ATV61HD90N4

2-year Warranty

Same Day Shipping

Schneider Electric ATV61HD90N4

ALTIVAR 61 VARIABLE SPEED DRIVE 90 KW 125 HP 380 TO 480 VOLT 3-PHASE

5/5
3 ratings

Select Condition

Refurbished

Request Quote

New

2 in stock

$9,837.00

Request a formal quote

  • Ships Today
  • 2 Year Warranty
  • Free Shipping
Part NumberATV61HD90N4
ManufacturerSchneider Electric
TypeAC Drives
Warranty2 Year
Range of productAltivar 61
166 A for 380 V 3 phases 90 kW / 125 hp
4...8 kHz with derating factor
Voltage/frequency ratio, 2 points
Flux vector control without sensor, standard
Voltage/frequency ratio - Energy Saving, quadratic U/f
CANopen
Communication card for BACnet
Communication card for CC-Link
Controller inside programmable card
Communication card for DeviceNet
Communication card for EtherNet/IP
Communication card for Fipio
I/O extension card
Communication card for Interbus-S
Communication card for LonWorks
Communication card for METASYS N2
Communication card for Modbus Plus
Communication card for Modbus TCP
Communication card for Modbus/Uni-Telway
Multi-pump card
Communication card for Profibus DP
Communication card for Profibus DP V1
Product or component typeVariable speed drive
Product specific applicationPumping and ventilation machine
Component nameATV61
Motor power kW90 kW, 3 phases at 380...480 V
Motor power hp125 hp, 3 phases at 380...480 V
Power supply voltage380...480 V - 15...10 %
Supply number of phases3 phases
Line current143 A for 480 V 3 phases 90 kW / 125 hp
EMC filterLevel 3 EMC filter
Assembly styleWith heat sink
Apparent power109.3 kVA at 380 V 3 phases 90 kW / 125 hp
Maximum prospective line Isc35 kA for 3 phases
Maximum transient current214.8 A for 60 s, 3 phases
Nominal switching frequency4 kHz
Switching frequency2...8 kHz adjustable
Asynchronous motor controlVoltage/frequency ratio, 5 points
Synchronous motor control profileVector control without sensor, standard
Communication port protocolModbus
Type of polarizationNo impedance for Modbus
Option cardCommunication card for APOGEE FLN

Our Repair Services

MRO Electric repairs CNCs, PLCs, Servo/Spindle Drives, Motors, Amplifiers, VFDs, HMIs, and more, most of which can be repaired in only 3-5 days.

Repair Benefits

MRO can restore your failed ATV61HD90N4 to remanufactured condition and save you up to 75% compared to buying new. We offer standard repair pricing to ensure you the best value for your repair.

Our certified technicians use rigorous testing procedures to ensure your parts are restored to fully functioning condition. Our team proudly stands behind all repairs by providing a minimum 2-year warranty.

Our technicians have vast experience with most manufacturers and models. In addition to this ATV61HD90N4 we also repair drives, motors, PLCs and more, so if you don’t see the model you need, please contact us.

Core Exchange

If you are interested in getting credit for your faulty ATV61HD90N4, just let us know, and we can issue you an RMA to send it in as an exchange. Our exchange program provides you with savings and keeps us stocked for the next time you need anything.

  • Shipping Weight : 1lb

Want it shipped today?

  • Order within the next 10 hours and 58 minutes.
  • If you order between 4pm and 6pm EST, you will be charged a small rush fee.

Ask about exchanging your faulty ATV61HD90N4 for credit when ordering from MRO Electric

MRO Electric provides a 2-year warranty on every item we sell and repair. We stand behind all of our products and guarantee them for the full 2 years. If there is an issue with any of our products within the warranty period, we will evaluate the unit and repair or replace it under warranty.

