XBTGT2330

2-year Warranty

Same Day Shipping

Schneider Electric XBTGT2330

MODICON MAGELIS ADVANCED TOUCHSCREEN PANEL - 320 X 240 PIXELS QVGA - 5.7 TFT LCD - 24 V DC

5/5
2 ratings

Select Condition

Refurbished

2 in stock

New

1 in stock

$1,473.00

Request a formal quote

  • Ships Today
  • 2 Year Warranty
  • Free Shipping
Part NumberXBTGT2330
ManufacturerSchneider Electric
TypeHMIs
Warranty2 Year
Product weight1 kg
Range of productMagelis XBTGT
Product or component typeAdvanced touchscreen panel
Display typeBacklit colour TFT LCD
Display colour65536 colours
Display resolution320 x 240 pixels QVGA
Display size5.7 inch
Software typeConfiguration software
Software designationVijeo Designer
Operating systemMagelis
Processor nameCPU RISC
Processor frequency133 MHz
Memory descriptionBack up of data SRAM 512 kB lithium battery
Integrated connection typeCOM1 serial link male SUB-D 9 RS232C/RS422/RS485 <= 115.2 kbits/s
Resistance to electrostatic discharge6 kV IEC 61000-4-2 level 3
Cut-out dimensions156 (+ 1/- 0) x 123.5 (+ 1/- 0) mm
Touch sensitive zone1024 x 1024
Touch panelAnalogue
Brightness8 levels via touch panel
Character fontASCII (European characters)
Chinese (simplified Chinese)
Japanese (ANK, Kanji)
Korean
Taiwanese (traditional Chinese)
[Us] rated supply voltage24 V DC
SupplyExternal source
Supply voltage limits19.2...28.8 V
Inrush current<= 30 A
Power consumption26 W
Local signalling1 LED (green or orange) for normal operation or backlighting faulty
Number of pagesLimited by internal memory capacity
Downloadable protocolsModbus Plus Telemecanique Modicon
Third party protocols Mitsubishi Melsec
Third party protocols Rockwell Automation Allen-Bradley
Third party protocols Siemens Simatic
Modbus Telemecanique Modicon
FIPWAY Telemecanique Modicon
Modbus TCP/IP Telemecanique Modicon
Third party protocols Omron Sysmac
Uni-TE Telemecanique Modicon
Realtime clockBuilt-in
Memory type1 slot for Compact Flash card (128 MB to 1 GB)
Use of slotFor 1 fieldbus communication card (Device Net, Profibus DP)
Port Ethernet10BASE-T/100BASE-TX
Product mountingFlush mounting
Fixing modeBy 2 spring clips
By 4 screw clamps
Enclosure materialPPT
MarkingCE
Width167.5 mm
Height135 mm
Depth59.5 mm

Our Repair Services

MRO Electric repairs CNCs, PLCs, Servo/Spindle Drives, Motors, Amplifiers, VFDs, HMIs, and more, most of which can be repaired in only 3-5 days.

Repair Benefits

MRO can restore your failed XBTGT2330 to remanufactured condition and save you up to 75% compared to buying new. We offer standard repair pricing to ensure you the best value for your repair.

Our certified technicians use rigorous testing procedures to ensure your parts are restored to fully functioning condition. Our team proudly stands behind all repairs by providing a minimum 2-year warranty.

Our technicians have vast experience with most manufacturers and models. In addition to this XBTGT2330 we also repair drives, motors, PLCs and more, so if you don’t see the model you need, please contact us.

Core Exchange

If you are interested in getting credit for your faulty XBTGT2330, just let us know, and we can issue you an RMA to send it in as an exchange. Our exchange program provides you with savings and keeps us stocked for the next time you need anything.

  • Shipping Weight : 3lbs

Want it shipped today?

  • Order within the next 13 hours and 28 minutes.
  • If you order between 4pm and 6pm EST, you will be charged a small rush fee.

Ask about exchanging your faulty XBTGT2330 for credit when ordering from MRO Electric

What is the replacement part number for the Magelis XBTGT2330 HMI?

  • The part number for the color touch panel replacement is HMIGTO2310.
MRO Electric provides a 2-year warranty on every item we sell and repair. We stand behind all of our products and guarantee them for the full 2 years. If there is an issue with any of our products within the warranty period, we will evaluate the unit and repair or replace it under warranty.

Schneider Electric XBTGT2330 Overview

Schneider Electric HMI Model XBTGT2330

The Schneider Electric XBTGT2330 is an advanced touchscreen panel designed for human-machine interface (HMI) applications, offering exceptional performance and reliability. As part of the Magelis XBTGT range, this HMI is known for its robustness and versatility, making it an excellent choice for various industrial settings that require efficient and user-friendly interface solutions.

Design and Display

The XBTGT2330 features a backlit color TFT LCD with a display resolution of 320 x 240 pixels (QVGA), supporting up to 65536 colors. This 5.7-inch display ensures clear and vibrant visuals, crucial for monitoring and controlling industrial processes. The high-quality display, combined with the touch-sensitive zone of 1024 x 1024, allows for precise and responsive touch interactions. The analog touch panel further enhances the user experience, offering eight levels of brightness adjustment through the touch panel for optimal visibility in different lighting conditions.

Processing Power and Memory

At the core of the XBTGT2330 is a CPU RISC processor running at 133 MHz. This processor provides sufficient computing power to handle complex HMI tasks efficiently. The HMI is equipped with 512 kB of SRAM for data backup, powered by a lithium battery, ensuring that critical data is preserved even during a power loss. Additionally, the unit includes a slot for a Compact Flash card, supporting memory capacities from 128 MB to 1 GB, which can be used for storage expansion or Fieldbus communication cards such as DeviceNet or Profibus DP.

