MODICON PREMIUM UNITY HOT STANDBY PROCESSOR - 1 RACKS, 2 COM MODULE PROCESSOR
| Part Number | TSXH5724M |
| Manufacturer | Schneider Electric |
| Type | CPUs |
| Model # | TSX-H57-24M |
| Warranty | 2 Year |
| Module format | Standard |
| Product or component type | Unity Hot Standby processor |
| Number of racks | 1 6/8/12 slots |
| Discrete I/O processor capacity | 1024 I/O |
| Analogue I/O processor capacity | 80 I/O |
| Number of application specific channel | ≤ 24 |
| Number of process control channel | ≤ 10 up to 30 simple loops |
| Integrated connection type | Ethernet TCP/IP RJ45 |
| USB port USB type A 12 Mbit/s | |
| Serial link female mini DIN RS485 19.2 kbit/s |
| Communication module processor | 2 |
| Memory description | PCMCIA card 16384 kB additional data storage |
| Internal RAM (with PCMCIA card) 768 kB program | |
| Internal RAM (with PCMCIA card) 192 kB data | |
| Internal RAM (without PCMCIA card) 192 kB program and data | |
| Software designation | Unity Pro |
| Protective treatment | TC |
| Number of slots | ≤ 12 |
| Port Ethernet | 10BASE-T/100BASE-TX |
| Maximum size of object areas | 192 kB data exchanged via CPU Sync link |
| 8056 %Mi located internal bits | |
| 32464 %MWi internal words located internal data | |
| 32760 %KWi constant words located internal data | |
| Unlimited (DFB and EFB function blocks) unlocated internal data |
| Unlimited (elementary and derived data) unlocated internal data | |
| Application structure | 1 master task |
| Execution time per instruction | 0.039...0.057 µs Boolean without PCMCIA card |
| 0.048...0.057 µs Boolean with PCMCIA card | |
| 0.054...0.073 µs word or fixed-point arithmetic without PCMCIA card | |
| 0.054...0.073 µs word or fixed-point arithmetic with PCMCIA card | |
| 0.055...0.063 µs floating points without PCMCIA card | |
| 0.055...0.063 µs floating points with PCMCIA card | |
| Number of instructions per ms | 11.4 Kinst/ms 65 % Boolean + 35 % fixed arithmetic without PCMCIA card |
| 11.4 Kinst/ms 65 % Boolean + 35 % fixed arithmetic with PCMCIA card | |
| 15.75 Kinst/ms 100 % Boolean without PCMCIA card | |
| 15.75 Kinst/ms 100 % Boolean with PCMCIA card | |
| System overhead | 1 ms master task |
| Marking | CE |
MRO Electric repairs CNCs, PLCs, Servo/Spindle Drives, Motors, Amplifiers, VFDs, HMIs, and more, most of which can be repaired in only 3-5 days.
MRO can restore your failed TSXH5724M to remanufactured condition and save you up to 75% compared to buying new. We offer standard repair pricing to ensure you the best value for your repair.
Our certified technicians use rigorous testing procedures to ensure your parts are restored to fully functioning condition. Our team proudly stands behind all repairs by providing a minimum 2-year warranty.
Our technicians have vast experience with most manufacturers and models. In addition to this TSXH5724M we also repair drives, motors, PLCs and more, so if you don’t see the model you need, please contact us.
If you are interested in getting credit for your faulty TSXH5724M, just let us know, and we can issue you an RMA to send it in as an exchange. Our exchange program provides you with savings and keeps us stocked for the next time you need anything.
Want it shipped today?
Ask about exchanging your faulty TSXH5724M for credit when ordering from MRO Electric
Introduction: The Schneider Electric TSXH5724M is a Unity Hot Standby processor designed to provide reliable and efficient control in industrial automation systems. Its advanced features and robust design ensure seamless operation and redundancy for critical applications.
As a Unity Hot Standby processor, the TSXH5724M offers redundancy and fault tolerance for increased system reliability. It supports automatic switchover between primary and standby processors, ensuring uninterrupted operation in the event of a failure.
Built in a standard module format, the TSXH5724M is compatible with various industrial setups. It can be easily installed into existing control systems, allowing for flexible configuration and scalability.
Equipped with integrated communication interfaces, including Ethernet TCP/IP, USB, and RS485, the TSXH5724M enables seamless connectivity with other devices and networks. This facilitates data exchange and integration within the automation environment.
The TSXH5724M processor supports a high I/O capacity, handling up to 1024 discrete I/O and 80 analog I/O. This allows for extensive control and monitoring of industrial processes and equipment.
With support for up to 24 application-specific channels and ten process control channels (expandable up to 30 simple loops), the TSXH5724M processor offers versatility and flexibility in system configuration. It can accommodate diverse control requirements and applications.
Featuring a PCMCIA card with 16384 kB of additional data storage, the TSXH5724M provides ample memory capacity for program and data storage. It includes internal RAM for program and data storage, ensuring efficient operation and data retention.
The TSXH5724M processor is compatible with Unity Pro software, providing users with a robust programming environment for developing and configuring control logic. Unity Pro offers a range of tools and features for streamlined development and maintenance of automation systems.
The TSXH5724M processor delivers high performance, with fast execution times per instruction for Boolean, word, fixed-point arithmetic, and floating-point operations. It supports a high number of instructions per millisecond, ensuring efficient control logic processing.
The TSXH5724M processor optimizes system performance and responsiveness with minimal system overhead. It operates with a master task execution time of 1 millisecond, ensuring timely execution of control tasks and operations.
The TSXH5724M processor is rugged and durable, built to withstand harsh industrial environments. It features protective treatment and complies with CE marking standards, ensuring reliability and safety in demanding industrial applications.
Q: What is the Schneider Electric TSXH5724M processor used for?
A: The Schneider Electric TSXH5724M processor is used for industrial automation control, providing redundancy and fault tolerance in critical applications. It supports high I/O capacity, integrated communication interfaces, and compatibility with Unity Pro software for efficient system configuration and operation.
Q: What are the key features of the TSXH5724M processor?
A: The TSXH5724M processor features Unity Hot Standby redundancy, high I/O capacity for discrete and analog I/O, integrated communication interfaces including Ethernet TCP/IP, USB, and RS485, support for application-specific and process control channels, ample memory and storage options, compatibility with Unity Pro software, and high execution performance with minimal system overhead.
Q: Is the TSXH5724M processor suitable for harsh industrial environments?
A: The TSXH5724M processor is designed to withstand harsh industrial environments. It features protective treatment, complies with CE marking standards, and offers rugged construction for reliability and durability in demanding industrial applications.
Q: What software is compatible with the TSXH5724M processor?
A: The TSXH5724M processor is compatible with Unity Pro software, which provides a robust programming environment for developing and configuring control logic. Unity Pro offers a range of tools and features for streamlined development and maintenance of automation systems.
Q: How does the TSXH5724M processor ensure system reliability?
A: The TSXH5724M processor ensures system reliability through Unity Hot Standby redundancy, which supports automatic switchover between primary and standby processors in case of failure. This provides uninterrupted operation and fault tolerance for critical industrial applications.
The Modicon Unity hot standby processor TSXH5724M is manufactured by Schneider Electric for use on the Modicon Premium automation platform. The Schneider Electric TSXH5724M uses Unity Pro software. These products are manufactured in France and are designed for Material handling, packaging, and textile machine usage. They come with a 2-year warranty from MRO Electric. We also carry CPUs from other manufacturers such as Modicon and ABB.
