Schneider Electric TSXP57103M

Rated 5/5 on 3 reviews

Rate this product

MANUFACTURER: Schneider Electric

DESCRIPTION: Single-Format PL7 Processor - 440 Ma 5 V DC

PRODUCT TYPE INFO: Modicon Premium

1 in stock

Ships Today

Free Shipping

2 Year warranty

Part NumberTSXP57103M
ManufacturerSchneider Electric
Model #TSX-P57-103M
Warranty2 Year
Module formatDouble
Product or component typeSingle-format PL7 processor
Number of racks2 12 slots
4 4/6/8 slots
Discrete I/O processor capacity512 I/O
Analogue I/O processor capacity24 I/O
Number of application specific channel≤ 8
Integrated connection typeSerial link 2 female mini DIN 19.2 kbit/s
Communication module processor1 network module
1 CANopen bus module
2 AS-Interface bus modules
Memory descriptionPCMCIA card 64 Kwords program
PCMCIA card 128 Kwords additional data storage
Internal RAM (with PCMCIA card) 32 Kwords data
Internal RAM (without PCMCIA card) 32 Kwords program and data
Software designationPL7 Junior/Pro
Protective treatmentTC
Number of slots≤ 32
Maximum size of object areas30.5 %MWi internal words located internal data
32 %KWi constant words located internal data
4096 %Mi located internal bits
Application structure1 fast task
1 master task
32 event tasks
Execution time per instruction0.5 µs Boolean without PCMCIA card
0.6 µs Boolean with PCMCIA card
0.62 µs word or fixed-point arithmetic without PCMCIA card
0.87 µs word or fixed-point arithmetic with PCMCIA card
44 µs floating points without PCMCIA card
44 µs floating points with PCMCIA card
Number of instructions per ms0.85 Kinst/ms 65 % Boolean + 35 % fixed arithmetic with PCMCIA card
1.05 Kinst/ms 65 % Boolean + 35 % fixed arithmetic without PCMCIA card
1.18 Kinst/ms 100 % Boolean with PCMCIA card
1.52 Kinst/ms 100 % Boolean without PCMCIA card
System overhead0.8 ms fast task
1.5 ms master task
Local signalling1 LED green processor running (RUN)
1 LED red processor or system fault (ERR)
1 LED red I/O module or configuration fault (I/O)
1 LED yellow activity on the terminal port (TER)
Current consumption440 mA 5 V DC

Our Repair Services

MRO Electric repairs CNCs, PLCs, Servo/Spindle Drives, Motors, Amplifiers, VFDs, HMIs, and more, most of which can be repaired in only 3-5 days.

Repair Benefits

MRO can restore your failed TSXP57103M to remanufactured condition and save you up to 75% compared to buying new. We offer standard repair pricing to ensure you the best value for your repair.

Our certified technicians use rigorous testing procedures to ensure your parts are restored to fully functioning condition. Our team proudly stands behind all repairs by providing a minimum 2-year warranty.

Our technicians have vast experience with most manufacturers and models. In addition to this TSXP57103M we also repair drives, motors, PLCs and more, so if you don’t see the model you need, please contact us.

Core Exchange

If you are interested in getting credit for your faulty TSXP57103M, just let us know, and we can issue you an RMA to send it in as an exchange. Our exchange program provides you with savings and keeps us stocked for the next time you need anything.

  • Shipping Weight : 1lb

Want it shipped today?

  • Order within the next 11 minutes.
  • If you order between 4pm and 6pm EST, you will be charged a small rush fee.

Ask about exchanging your faulty TSXP57103M for credit when ordering from MRO Electric

MRO Electric provides a 2-year warranty on every item we sell and repair. We stand behind all of our products and guarantee them for the full 2 years. If there is an issue with any of our products within the warranty period, we will evaluate the unit and repair or replace it under warranty.

