MODICON PREMIUM DOUBLE-FORMAT PL7 PROCESSOR - TRANSPARENT READY - 1110 MA 5 V DC
1 Available
Free Shipping
2 Year warranty
| Part Number | TSXP572623M |
| Manufacturer | Schneider Electric |
| Type | CPUs |
| Model # | TSX-P57-2623M |
| Warranty | 2 Year |
| Module format | Double |
| Product or component type | Double-format PL7 processor |
| Number of racks | 8 12 slots |
| 16 4/6/8 slots | |
| Discrete I/O processor capacity | 1024 I/O |
| Analogue I/O processor capacity | 80 I/O |
| Number of application specific channel | ≤ 24 |
| Number of process control channel | ≤ 10 up to 30 simple loops |
| Integrated connection type | Ethernet TCP/IP RJ45 10/100 Mbit/s |
| Serial link 2 female mini DIN 19.2 kbit/s | |
| Communication module processor | 1 CANopen bus module |
| 1 fieldbus module (none if CANopen used) | |
| 4 AS-Interface bus modules | |
| Memory description | PCMCIA card 160 Kwords program |
| PCMCIA card 2688 Kwords additional data storage | |
| Internal RAM (with PCMCIA card) 48 Kwords data | |
| Internal RAM (without PCMCIA card) 48 Kwords program and data | |
| Software designation | PL7 Junior/Pro |
| Protective treatment | TC |
| Concept | Transparent Ready |
| Number of slots | ≤ 128 |
| Maximum size of object areas | 30.5 %MWi internal words located internal data |
| 32 %KWi constant words located internal data | |
| 8132 %Mi located internal bits | |
| Application structure | 1 fast task |
| 1 master task | |
| 64 event tasks | |
| Execution time per instruction | 0.19 µs Boolean without PCMCIA card |
| 0.21 µs Boolean with PCMCIA card | |
| 0.25 µs word or fixed-point arithmetic without PCMCIA card | |
| 0.42 µs word or fixed-point arithmetic with PCMCIA card | |
| 2.6 µs floating points without PCMCIA card | |
| 2.6 µs floating points with PCMCIA card |
| Number of instructions per ms | 2.5 Kinst/ms 65 % Boolean + 35 % fixed arithmetic with PCMCIA card |
| 3.57 Kinst/ms 65 % Boolean + 35 % fixed arithmetic without PCMCIA card | |
| 3.7 Kinst/ms 100 % Boolean with PCMCIA card | |
| 4.76 Kinst/ms 100 % Boolean without PCMCIA card | |
| System overhead | 0.35 ms fast task |
| 1 ms master task | |
| Marking | CE |
| Local signalling | 1 LED green processor running (RUN) |
| 1 LED red processor or system fault (ERR) | |
| 1 LED red I/O module or configuration fault (I/O) | |
| 1 LED yellow activity on the terminal port (TER) | |
| 1 LED green Ethernet TCP/IP port ready (RUN) | |
| 1 LED red Ethernet TCP/IP port fault (ERR) | |
| 1 LED red collision detection (COL) | |
| 1 LED yellow Ethernet link diagnostics (STS) | |
| 1 LED yellow transmission activity (TX) | |
| 1 LED yellow reception activity (RX) | |
| Current consumption | 1110 mA 5 V DC |
MRO Electric repairs CNCs, PLCs, Servo/Spindle Drives, Motors, Amplifiers, VFDs, HMIs, and more, most of which can be repaired in only 3-5 days.
MRO can restore your failed TSXP572623M to remanufactured condition and save you up to 75% compared to buying new. We offer standard repair pricing to ensure you the best value for your repair.
Our certified technicians use rigorous testing procedures to ensure your parts are restored to fully functioning condition. Our team proudly stands behind all repairs by providing a minimum 2-year warranty.
Our technicians have vast experience with most manufacturers and models. In addition to this TSXP572623M we also repair drives, motors, PLCs and more, so if you don’t see the model you need, please contact us.
If you are interested in getting credit for your faulty TSXP572623M, just let us know, and we can issue you an RMA to send it in as an exchange. Our exchange program provides you with savings and keeps us stocked for the next time you need anything.
Want it shipped today?
Ask about exchanging your faulty TSXP572623M for credit when ordering from MRO Electric
The Schneider Electric TSXP572623M is a double-format PL7 processor, which is designed to operate with the Modicon PLCs. It is equipped with a variety of features and specifications, making it a reliable and efficient component for various applications. These products are manufactured in France and are designed for Material handling, packaging, and textile machines usage. They come with a 2-year warranty from MRO Electric. We also carry CPUs from other manufacturers such as Modicon and ABB.
The TSXP572623M is a double-format PL7 processor, which means it has two separate racks, each of which can hold up to 8 12-slot or 16 4/6/8-slot I/O processors. It has a discrete I/O processor capacity of 1024 I/O and an analog I/O processor capacity of 80 I/O. Additionally, it can have up to 24 application-specific channels and up to 10 to 30 simple loops of process control channels.