Connectivity and Communication

The XBTGT2330 offers a variety of integrated connection types, including a COM1 serial link with a male SUB-D 9 connector supporting RS232C, RS422, and RS485 protocols with data rates up to 115.2 kbits/s. For networking, it includes an Ethernet port supporting 10BASE-T/100BASE-TX standards. This extensive connectivity is further enhanced by support for various communication protocols, including Modbus Plus, Modbus TCP/IP, and third-party protocols from Mitsubishi Melsec, Rockwell Automation Allen-Bradley, Siemens Simatic, and Omron Sysmac. This flexibility ensures seamless integration with various industrial devices and systems.

Software and Operating System

The HMI operates on the Magelis operating system and is configured using Vijeo Designer software. This software suite provides a comprehensive set of tools for creating and managing HMI applications, making it easier for engineers to design intuitive and effective interfaces.

Physical Specifications and Durability

The XBTGT2330 is designed for durability and ease of installation. It has cut-out dimensions of 156 (+1/-0) x 123.5 (+1/-0) mm and can be mounted flush using either spring clips or screw clamps. The enclosure material is PPT, which is known for its strength and resilience. The device is marked with CE certification, ensuring compliance with European safety and quality standards. Additionally, it offers resistance to electrostatic discharge up to 6 kV, according to IEC 61000-4-2 level 3 standards, enhancing its reliability in industrial environments.

Power and Consumption

The HMI operates on an external 24 V DC supply, with voltage limits ranging from 19.2 to 28.8 V. It consumes 26 W and can handle an inrush current of up to 30 A. Local signaling is provided by a green or orange LED, indicating normal operation or a backlighting fault, respectively.

Versatility and Applications

Given its advanced features, robust design, and extensive connectivity options, the Schneider Electric XBTGT2330 HMI is ideal for various industrial applications. It is particularly suited for environments where reliable, transparent, and responsive human-machine interaction is critical. From factory automation to process control systems, the XBTGT2330 enhances operational efficiency and ensures seamless integration with existing industrial infrastructure.

Frequently Asked Questions (FAQ) about Schneider Electric HMI Model XBTGT2330

What type of applications is the Schneider Electric XBTGT2330 HMI suitable for?

The Schneider Electric XBTGT2330 HMI is ideal for industrial applications requiring efficient and user-friendly interfaces. It is particularly well-suited for factory automation, process control systems, and any environment where reliable, transparent, and responsive human-machine interaction is essential.

What are the display specifications of the XBTGT2330?

The XBTGT2330 features a 5.7-inch backlit color TFT LCD with a resolution of 320 x 240 pixels (QVGA) and supports up to 65536 colors. This ensures vibrant and clear visuals, enhancing the user experience in monitoring and controlling processes.

What kind of touch technology does the XBTGT2330 use?

The XBTGT2330 uses an analog touch panel with a touch-sensitive zone of 1024 x 1024. It allows for precise and responsive touch interactions and features eight levels of brightness adjustment via the touch panel.

How is the XBTGT2330 configured, and what software is used?

The XBTGT2330 is configured using Vijeo Designer software. This software provides a comprehensive set of tools for creating and managing HMI applications, facilitating the design of intuitive and effective user interfaces.

What processors and memory does the XBTGT2330 have?

The XBTGT2330 is powered by a CPU RISC processor running at 133 MHz. It includes 512 kB of SRAM for data backup, supported by a lithium battery. Additionally, it has a slot for a Compact Flash card with capacities ranging from 128 MB to 1 GB for storage expansion or fieldbus communication cards.

What types of connectivity options are available on the XBTGT2330?

The XBTGT2330 offers various connectivity options, including a COM1 serial link with a male SUB-D 9 connector that supports RS232C, RS422, and RS485 protocols and data rates up to 115.2 kbits/s. It also includes an Ethernet port that supports 10BASE-T/100BASE-TX standards, allowing for seamless integration with industrial networks.

What communication protocols does the XBTGT2330 support?

The XBTGT2330 supports several communication protocols, including Modbus Plus, Modbus TCP/IP, and third-party protocols from Mitsubishi Melsec, Rockwell Automation Allen-Bradley, Siemens Simatic, and Omron Sysmac. This wide range of protocol support ensures compatibility with various industrial devices and systems.

What are the physical dimensions and mounting options for the XBTGT2330?

The XBTGT2330 has cut-out dimensions of 156 (+1/-0) x 123.5 (+1/-0) mm and can be mounted flush using either spring clips or screw clamps. Its enclosure is made of durable PPT material, and its dimensions are 167.5 mm in width, 135 mm in height, and 59.5 mm in depth.

How does the XBTGT2330 handle power supply and consumption?

The XBTGT2330 operates on an external 24 V DC power supply, with voltage limits ranging from 19.2 to 28.8 V. It has a power consumption of 26 W and can handle an inrush current of up to 30 A.

What kind of local signaling does the XBTGT2330 provide?

The XBTGT2330 features an LED indicator that turns green or orange to signal normal operation or a backlighting fault, respectively. This local signaling helps users quickly identify the device's operational status.

Is the XBTGT2330 resistant to electrostatic discharge?

Yes, according to IEC 61000-4-2 level 3 standards, the XBTGT2330 is resistant to electrostatic discharge up to 6 kV. This feature enhances its reliability and durability in industrial environments.

What is the weight of the XBTGT2330?

The XBTGT2330 weighs 1 kg, making it relatively lightweight and easy to handle during installation and maintenance.
