ATV31HU40N4

2-year Warranty

Same Day Shipping

Schneider Electric ATV31HU40N4

ALTIVAR 31 VARIABLE SPEED DRIVE ALTIVAR 31 - 4KW - 500V 3-PHASE SUPPLY - EMC FILTER - IP20
5/5
2 ratings

Select Condition

Refurbished

2 in stock

$597.00

Request a formal quote

  • Ships Today
  • 2 Year Warranty
  • Free Shipping
Part NumberATV31HU40N4
ManufacturerSchneider Electric
TypeAC Drives
Warranty2 Year
Range ATV31
CategoryVariable speed drive
Rated voltage380...500 V - 5...5 %
AssemblyWith heat sink
Network frequency47.5...63 Hz
Switching frequency2...16 kHz adjustable
Frequency out0.0005…0.5 kHz
Speed range1…50
Network Frequency47.5...63 Hz
Regulation loopFrequency PI regulator
Transient overtorque150…170 % of nominal motor torque
Analog output2
EMC filterIntegrated
Max trans current14.3 A 60 s
Analog input3
Power dissipation150 W at nominal load
DestinationAsynchronous motors
Supply voltage323…550 V
Frequency out0.0005…0.5 kHz
Supply frequency50...60 Hz - 5...5 %
Line current10.6 A 500 V 13.9 A 380 V, Isc = 1 kA
ApplicationSimple machine
Max hp5 hp 4 kHz
Apparent power9.2 kVA
Phase3 Phase
Current out9.5 A 4 kHz
Prospective line Isc1 kA

Our Repair Services

MRO Electric repairs CNCs, PLCs, Servo/Spindle Drives, Motors, Amplifiers, VFDs, HMIs, and more, most of which can be repaired in only 3-5 days.

Repair Benefits

MRO can restore your failed ATV31HU40N4 to remanufactured condition and save you up to 75% compared to buying new. We offer standard repair pricing to ensure you the best value for your repair.

Our certified technicians use rigorous testing procedures to ensure your parts are restored to fully functioning condition. Our team proudly stands behind all repairs by providing a minimum 2-year warranty.

Our technicians have vast experience with most manufacturers and models. In addition to this ATV31HU40N4 we also repair drives, motors, PLCs and more, so if you don’t see the model you need, please contact us.

Core Exchange

If you are interested in getting credit for your faulty ATV31HU40N4, just let us know, and we can issue you an RMA to send it in as an exchange. Our exchange program provides you with savings and keeps us stocked for the next time you need anything.

  • Shipping Weight : 10lbs

Want it shipped today?

  • Order within the next 11 hours and 47 minutes.
  • If you order between 4pm and 6pm EST, you will be charged a small rush fee.

Ask about exchanging your faulty ATV31HU40N4 for credit when ordering from MRO Electric

MRO Electric provides a 2-year warranty on every item we sell and repair. We stand behind all of our products and guarantee them for the full 2 years. If there is an issue with any of our products within the warranty period, we will evaluate the unit and repair or replace it under warranty.

Schneider Electric ATV31HU40N4 Overview

Powerful Motor Control Solution

The Schneider Electric ATV31HU40N4 Variable Speed Drive (VSD) stands as a powerful and versatile solution for controlling motors in applications that require variable speed control. Part of the Altivar ATV31 series, this VSD is meticulously engineered to optimize the performance of machines and processes, particularly in scenarios involving simple machines.

Robust Design for Industrial Environments

Designed with both robustness and advanced features in mind, the ATV31HU40N4 VSD is tailor-made for the demands of industrial environments. Its integrated Electromagnetic Compatibility (EMC) filter plays a pivotal role in minimizing electromagnetic interference, thereby contributing to stable and interference-free operations. This drive is carefully crafted to accommodate a supply voltage ranging from 380V to 500V, making it compatible with a wide spectrum of power systems.

Impressive Motor Power Capability

A standout feature of the ATV31HU40N4 is its impressive motor power capability. With a rated motor power of 4 kW (equivalent to approximately 5 horsepower), this VSD is primed to efficiently control motors operating within this power range. The motor control profile of the drive is founded on sensorless flux vector control, utilizing a pulse-width modulation (PWM) motor control signal. This profile comes factory-set to ensure consistent torque operation, rendering it an excellent fit for various industrial applications.

