AS-B882-239

AS-B882-239

ASB882239 - 800-Series I/O Module, Intelligent/Special Purpose, High speed counter, 2 up-counters, 0-30 kHz
2 remanufactured in stock
Ships Today

Free 2 Day Shipping
1 year warranty

Categories

ManufacturerSchneider Electric
SeriesModicon 984 Series
FusingNo internal fusing
Number of Counters2
Number of Auxiliary Inputs6
Number of Outputs6
Number of Groups1
Input Voltage Range0-32 Vdc
Input Current8.1 mA with 32 Vdc supply
5 mA with 28 Vdc supply
Output ON Voltage1.0 Vdc (max.) @ 0.5 A
0.3 Vdc (typ.) @ 0.5 A
0.4 Vdc (max.) @ 0.1 A
0.2 Vdc (typ.) @ 0.1 A
Output OFF Leakage Current1.0 mA (max.) @ 32 Vdc
Output Load Current0.5 A continuous per output
1.5 A fusing per group
Max. Count Frequency
High Frequency Mode30 KHz
Low Frequency Mode350 Hz
Reset Pulse Width13 µs (min.)
Enable Set Up Time
High Frequency Mode11 µs (max.)
Low Frequency Mode1.3 µs (max.)
Range of Signal Values
-Log “1” Neg. Threshold1.1 Vdc (min.), 2.2 Vdc (typ.)
-Log “0” Pos. Threshold3.5 Vdc (max.), 2.7 Vdc (typ.)
-Hysteresis0.36 Vdc (min.), 0.49 Vdc (typ.)
Power Required
+ 5 Vdc188 mA
+ 4.3 Vdc0 mA
-5 Vdc0 mA
Terminal ConnectorIncluded
Our core exchange program offers you credit for your faulty items, please ask about getting an RMA to send your core in with for credit. You can also send in your unit to be repaired, our standard turnaround for repairs is 5-7 days, and all of our repaired items look like new, and come with a 1 year warranty.

This product weights 3lbs. Want it shipped today?

  • Order within the next 10 hours and 20 minutes.
  • If you order between 4pm and 6pm EST, you will be charged a small rush fee.

What is the product warranty?

  • AS-B882-239 comes with a 1 year warranty
  • Ask about exchanging your faulty AS-B882-239 for credit when ordering from MRO Electric

Additional Information

Check out the rest of our Schneider Electric product line. Whether it's using our online instant quote feature, giving us a call, or sending us an email, we strive for customer satisfaction first. This means lower prices and better service for you. For more products like AS-B882-239, take a look at more from our Modicon 984 Series line. If your current unit has gone bad, take advantage of our Core Exchange program for the most inexpensive route. We offer a repair service on all of our products that keep your downtime to a minimum. To stay up to date on on manufacturer news, as well as access any of our datasheets, manuals, or other documentation, we suggest you take a look at our blog.
