ATV71HC11N4

2-year Warranty

Same Day Shipping

Schneider Electric ATV71HC11N4

ALTIVAR 71 VARIABLE SPEED DRIVE 110 KW 150 HP 480 VOLT EMC
5/5
1 rating

1 Available


2 Year warranty

Part NumberATV71HC11N4
ManufacturerSchneider Electric
TypeAC Drives
Warranty2 Year
Range of productAltivar 71
200 m unshielded cable
202 A for 380 V 3 phases 110 kW / 150 hp
215 A at 2.5 kHz 460 V 3 phases 110 kW / 150 hp
355 A for 2 s 3 phases 110 kW / 150 hp
2.5...8 kHz with derating factor
ENA (Energy adaptation) system for unbalanced loads
Sensorless flux vector control (SFVC) (voltage or current vector)
Flux vector control (FVC) with sensor (current vector)
Product or component typeVariable speed drive
Product specific applicationComplex, high-power machines
Component nameATV71
Motor power kW110 kW, 3 phases at 380...480 V
Motor power hp150 hp, 3 phases at 380...480 V
Maximum motor cable length100 m shielded cable
Power supply voltage380...480 V - 15...10 %
Network number of phases3 phases
Line current163 A for 480 V 3 phases 110 kW / 150 hp
EMC filterIntegrated
Assembly styleWith heat sink
VariantReinforced version
Apparent power133 kVA at 380 V 3 phases 110 kW / 150 hp
Prospective line Isc35 kA for 3 phases
Nominal output current215 A at 2.5 kHz 380 V 3 phases 110 kW / 150 hp
Maximum transient current323 A for 60 s 3 phases 110 kW / 150 hp
Output frequency0.1…500 Hz
Nominal switching frequency2.5 kHz
Switching frequency2.5...8 kHz adjustable
Asynchronous motor control profileVoltage/frequency ratio (2 or 5 points)
Type of polarizationNo impedance for Modbus

Our Repair Services

MRO Electric repairs CNCs, PLCs, Servo/Spindle Drives, Motors, Amplifiers, VFDs, HMIs, and more, most of which can be repaired in only 3-5 days.

Repair Benefits

MRO can restore your failed ATV71HC11N4 to remanufactured condition and save you up to 75% compared to buying new. We offer standard repair pricing to ensure you the best value for your repair.

Our certified technicians use rigorous testing procedures to ensure your parts are restored to fully functioning condition. Our team proudly stands behind all repairs by providing a minimum 2-year warranty.

Our technicians have vast experience with most manufacturers and models. In addition to this ATV71HC11N4 we also repair drives, motors, PLCs and more, so if you don’t see the model you need, please contact us.

Core Exchange

If you are interested in getting credit for your faulty ATV71HC11N4, just let us know, and we can issue you an RMA to send it in as an exchange. Our exchange program provides you with savings and keeps us stocked for the next time you need anything.

  • Shipping Weight : 165lbs

Want it shipped today?

  • Order within the next 8 hours and 49 minutes.
  • If you order between 4pm and 6pm EST, you will be charged a small rush fee.

Ask about exchanging your faulty ATV71HC11N4 for credit when ordering from MRO Electric

MRO Electric provides a 2-year warranty on every item we sell and repair. We stand behind all of our products and guarantee them for the full 2 years. If there is an issue with any of our products within the warranty period, we will evaluate the unit and repair or replace it under warranty.

Schneider Electric ATV71HC11N4 Overview

Schneider Electric ATV71HC11N4 AC Drive

The Schneider Electric ATV71HC11N4 AC Drive is a versatile, high-performance variable-speed drive designed for complex, high-power machines.

Unmatched Performance and Versatility:

The ATV71HC11N4 is part of the Altivar 71 range, offering unparalleled performance and versatility in variable-speed drives. With a motor power of 110 kW (150 hp) and support for 380 to 480 V three-phase power supplies, it provides torque and speed control for various industrial applications.

