MANUFACTURER: Schneider Electric
DESCRIPTION: Modbus I/O Module Base - 6 I / 3 O
PRODUCT TYPE INFO: Modicon Momentum
| Part Number | 170ADM54080 |
| Manufacturer | Schneider Electric |
| Series | Modicon Communication |
| Model # | 170ADM54080 |
| Alternate Model | 170-ADM-540-80 |
| Type | IO Modules |
| Warranty | 2 Year |
| [Us] rated supply voltage | 115...220 V AC |
| 24 V DC | |
| Range of product | Modicon Momentum automation platform |
| Product or component type | Modbus I/O module base |
| Group of channels | 1 group of 3 discrete outputs |
| 1 group of 6 discrete inputs | |
| Discrete input number | 6 |
| Discrete output number | 3 |
| Number of port | 1 |
| Communication port protocol | Modbus |
| Wiring mode | 2 or 4 wires |
| Discrete input logic | Positive |
| Discrete input voltage | 0...132 V AC |
| 120 V AC 47...63 Hz | |
| Maximum overvoltage on input | 200 V |
| Voltage state 1 guaranteed | >= 79 V |
| Voltage state 0 guaranteed | <= 20 V |
| Current state 1 guaranteed | >= 5.5 mA |
| Current state 0 guaranteed | <= 1.9 mA |
| Discrete output logic | Positive |
| Discrete output voltage | 120 V 47...63 Hz |
| Discrete output current | 0.5 mA per point |
| 1.5 mA per module | |
| Voltage drop | < 1.5 V 0.5 A at state on |
| Leakage current | 1.9 mA AC 120 V |
| Surge current | >= 30 mA |
| Response time | < 12.3 ms 60 Hz from state 1 to state 0 input circuit |
| < 12.3 ms 60 Hz from state 1 to state 0 output circuit | |
| < 12.5 ms 60 Hz from state 0 to state 1 input circuit | |
| < 12.5 ms 60 Hz from state 0 to state 1 output circuit | |
| Communication port support | RS485 |
| Transmission rate | 19200 bit/s |
| 9600 bit/s | |
| Data format | 7-bit ASCII |
| 8-bit RTU | |
| Number of addresses | 0...247 |
| Port timeout | 150 ms |
| Marking | CE |
| Electrical connection | 2 connectors for removable terminal blocks |
MRO Electric repairs CNCs, PLCs, Servo/Spindle Drives, Motors, Amplifiers, VFDs, HMIs, and more, most of which can be repaired in only 3-5 days.
MRO can restore your failed 170ADM54080 to remanufactured condition and save you up to 75% compared to buying new. We offer standard repair pricing to ensure you the best value for your repair.
Our certified technicians use rigorous testing procedures to ensure your parts are restored to fully functioning condition. Our team proudly stands behind all repairs by providing a minimum 2 year warranty.
Our technicians have vast experience with most manufacturers and models. In addition to this 170ADM54080 we also repair drives, motors, PLCs and more, so if you don’t see the model you need, please contact us.
If you are interested in getting credit for your faulty 170ADM54080, just let us know and we can issue you an RMA to send it in as an exchange. Our exchange program provides you with savings and keeps us stocked for the next time you need anything.
Want it shipped today?
Ask about exchanging your faulty 170ADM54080 for credit when ordering from MRO Electric
Additional Information
The 170ADM54080 is a Modbus I/O Module Base - 6 I / 3 O that is manufactured by Schneider Electric. These products are manufactured in France and are designed for Material handling, packaging, and textile machines usage. All of the products in the modicon-communication line come with a 2 year warranty from MRO Electric. We also carry Momentum from other manufacturers such as Modicon and ABB.