Precise Control and Monitoring Options

The VSD offers a multitude of analog input options (AI1, AI2, AI3), enabling precise control and monitoring capabilities. It caters to a range of input types, spanning voltage and current, thus ensuring seamless compatibility with an array of control signals. Complementing the analog inputs, the drive provides a comprehensive suite of discrete inputs (LI1...LI6) and outputs (R1A, R1B, R2A, R2B), offering versatile control configuration possibilities.

Comprehensive Protection Features

Protection features are integral to the longevity and safety of both the drive and the connected motor. The ATV31HU40N4 excels in this regard by providing comprehensive safeguards against various electrical faults. These include input phase breaks, line supply overvoltage, and undervoltage, motor phase breaks, overcurrent, overheating, and short-circuits between motor phases, among others. Such robust protection mechanisms effectively mitigate the risk of equipment damage and enhance overall operational safety.

User-Friendly Monitoring and Integration

Ease of use and monitoring are paramount, and the ATV31HU40N4 excels in this aspect. It boasts a 7-segment LED display that furnishes pertinent information about drive voltage and status, facilitating efficient monitoring. Additionally, the drive seamlessly integrates into control systems through diverse communication interfaces, including CANopen and Modbus via RJ45 connectors. This feature ensures effortless assimilation into larger automation setups.

FAQ: Schneider Electric ATV31HU40N4 AC Drive

Q: What is the Schneider Electric ATV31HU40N4?

A: The Schneider Electric ATV31HU40N4 is an AC drive, also known as a variable speed drive, designed to control the speed of asynchronous motors in industrial applications.

Q: What are the key features of the ATV31HU40N4?

A: The ATV31HU40N4 features a rated voltage of 380 to 500 volts, assembly with a heat sink, adjustable switching frequency (2 to 16 kHz), frequency output range of 0.0005 to 0.5 kHz, and integrated EMC filter for electromagnetic compatibility.

Q: What is the range and category of the ATV31HU40N4?

A: The ATV31HU40N4 belongs to the ATV31 range of variable speed drives and is categorized as a variable speed drive suitable for controlling asynchronous motors.

Q: What are the typical applications of the ATV31HU40N4?

A: The ATV31HU40N4 is commonly used in simple machine applications where precise control of motor speed is required, such as conveyors, fans, pumps, and other industrial machinery.

Q: What is the supply voltage and frequency range of the ATV31HU40N4?

A: The ATV31HU40N4 operates with a supply voltage range of 323 to 550 volts and a supply frequency range of 50 to 60 Hz with a tolerance of ±5%.

Q: What are the maximum transient over-torque and current output of the ATV31HU40N4?

A: The ATV31HU40N4 can provide transient over-torque ranging from 150% to 170% of the nominal motor torque and has a maximum current output of 9.5 A at 4 kHz.

Q: Is the ATV31HU40N4 suitable for use with three-phase motors?

A: The ATV31HU40N4 is designed explicitly with three-phase asynchronous motors, offering precise control and efficiency in motor operation.

Q: What is the power dissipation and apparent power rating of the ATV31HU40N4?

A: The ATV31HU40N4 has a power dissipation of 150 watts at nominal load and an apparent power rating of 9.2 kVA, ensuring efficient operation and minimal energy loss.

Q: What protection features does the ATV31HU40N4 offer?

A: The ATV31HU40N4 provides integrated protection features, including overload protection, short-circuit protection, and overvoltage protection, ensuring reliable and safe operation in industrial environments.

Q: What is the intended destination or application of the ATV31HU40N4?

A: The ATV31HU40N4 is designed for various industrial applications, particularly in simple machines with essential speed control and reliable motor operation.

Schneider Electric products are manufactured in France and are designed for Material handling, packaging, and textile machines usage. They come with a 2-year warranty from MRO Electric. We also carry AC Drives from other manufacturers such as Modicon and ABB.
