AS-B872-100

2-year Warranty

Same Day Shipping

Schneider Electric AS-B872-100

MODICON 984 SERIES 800-SERIES I/O MODULE, ANALOG OUT, D/A: 4-20 MA, 4 PNTS

5/5
1 rating

Select Condition

Refurbished

4 in stock

New

1 in stock

$397.00

Request a formal quote

  • Ships Today
  • 2 Year Warranty
  • Free Shipping
Part NumberAS-B872-100
ManufacturerSchneider Electric
TypeI/O Modules
Model #ASB872100
Warranty2 Year
Terminal ConnectorAS-8535-000
DescriptionD/A; 4 ... 20 mA
Number of Channels4
Operating Range4 ... 20 mA
Max. Loop Supply Voltage60 Vdc
Resolution12 bit
Accuracy± 0.1% of full scale at 25°C
Linearity0 to 60°C, ± 1 LSB
Update Times<1 ms, all 4 channels
Isolation
Channel to Channel1000 V continuous
Channel to Case1000 V continuous
Channel to Module1000 V continuous
Power Required
+5 V475 mA
+4.3 V5 mA
-5 V0 mA
Space Required1 slot
Weight3 lbs (1.4 kg)

Our Repair Services

MRO Electric repairs CNCs, PLCs, Servo/Spindle Drives, Motors, Amplifiers, VFDs, HMIs, and more, most of which can be repaired in only 3-5 days.

Repair Benefits

MRO can restore your failed AS-B872-100 to remanufactured condition and save you up to 75% compared to buying new. We offer standard repair pricing to ensure you the best value for your repair.

Our certified technicians use rigorous testing procedures to ensure your parts are restored to fully functioning condition. Our team proudly stands behind all repairs by providing a minimum 2-year warranty.

Our technicians have vast experience with most manufacturers and models. In addition to this AS-B872-100 we also repair drives, motors, PLCs and more, so if you don’t see the model you need, please contact us.

Core Exchange

If you are interested in getting credit for your faulty AS-B872-100, just let us know, and we can issue you an RMA to send it in as an exchange. Our exchange program provides you with savings and keeps us stocked for the next time you need anything.

  • Shipping Weight : 1lb

Want it shipped today?

  • Order within the next 10 hours and 30 minutes.
  • If you order between 4pm and 6pm EST, you will be charged a small rush fee.

Ask about exchanging your faulty AS-B872-100 for credit when ordering from MRO Electric

MRO Electric provides a 2-year warranty on every item we sell and repair. We stand behind all of our products and guarantee them for the full 2 years. If there is an issue with any of our products within the warranty period, we will evaluate the unit and repair or replace it under warranty.

Schneider Electric AS-B872-100 Overview

Schneider Electric AS-B872-100: Precision I/O Modules for Industrial Automation

The Schneider Electric AS-B872-100 is a testament to precision and reliability in the realm of industrial automation I/O modules. Designed to meet the rigorous demands of modern manufacturing environments, this module offers exceptional performance and versatility, making it an indispensable asset for process control and monitoring applications.

High-Quality Terminal Connector:

Equipped with the AS-8535-000 terminal connector, the AS-B872-100 ensures secure and reliable connections for seamless integration into automation systems. This high-quality connector facilitates quick and easy installation, minimizing downtime and maximizing productivity in industrial environments.

Analog Output Capabilities:

The AS-B872-100 is a D/A (digital-to-analog) module capable of converting digital signals into analog outputs within the range of 4 to 20 mA. With four channels available, it provides precise control over process variables, enabling accurate adjustments and optimizations in industrial processes.

Wide Operating Range and Loop Supply Voltage:

Operating between 4 and 20 mA, the AS-B872-100 offers flexibility to accommodate various industrial applications. Additionally, with a maximum loop supply voltage of 60 Vdc, this module ensures compatibility with multiple power sources, providing stable and reliable operation in diverse environments.

High Resolution and Accuracy:

Featuring a resolution of 12 bits and an accuracy of ± 0.1% of full scale at 25°C, the AS-B872-100 delivers precise and reliable performance in process control and monitoring applications. Its high linearity ensures consistent and accurate output signals across a wide temperature range, from 0 to 60°C.

Fast Update Times and Isolation Features:

With less than 1 ms update times for all four channels, the AS-B872-100 enables rapid response and real-time adjustments in industrial processes. Moreover, its robust isolation features protect against electrical interference, with continuous isolation ratings of 1000 V for channel-to-channel, channel-to-case, and channel-to-module connections.

Efficient Power Consumption and Compact Design:

The AS-B872-100 boasts efficient power consumption requirements, with +5 V requiring 475 mA, +4.3 V requiring only five mA, and -5 V consuming no power. Its compact design, requiring only one slot, minimizes space requirements within control cabinets, optimizing valuable floor space in industrial facilities.

Reliable Performance and Easy Installation:

Weighing just 3 lbs (1.4 kg), the AS-B872-100 offers a lightweight yet robust solution for industrial automation applications. Its reliable performance and easy installation and maintenance ensure minimal downtime and maximum uptime, contributing to overall operational efficiency and productivity.

FAQs About Schneider Electric AS-B872-100 I/O Module:

Q: What is the Schneider Electric AS-B872-100? A: The AS-B872-100 is an I/O module manufactured by Schneider Electric, designed for precision control and monitoring in industrial automation applications.

Q: What type of module is the AS-B872-100? A: The AS-B872-100 is a D/A (digital-to-analog) module capable of converting digital signals into analog outputs within the 4 to 20 mA range.

Q: How many channels does the AS-B872-100 have? A: The AS-B872-100 has four channels, providing multiple outputs for precise control over process variables in industrial applications.

Q: What is the maximum loop supply voltage supported by the AS-B872-100? A: The AS-B872-100 supports a maximum loop supply voltage of 60 Vdc, ensuring compatibility with various power sources in industrial environments.

Q: What is the resolution and accuracy of the AS-B872-100? A: The AS-B872-100 features a resolution of 12 bits and an accuracy of ± 0.1% of full scale at 25°C, ensuring precise and reliable performance in process control and monitoring applications.

Q: What are the isolation features of the AS-B872-100? A: The AS-B872-100 offers robust isolation features, with continuous isolation ratings of 1000 V for channel-to-channel, channel-to-case, and channel-to-module connections, protecting against electrical interference.

Q: What are the power consumption requirements of the AS-B872-100? A: The AS-B872-100 requires +5 V with a consumption of 475 mA, +4.3 V with only five mA consumption, and -5 V with no power consumption, ensuring efficient energy utilization in industrial automation applications.

Q: How is the AS-B872-100 installed? A: The AS-B872-100 is installed using the AS-8535-000 terminal connector, which facilitates secure and reliable connections for seamless integration into automation systems and ensures quick and easy installation and maintenance.

Schneider Electric products are manufactured in France and are designed for Material handling, packaging, and textile machines usage. They come with a 2-year warranty from MRO Electric. We also carry I/O Modules from other manufacturers such as Modicon and ABB.
