Schneider Electric BMXAMO0802

1 rating

Select Condition


Request Quote


9 in stock


Request a formal quote

  • Ships Today
  • 2 Year Warranty
  • Free Shipping
Part NumberBMXAMO0802
ManufacturerSchneider Electric
TypeI/O Modules
Model #BMX-AMO-0802
Warranty2 Year
RangeModicon X80
ComponentAnalog output module
Connection20 ways 1 connector
Analogue input16 bits
Measurement error<= 0.25 % of full scale 0...60 °C 0.1 % of full scale 25 °C
Temperature45 ppm/°C 0...20 mA 45 ppm/°C 4...20 mA
Isolation voltage1400 V DC between channels and ground 1400 V DC between channels and bus
SupplyInternal power supply via rack
Conversion time<= 4 ms
Status LED1 LED (green) RUN 1 LED per channel (green) channel diagnostic 1 LED (red) ERR 1 LED (red) I/O
Power consumption in W3.6 W 24 V DC typical 3.9 W 24 V DC maximum 0.35 W 3.3 V DC typical 0.48 W 3.3 V DC maximum
CertificationsCE,RCM, CSA, EAC, Merchant Navy, UL
StandardsEN/IEC 61010-2-201 EN/IEC 61131-2 UL 61010-2-201 CSA C22.2 No 61010-2-201
