AS-B984-100

AS-B984-100

ASB984100 - 800-Series I/O Module, Intelligent/Special Purpose, Discrete High Speed Logic Solver
Available - call for stock

Free 2 Day Shipping
1 year warranty

Categories

ManufacturerSchneider Electric
SeriesModicon 984 Series
Terminal ConnectorIncluded
Mode of OperationTrue high
Working Voltage20 ... 28 Vdc
Response Time
Inputs100 µsec max (no filtering)
Outputs1 msec max.
Input
Number of Inputs16
Number of Groups1
Source Resistance1000 Ω
ON Level (<1M Source Impedence)19.2 Vdc
OFF Level (0 Source Impedence)6 Vdc
ON Condition Threshold18 Vdc
Input Wetting Current6 mA minimum at 24 Vdc
Outputs
Number of Outputs8
Number of Groups1
Min. ON State Output Voltage19.2 Vdc
ON CurrentMax. 1 A per channel
Max. 8 A per module
Max. OFF State Leakage1 mA
Min. Load Current100 mA
Diagnostic InformationOpen Load, Short to Ground or Supply, Current limit, Over temperature
Power Required
+5 Vdc0 mA
+4.3 Vdc0 mA
-5 Vdc0 mA
Our core exchange program offers you credit for your faulty items, please ask about getting an RMA to send your core in with for credit. You can also send in your unit to be repaired, our standard turnaround for repairs is 5-7 days, and all of our repaired items look like new, and come with a 1 year warranty.

This product weights 1lb. Want it shipped tomorrow?

  • Order within the next 20 hours and 22 minutes.
  • If you order between 4pm and 6pm EST, you will be charged a small rush fee.

What is the product warranty?

  • AS-B984-100 comes with a 1 year warranty
  • Ask about exchanging your faulty AS-B984-100 for credit when ordering from MRO Electric
