TSXPSY8500M

TSXPSY8500M

Rated 5/5 on 1 review

Rate this product


MANUFACTURER: Schneider Electric
DESCRIPTION: Power Supply Module - 5 V DC - 500/1700 Ma - 75 W
PRODUCT TYPE INFO: Modicon Premium


Available

Free Shipping
2 Year warranty

Categories

Part NumberTSXPSY8500M
ManufacturerSchneider Electric
SeriesModicon Premium
Model #TSXPSY8500M
Alternate ModelTSX-PSY-8500M
TypePLC
Warranty2 Year
Module formatDouble
Product or component typePower supply module
Primary voltage100...120 V AC 85...140 V
200...240 V AC 170...264 V
Network frequency50/60 Hz
Network frequency limits47...63 Hz
Power supply input current1700 mA 100 V
500 mA 240 V
Inrush current30 A 100 V
60 A 240 V
I²t on activation15 A².s 100 V
8 A².s 240 V
It on activation0.15 A.s 100 V
0.15 A.s 240 V
Protection typeInternal fuse 4 A 5 x 20 mm time-delayed primary circuit
Overload protection secondary circuit
Overvoltage protection secondary circuit
Short-circuit protection secondary circuit
Total useful secondary power100 W at 55 °C with fan module
77 W at 60 °C
85 W at 55 °C
Secondary power75 W 5 V DC
Current at secondary voltage1.6 A 24 V DC sensor power supply
15 A 5 V DC
Insulation resistance>= 100 MOhm primary/ground
>= 100 MOhm primary/secondary
MarkingCE
Local signalling1 LED green presence of sensor voltage (24V)
1 LED green presence of voltages (OK)
1 LED red battery fault (BAT)

Our Repair Services

MRO Electric repairs CNCs, PLCs, Servo/Spindle Drives, Motors, Amplifiers, VFDs, HMIs, and more, most of which can be repaired in only 3-5 days.

Repair Benefits

MRO can restore your failed TSXPSY8500M to remanufactured condition and save you up to 75% compared to buying new. We offer standard repair pricing to ensure you the best value for your repair.

Our certified technicians use rigorous testing procedures to ensure your parts are restored to fully functioning condition. Our team proudly stands behind all repairs by providing a minimum 2 year warranty.

Our technicians have vast experience with most manufacturers and models. In addition to this TSXPSY8500M we also repair drives, motors, PLCs and more, so if you don’t see the model you need, please contact us.

Core Exchange

If you are interested in getting credit for your faulty TSXPSY8500M, just let us know and we can issue you an RMA to send it in as an exchange. Our exchange program provides you with savings and keeps us stocked for the next time you need anything.

  • Shipping Weight : 1lb

Want it shipped today?

  • Order within the next 4 hours and 27 minutes.
  • If you order between 4pm and 6pm EST, you will be charged a small rush fee.

Ask about exchanging your faulty TSXPSY8500M for credit when ordering from MRO Electric

MRO Electric provides a 2-year warranty on every item we sell and repair. We stand behind all of our products and guarantee them for the full 2 years. If there is an issue with any of our products within the warranty period, we will evaluate the unit and repair or replace it under warranty.

Additional Information

Product Description

The TSXPSY8500M is a Power Supply Module - 5 V DC - 500/1700 Ma - 75 W that is manufactured by Schneider Electric. These products are manufactured in France and are designed for Material handling, packaging, and textile machines usage. All of the products in the modicon-premium line come with a 2 year warranty from MRO Electric. We also carry TSX from other manufacturers such as Modicon and ABB.
