ATV212HD37N4

2-year Warranty

Same Day Shipping

Schneider Electric ATV212HD37N4

ALTIVAR 212 VARIABLE SPEED DRIVE ATV212 - 37KW - 50HP - 480V - 3PH - EMC - IP21
5/5
1 rating

Select Condition

Refurbished

Request Quote

New

2 in stock

$3,625.00

Request a formal quote

  • Ships Today
  • 2 Year Warranty
Part NumberATV212HD37N4
ManufacturerSchneider Electric
TypeAC Drives
Warranty2 Year
Range Altivar 212
CategoryVaribale speed drive
DescriptionATV212
Voltage input380-480 V
DestinationAsynchronous motors
Phase3 Phase
Apparent power52 kVA 380 V
AssemblyWith heat sink
EMC filterClass C2 EMC filter integrated
Supply voltage380...480 V - 15...10 %
ApplicationsPumps and fans in HVAC
Max hp50 hp
Motor power37 kW
Network frequency47.5...63 Hz
Line current68.9 A 380 V 54.4 A 480 V
EMC filterClass C2 EMC filter integrated
Prospective line Isc22 kA
Speed range1…10
Nominal switching frequency8 kHz
Analogue output 1
Discrete output2
Physical interface2-wire RS 485
Option cardCommunication card LonWorks
ProtectionIP21

Our Repair Services

MRO Electric repairs CNCs, PLCs, Servo/Spindle Drives, Motors, Amplifiers, VFDs, HMIs, and more, most of which can be repaired in only 3-5 days.

Repair Benefits

MRO can restore your failed ATV212HD37N4 to remanufactured condition and save you up to 75% compared to buying new. We offer standard repair pricing to ensure you the best value for your repair.

Our certified technicians use rigorous testing procedures to ensure your parts are restored to fully functioning condition. Our team proudly stands behind all repairs by providing a minimum 2-year warranty.

Our technicians have vast experience with most manufacturers and models. In addition to this ATV212HD37N4 we also repair drives, motors, PLCs and more, so if you don’t see the model you need, please contact us.

Core Exchange

If you are interested in getting credit for your faulty ATV212HD37N4, just let us know, and we can issue you an RMA to send it in as an exchange. Our exchange program provides you with savings and keeps us stocked for the next time you need anything.

  • Shipping Weight : 77lbs

Want it shipped today?

  • Order within the next 9 hours and 17 minutes.
  • If you order between 4pm and 6pm EST, you will be charged a small rush fee.

Ask about exchanging your faulty ATV212HD37N4 for credit when ordering from MRO Electric

MRO Electric provides a 2-year warranty on every item we sell and repair. We stand behind all of our products and guarantee them for the full 2 years. If there is an issue with any of our products within the warranty period, we will evaluate the unit and repair or replace it under warranty.

Schneider Electric ATV212HD37N4 Overview

Schneider Electric ATV212HD37N4

The Schneider Electric ATV212HD37N4 is a high-performance variable-speed drive designed for precise control and energy efficiency in industrial applications, particularly in the realm of HVAC (Heating, Ventilation, and Air Conditioning). As part of the Altivar 212 range, this drive is characterized by its advanced features and specifications that make it a reliable solution for various motor control needs.

Key Specifications:

Powerful Performance:

The ATV212HD37N4 boasts a motor power of 37 kW, equivalent to 50 horsepower, making it suitable for demanding applications where substantial power is required. Operating in a 3-phase system at 480V, this drive ensures robust and efficient motor control.

Versatility in HVAC:

Designed specifically for asynchronous motors, the ATV212HD37N4 finds its niche in applications related to pumps and fans in HVAC systems. This specialization underscores its adaptability to the unique demands of heating, ventilation, and air conditioning processes.

Intelligent Assembly Style:

The drive is equipped with a heat sink assembly style, ensuring optimal heat dissipation during operation. This intelligent design enhances the longevity and reliability of the drive, contributing to its performance in diverse industrial environments.