Advanced Control Features for Optimal Efficiency:

Equipped with an Energy Adaptation (ENA) system for unbalanced loads and Sensorless Flux Vector Control (SFVC) and Flux Vector Control (FVC) with sensor options, the ATV71HC11N4 ensures optimal efficiency and performance in complex machine setups. Its variable frequency output, ranging from 0.1 to 500 Hz, allows for precise speed control and adaptation to varying process requirements.

Robust Design for Reliable Operation:

Featuring an integrated EMC filter and assembly with a heat sink, the ATV71HC11N4 is built to withstand the rigors of industrial environments. Its reinforced variant ensures durability and reliability even in harsh operating conditions, making it suitable for heavy-duty applications where reliability is critical.

Enhanced Safety and Protection Features:

The ATV71HC11N4 has built-in protections such as integrated EMC filters, short-circuit protection, and maximum transient current handling capability, safeguarding equipment and personnel from electrical faults. Its adjustable switching frequency allows for performance optimization while maintaining safety standards.

Seamless Integration and Easy Installation:

With its compact design and user-friendly interface, the ATV71HC11N4 is easy to install and integrate into existing industrial setups. It supports a maximum motor cable length of 100 meters with shielded cable, providing flexibility in installation configurations.

Optimized Energy Consumption and Cost Savings:

The ATV71HC11N4 helps optimize energy consumption and reduce operating costs by providing precise speed and torque control. Its energy adaptation system and advanced control algorithms ensure efficient operation, minimizing wasted energy and maximizing productivity.

FAQs about the Schneider Electric ATV71HC11N4 AC Drive:

What is the Schneider Electric ATV71HC11N4 AC Drive?

The ATV71HC11N4 is a variable-speed drive designed for industrial applications. It controls motor speed and torque precisely, making it ideal for complex, high-power machines.

What are the key features of the ATV71HC11N4 AC Drive?

The ATV71HC11N4 offers a wide range of features, including support for motor powers up to 110 kW (150 hp), voltage range of 380 to 480 V three-phase, advanced control options like Energy Adaptation (ENA) system and Sensorless Flux Vector Control (SFVC), robust design with integrated EMC filter and heat sink assembly, and safety features such as short-circuit protection and maximum transient current handling.

What applications are the ATV71HC11N4 AC Drive suitable for?

The ATV71HC11N4 is suitable for various industrial applications, including pumps, fans, conveyors, compressors, and more. Its versatility and advanced control features make it ideal for complex machinery requiring precise speed and torque control.

How does the ATV71HC11N4 AC Drive help optimize energy consumption?

The ATV71HC11N4 features an Energy Adaptation (ENA) system that optimizes energy consumption for unbalanced loads, ensuring efficient operation even in varying conditions. Its advanced control algorithms and variable frequency output also help minimize wasted energy, leading to cost savings.

Is the ATV71HC11N4 AC Drive easy to install and integrate?

The ATV71HC11N4 is designed for easy installation and seamless integration into industrial setups. Its compact design and user-friendly interface simplify installation, while its compatibility with shielded motor cables up to 100 meters provides flexibility in configuration.

What safety features are included in the ATV71HC11N4 AC Drive?

The ATV71HC11N4 comes with integrated EMC filters, short-circuit protection, and maximum transient current handling capability to ensure equipment and personnel safety. These features help protect against electrical faults and ensure reliable operation.

What are the advantages of using the ATV71HC11N4 AC Drive in industrial applications?

The ATV71HC11N4 offers numerous advantages, including improved productivity, reduced downtime, enhanced energy efficiency, and cost savings. Its advanced control features and robust design make it a reliable and versatile solution for industrial automation needs.

Schneider Electric products are manufactured in France and are designed for Material handling, packaging, and textile machines usage. They come with a 2-year warranty from MRO Electric. We also carry AC Drives from other manufacturers such as Modicon and ABB.
