MANUFACTURER: Schneider Electric
DESCRIPTION: Double-Format PL7 Processor - Transparent Ready - 1440 Ma
PRODUCT TYPE INFO: Modicon Premium


Free Shipping
2 Year warranty
Part NumberTSXP574823AM
ManufacturerSchneider Electric
Model #TSXP574823AM
Warranty2 Year
Module formatDouble
Product or component typeDouble-format PL7 processor
Software designationPL7 Junior/Pro
ConceptTransparent Ready
Number of racks8 12 slots
16 4/6/8 slots
Number of slots<= 128
Discrete I/O processor capacity2040 I/O
Analogue I/O processor capacity256 I/O
Number of application specific channel<= 64
Number of process control channel<= 20 up to 60 simple loops
Integrated connection typeNon isolated serial link 2 female mini DIN 19.2/115 kbit/s
Ethernet TCP/IP RJ45 10/100 Mbit/s
Fipio manager (127 agents) SUB-D 9
Communication module processor8 AS-Interface bus modules
4 network modules
2 fieldbus modules (1 if CANopen used)
1 CANopen bus module
Memory descriptionPCMCIA card 992 Kwords program
PCMCIA card 2048 Kwords additional data storage
Internal RAM (without PCMCIA card) 96 Kwords program and data
Internal RAM (with PCMCIA card) 176 Kwords data
Maximum size of object areas32768 %Mi located internal bits
32 %KWi constant words located internal data
30.5 %MWi internal words located internal data
Application structure1 fast task
1 master task
64 event tasks
Execution time per instruction1.7 µs floating points without PCMCIA card
1.7 µs floating points with PCMCIA card
0.08 µs word or fixed-point arithmetic without PCMCIA card
0.08 µs word or fixed-point arithmetic with PCMCIA card
0.06 µs Boolean without PCMCIA card
0.06 µs Boolean with PCMCIA card
Number of instructions per ms8.8 Kinst/ms 65 % Boolean + 35 % fixed arithmetic without PCMCIA card
8.8 Kinst/ms 65 % Boolean + 35 % fixed arithmetic with PCMCIA card
13.82 Kinst/ms 100 % Boolean without PCMCIA card
13.82 Kinst/ms 100 % Boolean with PCMCIA card
System overhead1.15 ms master task
0.22 ms fast task
Local signalling1 LED yellow transmission activity (TX)
1 LED yellow reception activity (RX)
1 LED yellow Ethernet link diagnostics (STS)
1 LED yellow activity on the terminal port (TER)
1 LED red processor or system fault (ERR)
1 LED red I/O module or configuration fault (I/O)
1 LED red Ethernet TCP/IP port fault (ERR)
1 LED red collision detection (COL)
1 LED red activity on Fipio bus (FIP)
1 LED green processor running (RUN)
1 LED green Ethernet TCP/IP port ready (RUN)
Current consumption1440 mA 5 V DC

Our Repair Services

MRO Electric repairs CNCs, PLCs, Servo/Spindle Drives, Motors, Amplifiers, VFDs, HMIs, and more, most of which can be repaired in only 3-5 days.

Repair Benefits

MRO can restore your failed TSXP574823AM to remanufactured condition and save you up to 75% compared to buying new. We offer standard repair pricing to ensure you the best value for your repair.

Our certified technicians use rigorous testing procedures to ensure your parts are restored to fully functioning condition. Our team proudly stands behind all repairs by providing a minimum 2 year warranty.

Our technicians have vast experience with most manufacturers and models. In addition to this TSXP574823AM we also repair drives, motors, PLCs and more, so if you don’t see the model you need, please contact us.

Core Exchange

If you are interested in getting credit for your faulty TSXP574823AM, just let us know and we can issue you an RMA to send it in as an exchange. Our exchange program provides you with savings and keeps us stocked for the next time you need anything.

  • Shipping Weight : 2lbs

Want it shipped today?

  • Order within the next 15 hours and 30 minutes.
  • If you order between 4pm and 6pm EST, you will be charged a small rush fee.

Ask about exchanging your faulty TSXP574823AM for credit when ordering from MRO Electric

MRO Electric provides a 2-year warranty on every item we sell and repair. We stand behind all of our products and guarantee them for the full 2 years. If there is an issue with any of our products within the warranty period, we will evaluate the unit and repair or replace it under warranty.

Additional Information

Product Description

The TSXP574823AM is a Double-Format PL7 Processor - Transparent Ready -... that is manufactured by Schneider Electric. These products are manufactured in France and are designed for Material handling, packaging, and textile machines usage. All of the products come with a 2 year warranty from MRO Electric. We also carry CPUs from other manufacturers such as Modicon and ABB.
