Schneider Electric 170ADM69051

MODICON MOMENTUM DISCRETE I/O MODULE - 10I / 8O SOLID STATE

5/5
1 rating

Select Condition

Refurbished

6 in stock

$463.00

Request a Quote
  • Ships Today
  • 2 Year Warranty
  • Free Shipping
Part Number170ADM69051
ManufacturerSchneider Electric
TypeI/O Modules
Model #170-ADM-690-51
Warranty2 Year
Width4.92 in (125 mm)
Range of productModicon Momentum automation platform
Product or component typeDiscrete triac I/O base AC
Group of channels1 group of 8 outputs
1 group of 10 inputs
Discrete input number10 IEC 1131-2 Type 2
Discrete input logicPositive
Discrete input voltage120 V AC
Discrete output number8
Discrete output typeTriac
Discrete output voltage120...132 V DC
Discrete output logicPositive
Protective treatmentTC
[Us] rated supply voltage120 V AC
Input voltage limits74...132 V
Network frequency47...63 Hz
Voltage state 0 guaranteed< 20 V
Voltage state1 guaranteed> 74 V
Current state 0 guaranteed<= 2.6 mA
Current state 1 guaranteed>= 6 mA
Input resistance4 kOhm
Discrete output current2 A per group
4 A per module
30 mA...0.5 A per point
Leakage current< 1.3 mA 120 V output circuit
Voltage drop< 1.5 V 0.5 A at state 1 output circuit
Operating rate3000 cyc/h 0.5 A inductive
Response time1/2 x 1/f from state 0 to state 1 on input
1/2 x 1/f from state 0 to state 1 on output
1/2 x 1/f from state 1 to state 0 on input
1/2 x 1/f from state 1 to state 0 on output
Isolation between channels and bus1780 V AC
Power dissipation6 W
<= 8 W
Protection typeInternal 2 x 2.5 A slow-blow fuses
MarkingCE
Terminals description PLC n°1(4)IN_DIS#4
(1)IN_DIS#1
(10)IN_DIS#10
(N)PW
TB
(8)IN_DIS#8
(5)IN_DIS#5
(7)IN_DIS#7
(L1)PW
(6)IN_DIS#6
(9)IN_DIS#9
(2)IN_DIS#2
(3)IN_DIS#3
Terminals description PLC n°2(6)OUT_DIS#6
(1N)PW
(4)OUT_DIS#4
(1)OUT_DIS#1
(2)OUT_DIS#2
(7)OUT_DIS#7
(1L1)PW
TB_1
(5)OUT_DIS#5
(3)OUT_DIS#3
(8)OUT_DIS#8
Current consumption160 mA 120 V AC
Depth1.87 in (47.5 mm)
Height5.57 in (141.5 mm)

Our Repair Services

MRO Electric repairs CNCs, PLCs, Servo/Spindle Drives, Motors, Amplifiers, VFDs, HMIs, and more, most of which can be repaired in only 3-5 days.

Repair Benefits

MRO can restore your failed 170ADM69051 to remanufactured condition and save you up to 75% compared to buying new. We offer standard repair pricing to ensure you the best value for your repair.

Our certified technicians use rigorous testing procedures to ensure your parts are restored to fully functioning condition. Our team proudly stands behind all repairs by providing a minimum 2-year warranty.

Our technicians have vast experience with most manufacturers and models. In addition to this 170ADM69051 we also repair drives, motors, PLCs and more, so if you don’t see the model you need, please contact us.

Core Exchange

If you are interested in getting credit for your faulty 170ADM69051, just let us know, and we can issue you an RMA to send it in as an exchange. Our exchange program provides you with savings and keeps us stocked for the next time you need anything.

  • Shipping Weight : 1lb

Want it shipped today?

  • Order within the next 7 hours and 53 minutes.
  • If you order between 4pm and 6pm EST, you will be charged a small rush fee.

Ask about exchanging your faulty 170ADM69051 for credit when ordering from MRO Electric

MRO Electric provides a 2-year warranty on every item we sell and repair. We stand behind all of our products and guarantee them for the full 2 years. If there is an issue with any of our products within the warranty period, we will evaluate the unit and repair or replace it under warranty.

Schneider Electric 170ADM69051 Overview

Schneider Electric 170ADM69051 I/O Module

The Schneider Electric 170ADM69051 is a robust and reliable discrete triac I/O base module part of the Modicon Momentum automation platform. Engineered for seamless integration into modern industrial automation systems, this module offers a compact yet powerful solution for interfacing both discrete inputs and outputs within a control architecture. Measuring 4.92 inches in width, 5.57 inches in height, and 1.87 inches in depth, the 170ADM69051 is designed to fit efficiently into tight spaces while delivering high-performance operation in demanding environments.

Dual Functionality with Inputs and Outputs

The 170ADM69051 is a versatile unit featuring one group of 10 discrete inputs and one group of 8 discrete outputs. The discrete input side complies with IEC 1131-2 Type 2 standards. It uses positive logic to operate at 120 V AC. Input voltage limits range from 74 V to 132 V, with guaranteed state detection thresholds below 20 V for logic zero and above 74 V for logic 1. The discrete output section consists of triac-based outputs that handle 120 to 132 V DC, also using positive logic. With a maximum of 2 A per group and 4 A per module, this output capacity is ideal for controlling various industrial devices. Each output point is rated between 30 mA and 0.5 A, providing precise control and low-power switching capability.

Performance, Speed, and Electrical Specifications

The Schneider 170ADM69051 offers a high-speed response with switching times defined by half the cycle of the input frequency, enabling fast and accurate data processing. This makes the module suitable for applications that require reliable and quick decision-making. Operating at a network frequency of 47 to 63 Hz, the module includes built-in protection with two internal 2.5 A slow-blow fuses. The unit ensures electrical isolation between the I/O channels and the system bus at a rating of 1780 V AC. Input resistance is four kΩ, and current thresholds are carefully designed to guarantee performance even in electrically noisy environments. With low voltage drop (less than 1.5 V at 0.5 A) and minimal leakage current (less than 1.3 mA), the module maintains energy efficiency and reduces the risk of inadvertent activation.

Ease of Use, Reliability, and Support

Designed with clearly marked terminal descriptions for simplified installation and troubleshooting, the 170ADM69051 is built for easy use in real-world applications. It features protective treatment TC for enhanced durability and environmental resistance. The unit's power dissipation is between 6 W and 8 W, keeping it cool during extended operation. Certified with CE marking, this module meets global quality and safety standards. Backed by a 2-year warranty from MRO Electric and Supply, and available for immediate shipping with free delivery, the 170ADM69051 offers unmatched value and dependable performance in any automation setup.
