XBTGT2220

2-year Warranty

Same Day Shipping

Schneider Electric XBTGT2220

HMIS ADVANCED TOUCHSCREEN PANEL 320 X 240 PIXELS QVGA - 5.7 - 24 V

5/5
1 rating

Select Condition

Refurbished

1 in stock

New

1 in stock

$1,995.00

Request a formal quote

  • Ships Today
  • 2 Year Warranty
  • Free Shipping
Part NumberXBTGT2220
ManufacturerSchneider Electric
TypeHMIs
Warranty2 Year
Product weight1 kg
Range of productMagelis XBTGT
Product or component typeAdvanced touchscreen panel
Display typeBacklit colour STN LCD
Display colour4096 colours
Display resolution320 x 240 pixels QVGA
Display size5.7 inch
Software typeConfiguration software
Software designationVijeo Designer
Operating systemMagelis
Processor nameCPU RISC
Processor frequency133 MHz
Memory descriptionBack up of data SRAM 512 kB lithium battery
Resistance to electrostatic discharge6 kV IEC 61000-4-2 level 3
Cut-out dimensions156 (+ 1/- 0) x 123.5 (+ 1/- 0) mm
Touch sensitive zone1024 x 1024
Touch panelAnalogue
Brightness8 levels via touch panel
Contrast8 levels via touch panel
Character fontASCII (European characters)
Chinese (simplified Chinese)
Japanese (ANK, Kanji)
Korean
Taiwanese (traditional Chinese)
[Us] rated supply voltage24 V DC
SupplyExternal source
Supply voltage limits19.2...28.8 V
Inrush current<= 30 A
Power consumption26 W
Local signalling1 LED (green or orange) for normal operation or backlighting faulty
Number of pagesLimited by internal memory capacity
Downloadable protocolsFIPWAY Telemecanique Modicon
Modbus TCP/IP Telemecanique Modicon
Uni-TE Telemecanique Modicon
Third party protocols Omron Sysmac
Modbus Telemecanique Modicon
Third party protocols Rockwell Automation Allen-Bradley
Modbus Plus Telemecanique Modicon
Third party protocols Mitsubishi Melsec
Third party protocols Siemens Simatic
Realtime clockBuilt-in
Memory type1 slot for Compact Flash card (128 MB to 1 GB)
Use of slotFor 1 fieldbus communication card (Device Net, Profibus DP)
Product mountingFlush mounting
Fixing modeBy 2 spring clips
By 4 screw clamps
Enclosure materialPPT
MarkingCE
Width167.5 mm
Height135 mm
Depth59.5 mm

Our Repair Services

MRO Electric repairs CNCs, PLCs, Servo/Spindle Drives, Motors, Amplifiers, VFDs, HMIs, and more, most of which can be repaired in only 3-5 days.

Repair Benefits

MRO can restore your failed XBTGT2220 to remanufactured condition and save you up to 75% compared to buying new. We offer standard repair pricing to ensure you the best value for your repair.

Our certified technicians use rigorous testing procedures to ensure your parts are restored to fully functioning condition. Our team proudly stands behind all repairs by providing a minimum 2-year warranty.

Our technicians have vast experience with most manufacturers and models. In addition to this XBTGT2220 we also repair drives, motors, PLCs and more, so if you don’t see the model you need, please contact us.

Core Exchange

If you are interested in getting credit for your faulty XBTGT2220, just let us know, and we can issue you an RMA to send it in as an exchange. Our exchange program provides you with savings and keeps us stocked for the next time you need anything.

  • Shipping Weight : 3lbs

Want it shipped today?

  • Order within the next 7 hours and 6 minutes.
  • If you order between 4pm and 6pm EST, you will be charged a small rush fee.

Ask about exchanging your faulty XBTGT2220 for credit when ordering from MRO Electric

MRO Electric provides a 2-year warranty on every item we sell and repair. We stand behind all of our products and guarantee them for the full 2 years. If there is an issue with any of our products within the warranty period, we will evaluate the unit and repair or replace it under warranty.

Schneider Electric XBTGT2220 Overview

Schneider Electric Magelis XBTGT2220: Advanced Touchscreen HMI

The Schneider Electric Magelis XBTGT2220, part of the Magelis XBTGT series, is a high-performance Human-Machine Interface (HMI) designed to facilitate efficient control and monitoring in various industrial settings. Known for its advanced functionality and user-friendly features, this 5.7-inch touchscreen panel offers extensive display options, flexible software compatibility, and robust build quality, making it a popular choice for automation tasks in manufacturing, energy, and processing industries.