EMC and IP21 Protection:

The inclusion of an Electromagnetic Compatibility (EMC) Class C2 filter ensures that the drive complies with electromagnetic interference standards. Additionally, the IP21 protection rating signifies protection against solid objects and offers a level of protection suitable for indoor use.

Wide Voltage Range:

With a rated supply voltage of 380-480 V, the ATV212HD37N4 accommodates variations in the power supply, operating within supply voltage limits of 323 to 528 V. The drive is capable of handling a supply frequency ranging from 50 to 60 Hz.

Advanced Control Features:

The drive supports various control profiles, including flux vector control without a sensor and voltage/frequency ratio control with multiple points. This flexibility allows for precise and adaptable control over motor performance.

Communication Capabilities:

Equipped with communication ports supporting protocols such as METASYS N2, BACnet, Modbus, APOGEE FLN, and LonWorks, the drive facilitates seamless integration into diverse industrial communication networks.

Environmental Considerations:

The ATV212HD37N4 is designed to operate in a temperature range of 14 to 104 degrees Fahrenheit (-10 to 40 degrees Celsius) without derating, with the option for additional derating in higher temperature conditions.

Compliance and Certifications:

The drive adheres to various international standards, including IEC and EN standards for environments, as well as certifications such as UL, NOM, C-Tick, and CSA, ensuring compliance with safety and performance regulations.

Frequently Asked Questions

1. What is the primary application of the ATV212HD37N4 variable speed drive?

The ATV212HD37N4 is designed for asynchronous motors and is particularly well-suited for controlling pumps and fans in HVAC (Heating, Ventilation, and Air Conditioning) systems.

2. What is the power rating of the ATV212HD37N4?

This variable-speed drive has a motor power of 37 kW, equivalent to 50 horsepower, making it suitable for applications requiring substantial power.

3. What is the significance of the EMC filter (Class C2) integrated into the drive?

The EMC filter ensures compliance with electromagnetic compatibility standards, minimizing electromagnetic interference and ensuring reliable performance in industrial environments.

4. Can the ATV212HD37N4 operate in different voltage conditions?

Yes, the drive has a rated supply voltage of 380-480 V, with supply voltage limits ranging from 323 to 528 V, providing flexibility and adaptability to variations in the power supply.

5. What communication protocols are supported by the ATV212HD37N4?

The drive supports communication protocols such as METASYS N2, BACnet, Modbus, APOGEE FLN, and LonWorks, facilitating seamless integration into diverse industrial communication networks.

6. Is the ATV212HD37N4 suitable for outdoor use?

The drive has an IP21 protection rating, which signifies protection against solid objects. While suitable for indoor use, additional protective measures may be required for outdoor applications.

7. What is the temperature range for the operation of the ATV212HD37N4?

The drive is designed to operate in a temperature range of 14 to 104 degrees Fahrenheit (-10 to 40 degrees Celsius) without derating, with the option for additional derating in higher temperature conditions.

8. How does the ATV212HD37N4 contribute to energy efficiency in HVAC applications?

The drive's advanced control features, including flux vector control without a sensor and voltage/frequency ratio control, enable precise and energy-efficient control of pumps and fans in HVAC systems.

9. Does the ATV212HD37N4 comply with international standards and certifications?

Yes, the drive adheres to various international standards, including IEC and EN standards for environments. It also holds certifications such as UL, NOM, C-Tick, and CSA, ensuring compliance with safety and performance regulations.

10. Can the ATV212HD37N4 be used in applications beyond HVAC, such as industrial pumps or fans?

While designed for HVAC applications, the ATV212HD37N4's versatility in motor control and adaptability to different loads makes it suitable for a range of industrial applications beyond HVAC, such as industrial pumps and fans.

Schneider Electric products are manufactured in France and are designed for Material handling, packaging, and textile machines usage. They come with a 2-year warranty from MRO Electric. We also carry AC Drives from other manufacturers such as Modicon and ABB.