Schneider Electric TSXP57103M Overview

Schneider Electric products are manufactured in France and are designed for Material handling, packaging, and textile machines usage. They come with a 2-year warranty from MRO Electric. We also carry CPUs from other manufacturers such as Modicon and ABB.

Schneider Electric TSXP57103M: A Powerful PLC for Industrial Control

The Schneider Electric TSXP57103M is a high-performance programmable logic controller (PLC) designed to meet the demanding automation needs of industrial applications. As part of the Schneider Electric product line, this PLC is known for its reliability, efficiency, and versatility, making it a popular choice among engineers and automation professionals.

Powerful Processing Capability:

The TSXP57103M is a single-format PL7 processor with a double module format. It offers exceptional processing power, making it suitable for complex control tasks in various industries. With a total of 12 slots in 2 racks, or 4, 6, or 8 slots in a single rack configuration, the PLC can handle extensive I/O requirements and manage diverse automation tasks seamlessly.

Flexible I/O Capacity:

This PLC boasts an impressive discrete I/O processor capacity of 512 I/O points, providing ample connectivity for various sensors, actuators, and other field devices. Additionally, its analog I/O processor capacity of 24 I/O points enables precise control and monitoring of analog signals. With support for up to 8 application-specific channels, the TSXP57103M allows customization for specific industrial requirements.

Extensive Communication Options:

The TSXP57103M offers multiple communication options, enhancing its ability to integrate with other automation systems and devices. It features a Serial Link 2 female mini-DIN port operating at 19.2 kbit/s for serial communication. Additionally, the PLC supports one network module, one CANopen bus module, and two AS-Interface bus modules, allowing seamless communication with a wide range of industrial networks and protocols.

Ample Memory and Software Support:

To support complex control programs and data storage, the PLC comes equipped with a PCMCIA card with 64 Kwords of program memory and 128 Kwords of additional data storage. It also features 32 Kwords of internal RAM for data storage when the PCMCIA card is inserted and 32 Kwords for program and data storage when the card is not in use. The PLC operates on the PL7 Junior/Pro software, providing a user-friendly programming environment and powerful tools for application development and debugging.

Efficient Execution Time:

The TSXP57103M excels in performance, offering impressive execution times per instruction. It can execute Boolean instructions as fast as 0.5 µs without a PCMCIA card and 0.6 µs with the card. For word or fixed-point arithmetic, the execution time is 0.62 µs without a card and 0.87 µs with it. Additionally, it delivers fast execution times of 44 µs for floating-point calculations, making it ideal for applications requiring high-speed processing.

Enhanced System Overhead and Diagnostics:

The PLC features a well-designed application structure with one fast task, one master task, and up to 32 event tasks, enabling efficient multitasking and event-driven programming. The system overhead for the fast task is only 0.8 ms, and for the master task, it is 1.5 ms, ensuring precise control and minimal processing delays.

Robust Design and Enhanced Safety:

Built with high-quality materials and protective treatment, the TSXP57103M is designed to withstand challenging industrial environments. It complies with CE marking standards, signifying its adherence to safety and performance requirements. The PLC is equipped with multiple LED indicators, providing clear local signaling for processor status, I/O module status, and terminal port activity.

Energy-Efficient Operation:

The TSXP57103M is designed with energy efficiency in mind, consuming a current of 440 mA at 5 V DC. This optimized power consumption ensures reduced energy costs and supports sustainable automation practices.


The Schneider Electric TSXP57103M is a powerful and feature-rich programmable logic controller that excels in complex automation tasks across various industries. With its high I/O capacity, extensive communication options, ample memory, and efficient execution times, it is a reliable and efficient solution for demanding automation applications. Whether used in manufacturing, process control, or other industrial settings, the TSXP57103M delivers exceptional performance, precise control, and seamless integration, making it a valuable asset in the world of industrial automation. Its durability, user-friendly software support, and energy-efficient operation further contribute to its position as a leading PLC in the market, meeting the evolving needs of modern industrial automation.
