ATV71H075N4

2-year Warranty

Same Day Shipping

Schneider Electric ATV71H075N4

ALTIVAR 71 VARIABLE SPEED DRIVE 0.75 KW 1 HP 480 VOLT EMC FILTER
5/5
2 ratings

Select Condition

Refurbished

Request Quote

New

3 in stock

$1,591.00

Request a formal quote

  • Ships Today
  • 2 Year Warranty
  • Free Shipping
Part NumberATV71H075N4
ManufacturerSchneider Electric
TypeAC Drives
Warranty2 Year
RangeATV71
CategoryVariable speed drive
ApplicationComplex, high-power machines
Power supply323…528 V
Max motor cable length164.04 Ft (50 m) shielded cable 328.08 ft (100 m) unshielded cable
EMC filterIntegrated
Output frequency0.1…599 Hz
Motor power kW0.75 kW, 3 phase 380...480 V
Assembly styleWith heat sink
Phase3Phase
Nominal switching frequency4 kHz
Apparent power2.4 kVA 380 V 3 phase 0.75 kW / 1 hp
Max Horse Power Rating1 hp, 3 phase 380...480 V
DestinationAsynchronous motors Synchronous motors
Power supply frequency50...60 Hz - 5...5 %
Speed accuracy+/- 0.01 % of nominal speed in closed-loop mode with encoder feedback 0.2 Tn to Tn +/- 10 % of nominal slip without speed feedback 0.2 Tn to Tn
Discrete input number7
Analogue output1
Discrete output number2
Maximum switching currentR1, R2 2 A 250 V AC inductive, cos phi = 0.4 R1, R2 2 A 30 V DC inductive, cos phi = 0.4 R1, R2 5 A 250 V AC resistive, cos phi = 1 R1, R2 5 A 30 V DC resistive, cos phi = 1

Our Repair Services

MRO Electric repairs CNCs, PLCs, Servo/Spindle Drives, Motors, Amplifiers, VFDs, HMIs, and more, most of which can be repaired in only 3-5 days.

Repair Benefits

MRO can restore your failed ATV71H075N4 to remanufactured condition and save you up to 75% compared to buying new. We offer standard repair pricing to ensure you the best value for your repair.

Our certified technicians use rigorous testing procedures to ensure your parts are restored to fully functioning condition. Our team proudly stands behind all repairs by providing a minimum 2-year warranty.

Our technicians have vast experience with most manufacturers and models. In addition to this ATV71H075N4 we also repair drives, motors, PLCs and more, so if you don’t see the model you need, please contact us.

Core Exchange

If you are interested in getting credit for your faulty ATV71H075N4, just let us know, and we can issue you an RMA to send it in as an exchange. Our exchange program provides you with savings and keeps us stocked for the next time you need anything.

  • Shipping Weight : 4lbs

Want it shipped tomorrow?

  • Order within the next 22 hours and 33 minutes.
  • If you order between 4pm and 6pm EST, you will be charged a small rush fee.

Ask about exchanging your faulty ATV71H075N4 for credit when ordering from MRO Electric

MRO Electric provides a 2-year warranty on every item we sell and repair. We stand behind all of our products and guarantee them for the full 2 years. If there is an issue with any of our products within the warranty period, we will evaluate the unit and repair or replace it under warranty.

Schneider Electric ATV71H075N4 Overview

ATV71H075N4Z  Drive

The ATV71H075N4Z is a variable-speed drive from the Altivar 71 product range, designed for complex, high-power machines. It is a highly versatile and efficient drive suitable for various industrial applications that require precise motor control and energy optimization.

Features

The variable speed drive is rated at 0.75kW or 1 horsepower, making it ideal for driving motors with a three-phase power supply ranging from 380V to 480V. The drive offers flexibility in motor control and can handle various asynchronous and synchronous motor types.

One of the significant advantages of the ATV71H075N4Z is its integrated EMC filter, which helps reduce electromagnetic interference and ensures compliance with electromagnetic compatibility standards. The filter is essential in industrial settings where sensitive electronic equipment may be susceptible to interference from motor drives.

Design

The drive is designed with a heat sink assembly style, enabling effective heat dissipation and ensuring reliable performance even in demanding applications. However, it does not come with a remote graphic terminal, meaning that the drive can be controlled through other means or integrated into a broader control system.

Specifications

In terms of its electrical specifications, the ATV71H075N4Z can handle an apparent power of up to 2.4kVA at 380V and 3.7A at 480V. It has a nominal output current of 2.1A at 4kHz for 460V and 2.3A at 4kHz for 380V. The drive is capable of handling maximum transient currents of 3.5A for 60 seconds and 3.8A for 2 seconds.

The drive offers precise motor control with an output frequency range from 0.1Hz to 599Hz, enabling a wide range of motor speeds. It also has a nominal switching frequency of 4kHz, which can be adjusted between 1kHz to 16kHz to optimize motor control performance based on specific application requirements.

Control

The ATV71H075N4Z supports various motor control profiles, including Flux Vector Control (FVC) with sensor (current vector), Sensorless Flux Vector Control (SFVC) with voltage or current vector, and Voltage/Frequency ratio (2 or 5 points). These control profiles allow users to select the most suitable method for their specific motor and application needs.

Installation

In terms of installation and connectivity, the variable speed drive comes with several input and output options. It has two analog inputs (AI1-/Al1+ and AI2) and one analog output (AO1) that can be software-configured based on the application requirements. Additionally, it has seven discrete inputs (LI1...LI6, PWR) and two discrete outputs (R1A, R1B, R1C, R2A, R2B).

Communication

The drive supports various communication protocols, including CANopen and Modbus, allowing for seamless integration into control systems. It has built-in protections against a range of faults and overloads, ensuring the safe and reliable operation of the connected motor.

Design

The ATV71H075N4Z is designed to withstand challenging environmental conditions, with a wide operating temperature range from -10°C to 50°C. It is also built to withstand vibrations and shocks, making it suitable for use in rugged industrial environments.

Overall, the ATV71H075N4Z is a robust and versatile variable-speed drive that offers precise motor control, energy efficiency, and reliable operation. Its integrated EMC filter, multiple control profiles, and various communication options make it an excellent choice for demanding industrial applications where motor control and optimization are critical factors.

Schneider Electric products are manufactured in France and are designed for Material handling, packaging, and textile machines usage. They come with a 2-year warranty from MRO Electric. We also carry AC Drives from other manufacturers such as Modicon and ABB.