The TSXP572623M has a built-in Ethernet TCP/IP RJ45 connection for seamless communication, along with a serial link with 2 female mini DIN 19.2 kbit/s. It also features a communication module processor with one CANopen bus module, one fieldbus module (none if CANopen is used), and four AS-Interface bus modules. The device's memory is described as a PCMCIA card with a 160 Kwords program and 2688 Kwords additional data storage. The internal RAM with a PCMCIA card has 48 Kwords of data storage, and without it, 48 Kwords of program and data storage.
The TSXP572623M is compatible with the PL7 Junior/Pro software and is designed to protect against environmental factors with its TC protective treatment. It is also Transparent Ready, which means it can be easily integrated with other systems. The device's slots can support up to 128 object areas, with 30.5 %MWi internal words located in internal data, 32 %KWi constant words located in internal data, and 8132 %Mi located internal bits.
Regarding its performance, the TSXP572623M has an execution time per instruction of 0.19 µs Boolean without PCMCIA card, 0.21 µs Boolean with PCMCIA card, 0.25 µs word or fixed-point arithmetic without PCMCIA card, 0.42 µs word or fixed-point arithmetic with PCMCIA card, 2.6 µs floating points without PCMCIA card, and 2.6 µs floating points with PCMCIA card. The device can execute 2.5 Kinst/ms 65 % Boolean + 35 % fixed arithmetic with a PCMCIA card, 3.57 Kinst/ms 65 % Boolean + 35 % fixed arithmetic without a PCMCIA card, 3.7 Kinst/ms 100 % Boolean with a PCMCIA card, and 4.76 Kinst/ms 100 % Boolean without PCMCIA card. The system overhead is 0.35 ms fast task and 1 ms master task.
The TSXP572623M has several LED indicators to provide local signalings, such as a green LED for processor running (RUN), a red LED for processor or system fault (ERR), and a yellow LED for activity on the terminal port (TER), and more. The device consumes a current of 1110 mA 5 V DC.
What is the Schneider Electric TSXP572623M?
The TSXP572623M is a double-format PL7 processor from Schneider Electric, designed for use in modular programmable logic controllers (PLCs). This CPU offers high performance and is suitable for complex automation systems with multiple I/O and communication modules. It supports Ethernet TCP/IP and serial communication, making it versatile for various industrial applications.
How many I/O points does the TSXP572623M CPU support?
The CPU supports a discrete I/O processor capacity of 1024 I/O points and an analog I/O processor capacity of up to 80 I/O points. This extensive I/O capacity allows the CPU to handle various inputs and outputs for complex automation tasks.
What types of communication interfaces are integrated into this CPU?
The TSXP572623M features integrated Ethernet TCP/IP with an RJ45 connector supporting 10/100 Mbit/s speeds, as well as a serial link through two female mini-DIN ports with speeds of up to 19.2 kbit/s. These interfaces enable accessible communication with other devices and networks in the system.
Can the TSXP572623M support communication modules?
Yes, the CPU can support various communication modules. It includes 1 CANopen bus module, one fieldbus module (unless a CANopen bus module is used), and up to 4 AS-Interface bus modules. This flexibility in communication modules allows for connectivity with various industrial protocols.
How much memory does the TSXP572623M have?
The CPU comes with internal RAM and supports additional memory via PCMCIA cards. It has 48 K words of internal RAM, which can be used for both program and data storage. Additionally, it supports PCMCIA cards with 160 K words for program storage and up to 2688 K words for additional data storage.
What are the execution times for instructions on this CPU?
The execution time per instruction depends on the type of operation and whether a PCMCIA card is used. For Boolean instructions, it ranges from 0.19 µs to 0.21 µs. For word or fixed-point arithmetic, it ranges from 0.25 µs to 0.42 µs, and for floating-point operations, it is 2.6 µs.
What is the maximum number of racks and slots the TSXP572623M can handle?
Depending on the configuration, this CPU can support up to 8 racks with 12 slots or 16 racks with 4/6/8 slots. This provides flexibility in expanding the system based on the specific needs of the automation process.
What is the current consumption of the TSXP572623M CPU?
The CPU consumes 1110 mA at 5 V DC, the standard for a high-performance PLC processor.
What are the diagnostic and status indicators on the TSXP572623M?
The CPU features several LEDs for local signaling, including indicators for processor status (RUN), processor or system faults (ERR), I/O module or configuration faults (I/O), Ethernet status (RUN, ERR, COL, STS), and transmission/reception activities (TX, RX). These indicators provide valuable information for monitoring system health and performance.
Does the TSXP572623M come with a warranty?
Yes, the Schneider Electric TSXP572623M comes with a 2-year warranty from MRO Electric and Supply, and free shipping is available when purchased from this supplier.
