instant quote feature, giving us a call, or sending us an email, we strive for customer satisfaction first. This means lower prices and better service for you. For more products like AS-B806-124, take a look at more from our Modicon 984 Series line. If your current unit has gone bad, take advantage of our Core Exchange program for the most inexpensive route. We offer a repair service on all of our products that keep your downtime to a minimum. To stay up to date on manufacturer news, as well as access any of our datasheets, manuals, or other documentation, we suggest you take a look at our blog.
