BMXDDO3202K

2-year Warranty

Same Day Shipping

Schneider Electric BMXDDO3202K

MANUFACTURER: Schneider Electric
DESCRIPTION: Digital 32Q I/O Module
INFO: I/O Modules


1 in stock

Ships Today


Free Shipping

2 Year warranty

Part NumberBMXDDO3202K
ManufacturerSchneider Electric
TypeI/O Modules
Model #BMX-DDO-3202K
Warranty2 Year
RangeModicon X80
CategoryDiscrete output module
Discrete output typeSolid state
Discrete output current0.1 A
Discrete output number32 EN/IEC 61131-2
Current per channel 0.125 A
Maximum current 3.2 A
Discrete output logicPositive
Maximum leakage current0.1 mA at state 0
Discrete output voltage24 V 19...30 V DC
Maximum voltage drop<1.5 V at state 1
Power dissipation3.6 W
Response time on output1.2 ms
Insulation resistance> 10 MOhm 500 V DC
MTBF reliability290000 H
Typical current consumption125 mA 3.3 V DC
Output overload protectionWith current limiter With electronic circuit breaker 0.125 A < Id < 0.185 A
Switching frequency0.5/LI² Hz
Load impedance ohmic>= 220 Ohm
Maximum overload time15 ms
ProtectionIP20

Our Repair Services

MRO Electric repairs CNCs, PLCs, Servo/Spindle Drives, Motors, Amplifiers, VFDs, HMIs, and more, most of which can be repaired in only 3-5 days.

Repair Benefits

MRO can restore your failed BMXDDO3202K to remanufactured condition and save you up to 75% compared to buying new. We offer standard repair pricing to ensure you the best value for your repair.

Our certified technicians use rigorous testing procedures to ensure your parts are restored to fully functioning condition. Our team proudly stands behind all repairs by providing a minimum 2-year warranty.

Our technicians have vast experience with most manufacturers and models. In addition to this BMXDDO3202K we also repair drives, motors, PLCs and more, so if you don’t see the model you need, please contact us.

Core Exchange

If you are interested in getting credit for your faulty BMXDDO3202K, just let us know, and we can issue you an RMA to send it in as an exchange. Our exchange program provides you with savings and keeps us stocked for the next time you need anything.

  • Shipping Weight : 1lb

Want it shipped today?

  • Order within the next 11 hours and 28 minutes.
  • If you order between 4pm and 6pm EST, you will be charged a small rush fee.

Ask about exchanging your faulty BMXDDO3202K for credit when ordering from MRO Electric

MRO Electric provides a 2-year warranty on every item we sell and repair. We stand behind all of our products and guarantee them for the full 2 years. If there is an issue with any of our products within the warranty period, we will evaluate the unit and repair or replace it under warranty.

Schneider Electric BMXDDO3202K Overview

BMXDDO3202K Discrete Output Module

Introduction:

The BMXDDO3202K stands as a cornerstone in the Modicon X80 range, offering precision and versatility in discrete output control. With 32 transistor outputs and a host of advanced features, this discrete output module is engineered to meet the demands of industrial automation with reliability and efficiency.

Key Specifications:

Range of Product: Modicon X80

As part of the Modicon X80 range, the BMXDDO3202K is designed to integrate seamlessly into Modicon automation systems, providing a robust solution for discrete output control.

Discrete Output Number: 32 EN/IEC 61131-2

Featuring an impressive 32-transistor output, the module enables the precise control of multiple devices or processes, enhancing the flexibility of industrial applications.

Discrete Output Type: Solid State

The use of solid-state technology ensures reliability and longevity in operation, making the BMXDDO3202K a dependable choice for critical industrial processes.

Discrete Output Logic: Positive

Employing positive logic simplifies integration, ensuring consistent and intuitive communication within the Modicon automation system.

Discrete Output Voltage: 24 V (19...30 V DC)

Operating within a voltage range of 19 to 30 V DC, the module provides compatibility with various industrial setups, offering flexibility in power requirements.

Discrete Output Current: 0.1 A

Each discrete output channel can handle a current of 0.1 A, allowing for precise control over connected devices or components.

Maximum Current per Module: 3.2 A

With a maximum current capacity of 3.2 A per module, the BMXDDO3202K meets the demands of industrial applications with higher current requirements.

Response Time on Output: 1.2 ms

The module boasts a rapid response time of 1.2 ms, ensuring real-time control and execution of commands for efficient industrial processes.

Status LED Indicators:

Equipped with status LEDs, including module operating (RUN), channel diagnostic (Green), module error (ERR), and module I/O (Red), users can easily monitor and diagnose the status of the module and connected channels.

Protection Features:

The module includes a range of protection features such as external fuse reverse polarity protection, short-circuit protection, overload protection, and overvoltage protection, ensuring the longevity and reliability of the connected devices.

Environmental Considerations:

The BMXDDO3202K boasts a robust IP20 degree of protection, making it resilient against solid objects. It adheres to directives such as the low voltage directive (2014/35/EU) and electromagnetic compatibility (2014/30/EU).

Mechanical Data:

With a compact and lightweight design (0.24 lb/0.11 kg), the module is easy to integrate into various industrial setups.

Environmental Operating Conditions:

The module can operate in a wide temperature range (-40…185 °F) and at altitudes up to 6561.68 ft (2000 m) without derating. It exhibits resistance to vibrations (3 gn) and shocks (30 gn).