Display and Usability Features

The XBTGT2220 has a backlit STN LCD that provides 4096 colors at a resolution of 320 x 240 pixels (QVGA), offering a clear and vibrant display for real-time data monitoring. The 5.7-inch screen size balances compactness and readability, making it suitable for smaller spaces without sacrificing usability. The touchscreen panel is highly responsive, featuring a 1024 x 1024 touch-sensitive grid that supports easy interaction through its analog touch capabilities. The screen brightness and contrast can be adjusted through eight levels to accommodate different lighting conditions directly accessible via the touch panel.

Processing Power and Software Compatibility

Powered by a 133 MHz RISC CPU, the XBTGT2220 can efficiently handle real-time data processing. It operates on the Magelis operating system and is compatible with Schneider Electric's Vijeo Designer configuration software, simplifying setup and customization. The user-friendly software supports various downloadable communication protocols for seamless integration with multiple industrial systems. Supported protocols include Modbus TCP/IP, Modbus Plus, and FIPWAY for Telemecanique Modicon, as well as third-party protocols for Omron Sysmac, Rockwell Allen-Bradley, Siemens Simatic, and Mitsubishi Melsec, providing versatile connectivity across platforms.

Memory and Data Storage

The HMI includes 512 kB SRAM memory for data backup, safeguarded by a lithium battery to prevent data loss in case of power failure. Additionally, the XBTGT2220 features a compact flash card slot that supports storage capacities from 128 MB to 1 GB, allowing users to expand data storage according to the application's needs. This slot can also be used for Fieldbus communication cards like DeviceNet or Profibus DP, further enhancing its communication capabilities.

Power and Durability

Operating on an external 24 V DC power supply, the XBTGT2220 can handle voltage limits ranging from 19.2 to 28.8 V DC, making it adaptable to various power environments. Its inrush current is limited to 30 A, with a maximum power consumption of 26 W, ensuring energy-efficient operation. The enclosure is made from durable PPT material. It is designed for flush mounting, secured either by two spring clips or four screw clamps, providing stability and reliability in industrial settings.

Safety and Compliance

Built to withstand industrial conditions, the XBTGT2220 is resistant to electrostatic discharge up to 6 kV, adhering to IEC 61000-4-2 Level 3 standards. The unit features a green or orange LED for local signaling, indicating operational status or alerting users to backlighting issues. Certified with a CE marking, this model meets international safety and quality standards, underscoring Schneider Electric's commitment to reliability and user safety.

Typical Applications

The Schneider Electric Magelis XBTGT2220 HMI is ideal for applications requiring reliable real-time monitoring and control, including:

  • Manufacturing automation and process control
  • Power generation and energy management
  • Material handling and packaging systems
  • Complex machinery operations
  • Transportation and logistics automation

Technical Specifications

  • Display Type: Backlit color STN LCD
  • Resolution: 320 x 240 pixels (QVGA)
  • Touch Panel: Analogue, 1024 x 1024 sensitivity
  • Processor: 133 MHz CPU RISC
  • Memory: 512 kB SRAM, Compact Flash slot (128 MB to 1 GB)
  • Supported Protocols: Modbus TCP/IP, Modbus Plus, FIPWAY, Omron Sysmac, Allen-Bradley, Siemens Simatic, Mitsubishi Melsec
  • Supply Voltage: 24 V DC (19.2–28.8 V)
  • Dimensions: Width 167.5 mm, Height 135 mm, Depth 59.5 mm
  • Mounting: Flush, with spring clips or screw clamps

FAQs

What is the primary purpose of the Magelis XBTGT2220 HMI?

The XBTGT2220 is an advanced HMI designed for real-time control and monitoring in industrial applications. Users need an intuitive interface for automation and system adjustments.

Which software is compatible with this HMI?

The XBTGT2220 is compatible with Schneider Electric's Vijeo Designer configuration software, which allows users to efficiently set up and customize their HMI interface.

What communication protocols does the XBTGT2220 support?

This model supports a range of protocols, including Modbus TCP/IP, Modbus Plus, and FIPWAY, as well as third-party protocols for Omron, Allen-Bradley, Siemens, and Mitsubishi systems.

How is data stored on the XBTGT2220?

Data is stored using 512 kB of SRAM backed up by a lithium battery. The unit includes a Compact Flash slot that supports 128 MB to 1 GB cards for additional storage.

What safety certifications does this HMI have?

The XBTGT2220 carries a CE marking and complies with IEC 61000-4-2 standards, ensuring safety against electrostatic discharge and adherence to international quality standards.