Schneider Electric ATV61HD90N4 Overview

The ATV61HD90N4 is a powerful and versatile variable-speed drive designed to meet the needs of a wide range of industrial applications. This high-performance drive is part of the Altivar 61 product range specifically tailored for use with pumping and ventilation machines. With its robust features and capabilities, the ATV61HD90N4 is well-suited for demanding tasks.

Motor Power and Horsepower

This variable speed drive has a motor power rating of 90 kW, making it suitable for 3-phase power supplies within the range of 380 to 480 V. It is capable of delivering a maximum horsepower of 125 hp under similar voltage conditions, making it a formidable choice for applications that require high power output.

Power Supply and EMC

The drive operates on a 3-phase power supply voltage of 380 to 480 V with a tolerance range of -15% to +10%. It incorporates a Level 3 EMC filter to minimize electromagnetic interference. The ATV61HD90N4 is designed to handle a maximum prospective line Isc of 35 kA for 3-phase power systems, ensuring safety and stability even under challenging conditions.

Control Capabilities

This variable speed drive offers a wide range of control modes for both asynchronous and synchronous motors. It supports voltage/frequency ratio control with 5 and 2 points, flux vector control without a sensor, and energy-saving quadratic U/f control. Vector control without a sensor is also available for synchronous motors, making it versatile for various motor types and applications.

Communication

The ATV61HD90N4 features multiple communication options, including Modbus and CANopen protocols. Users can easily integrate it into their industrial networks and control systems. It also supports various communication cards, such as APOGEE FLN, BACnet, CC-Link, and more, providing flexibility for different communication needs.

Protection and Diagnostics

To ensure the safety and reliability of your operations, this variable speed drive includes a range of protection features. These include protection against input phase loss, line supply overvoltage, overcurrent between output phases and earth, overheating, and many others. It also offers diagnostic capabilities through LED indicators, allowing for quick and effective troubleshooting.

Physical Characteristics

The ATV61HD90N4 is designed for easy installation and integration into your industrial setup. It comes with various terminal options for electrical connections, making it adaptable to different installation requirements. Its compact dimensions, with a width of 12.60 inches, height of 36.22 inches, and depth of 14.84 inches, ensure it can fit into various enclosures.

Environmental Considerations

This drive is built to withstand industrial environments. It has a degree of protection of IP41 on the upper part and IP54 on the lower part, ensuring resistance to dust and moisture. It can operate in temperatures ranging from -10°C to 45°C without derating and up to 60°C with derating, making it suitable for a wide range of working conditions.

Certifications and Compliance

The ATV61HD90N4 complies with various international standards, including CE, UL, and IEC standards for electrical and electromagnetic compatibility. It also has certifications from organizations like DNV, GOST, CSA, and NOM.

In summary, the ATV61HD90N4 is a highly capable variable-speed drive with a motor power of 90 kW and a maximum horsepower rating of 125 hp. It offers extensive control options, communication flexibility, and robust protection features, making it an ideal choice for demanding industrial applications in the field of pumping and ventilation. Its adherence to international standards and certifications ensures its reliability and safety in various environments.

Schneider Electric products are manufactured in France and are designed for Material handling, packaging, and textile machines usage. They come with a 2-year warranty from MRO Electric. We also carry AC Drives from other manufacturers such as Modicon and ABB.

Contact Us Today For More Information About Schneider Electric Products

Check out the rest of our Schneider Electric product line. Whether it's using our online instant quote feature, giving us a call at (800) 691-8511, or emailing us at sales@mroelectric.com, we strive for customer satisfaction first. This means lower prices and better service for you. For more products like ATV61HD90N4, take a look at more from our AC Drives line. If your current unit has gone bad, take advantage of our Core Exchange program for the most inexpensive route. You can learn more about this program on our FAQ page here. We offer a repair service on all of our ATV61HD90N4 products that keep your downtime to a minimum. To stay up to date on manufacturer news, as well as access any of our datasheets, manuals, or other documentation, we suggest you take a look at our blog.
